Choosing the HSIO Operating Mode

Understanding the
Six Modes
Mode
High-Speed
Counter
Quadrature
Counter
High-Speed
Interrupt
Pulse Catch
Pulse Output
Filtered Input

Default Mode

The High-Speed I/O circuit operates in one of 6 basic modes as listed in the table
below. The number in the left column is the mode number (later, we'll use these
numbers to configure the PLC). Choose one of the following modes according to the
primary function you want from the dedicated High-Speed I/O circuit. You can simply
use all eight inputs and six outputs as regular I/O points with Mode 60.
Mode Mode Name
Number
10 High-Speed
Counter
20 Quadrature
Counter
30 Pulse Output
40 High-Speed
Interrupt
50 Pulse Catch
60 Discrete/Filtered
Input
In choosing one of the six high-speed I/O modes, the I/O points listed in the table
below operate only as the function listed. If an input point is not specifically used to
support a particular mode, it usually operates as a filtered input by default. Similarly,
output points operate normally unless Pulse Output mode is selected.
Physical I/O Point Usage
DC Input Points
X0
Counter clock Filtered Input
Phase A Input Phase B Input
Interrupt Input Filtered Input
Pulse Input Filtered Input
Filtered Input Filtered Input
Filtered Input Filtered Input
Mode 60 (Filtered Inputs) is the default mode. The DL05 is initialized to this mode at
the factory, and any time you reset V-memory scratchpad. In the default condition,
X0–X2 are filtered inputs (10 mS delay) and Y0–Y1 are standard outputs.
Mode Features
5 kHz counter with 24 presets and reset input,
counts up only, causes interrupt on preset
Channel A / Channel B 5 kHz quadrature input,
counts up and down
Stepper control – pulse and direction signals,
programmable motion profile (7kHz max.)
Generates an interrupt based on input transition
or time
Captures narrow pulses on a selected input
Rejects narrow pulses on selected inputs
X1 X2
Filtered Input
or Reset Cnt
Filtered Input
or Reset Cnt
Filtered Input
Filtered Input
Filtered Input,
Filtered Input
DC Output Points
Y0 Y1
Regular Output Regular Output
Regular Output Regular Output
Regular Output Regular Output
Regular Output Regular Output
Pulse Direction
or or
CW Pulse CCW Pulse
Regular Output Regular Output
