Heat Output II

Temperature set: 70/40/20 °C
Panel length
1.00 - 1.19 m
1.20 - 1.39 m
1.40 - 1.59 m
1.60 - 1.79 m
1.80 - 1.99 m
2.00 - 2.19 m
2.20 - 2.39 m
2.40 - 2.59 m
2.60 - 2.79 m
2.80 - 2.99 m
3.00 - 3.19 m
3.20 - 3.39 m
3.40 - 3.50 m
Temperature set: 75/65/20 °C
Panel length
1,00 - 1,19 m
1.20 - 1.39 m
1.40 - 1.59 m
1.60 - 1.79 m
1.80 - 1.99 m
2.00 - 2.19 m
2.20 - 2.39 m
2.40 - 2.59 m
2.60 - 2.79 m
2.80 - 2.99 m
3.00 - 3.19 m
3.20 - 3.39 m
3.40 - 3.50 m
CONVEC
Heat output
29 W
74 W
131 W
195 W
263 W
333 W
407 W
481 W
556 W
633 W
709 W
787 W
864 W
Heat output
140 W
243 W
349 W
457 W
564 W
670 W
775 W
878 W
990 W
1,108 W
1,227 W
1,347 W
1,467 W
VD.YC.D2.02 © Danfoss 01/2006
(Fan speed: 1500 RPM)
Flow
1 l/h
2 l/h
4 l/h
6 l/h
8 l/h
10 l/h
12 l/h
14 l/h
16 l/h
19 l/h
21 l/h
23 l/h
25 l/h
(Fan speed: 1500 RPM)
Flow
12 l/h
21 l/h
31 l/h
40 l/h
50 l/h
59 l/h
68 l/h
78 l/h
87 l/h
98 l/h
108 l/h
119 l/h
129 l/h
13
