Quantum Scalar i6000 Manual page 52

15 Slide the robot an inch or two to the left until the collectors are positioned in front of the power rail load
guides (see Figure 28
Figure 28 Power Rail Load Guides
16 Close the collector door and tighten the two captive thumbscrews (see
the collectors into the power rails.
52
).
Power rail load
guides
Figure 19 on 42). This pushes
Introduction
