Heat output I

Temperature set: 50/45/20 °C
Panel length
1.00 - 1.19 m
1.20 - 1.39 m
1.40 - 1.59 m
1.60 - 1.79 m
1.80 - 1.99 m
2.00 - 2.19 m
2.20 - 2.39 m
2.40 - 2.59 m
2.60 - 2.79 m
2.80 - 2.99 m
3.00 - 3.19 m
3.20 - 3.39 m
3.40 - 3.50 m
Temperature set: 60/50/20 °C
Panel length
1.00 - 1.19 m
1.20 - 1.39 m
1.40 - 1.59 m
1.60 - 1.79 m
1.80 - 1.99 m
2.00 - 2.19 m
2.20 - 2.39 m
2.40 - 2.59 m
2.60 - 2.79 m
2.80 - 2.99 m
3.00 - 3.19 m
3.20 - 3.39 m
3.40 - 3.50 m
12
Heat output
80 W
137 W
196 W
254 W
313 W
370 W
427 W
487 W
552 W
617 W
683 W
749 W
815 W
Heat output
83 W
153 W
226 W
301 W
377 W
453 W
530 W
605 W
681 W
755 W
829 W
902 W
983 W
VD.YC.D2.02 © Danfoss 01/2006
(Fan speed: 1500 RPM)
Flow
14 l/h
24 l/h
34 l/h
44 l/h
54 l/h
65 l/h
75 l/h
85 l/h
96 l/h
108 l/h
119 l/h
131 l/h
142 l/h
(Fan speed: 1500 RPM)
Flow
7 l/h
13 l/h
20 l/h
26 l/h
33 l/h
40 l/h
46 l/h
53 l/h
60 l/h
66 l/h
73 l/h
79 l/h
86 l/h
CONVEC
