EPSON Stylus Photo RX585/RX595/RX610

1.7.6.2 Ink Levels

The current ink levels of each of the cartridges are displayed in bar chart by the rules
described below. After displaying the ink levels, the next operation can be selected
from the following two options; "End the ink levels display" or "Change Ink
Cartridge".
• The bar chart is displayed in the order of yellow, black, light cyan, light magenta, magenta,
and cyan from the left.
• When initial ink charge is completed, or after replacing the cartridge, the ink level becomes
100% (full).
• The ink level is indicated in increment of 1%. Lower than 1% is rounded down.
• When the ink level becomes lower than 10%, "!" icon appears to notify the user of the ink low
status.

1.7.6.3 PictBridge Setup

The print settings to be used for the camera direct print (USB Direct Print/PictBridge)
can be specified. When print settings (paper type, paper size, layout, quality, auto
correct) are specified from the DSC, the DSC settings are applied and the settings made
here are ignored. For more details, see
Direct Print/PictBridge) (p.27)".
1.7.6.4 CD Print Position (EAI)
CD/Sticker Print Position (Euro, Asia)
The printing range when printing on a CD/DVD or a sticker can be adjusted.
1.7.6.5 Backup Memory Card
This menu allows the user to make a backup copy of a memory card on media in an
external device. The "Folder Select" displays a folder selection screen to select the
target folder in an external media to be printed.
The "Folder Select" menu item is disabled (grayout) in the following cases.
When any external device is not connected
When no image files is detected in the inserted memory card.
See "1.7.3 Backup Function (p.25)"
Product Description
"1.7.4 Camera Direct Print Function (USB
for more information on the backup function.
Specifications of Each Function

1.7.6.6 Bluetooth Settings

Bluetooth communication settings can be configured. This menu is enabled only when
the optional Bluetooth unit is connected.
Table 1-35. Bluetooth Settings Sub Menus
Item
Sets the passkey to request to an external device when accepting the
BT PIN Code Set communication request from the device. The setting range is 0000 to
9999.
Sets the printer ID to be identified in the Bluetooth communication
when multiple same models exist. Enter a one-digit number (1 to 9, 0)
BT Printer ID Set
to be appended as a suffix to the printer name. The change does not
take effect until the printer is rebooted.
Selects the BT communication mode from the following three
options.
• Discoverable
Allows an external device to search for the printer and the
connection can be established.
No authentication or passkey request is made by the printer.
• Not Discoverable
Does not allow an external device to search for the printer but the
BT Mode
connection can be established.
No authentication or passkey request is made by the printer.
• Pairing
Allows an external device to search for the printer and the
connection can be established.
The printer requests a passkey to the device. Once the connection is
established, the printer remembers the device (only one device can
be remembered), and does not request a passkey for the second or
later access of the device.
When this is set to "On", the Bluetooth communication data is
BT Encryption
encrypted and the printer requests device authentication.
The physical address (unique value) of the Bluetooth module is
BT Device Address displayed. The address is displayed in hexadecimal 12-digit numbers
(xx-xx-xx-xx-xx-xx).
Revision B
Explanation
32
