Htek UC8xxSERIES SIP PHONE
Auto Provision User Guide
Nanjing Hanlong Technology Co., Ltd.
0086-25-84658050
www.htek.com
sales@htek.com
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the UC802 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Htek UC802

Summary of Contents for Htek UC802

  • Page 1 Htek UC8xxSERIES SIP PHONE Auto Provision User Guide Nanjing Hanlong Technology Co., Ltd. 0086-25-84658050 www.htek.com sales@htek.com...

  • Page 2: Table Of Contents

    Table of Contents Table of Contents 1. Introduction ..............................1 2. Manage Configuration ..........................1 2.1 Obtain configuration files ........................ 2 2.2 Obtain phone information ........................3 2.3 Manage configuration files ......................... 3 2.4 How to edit cfg000x.xml file ....................... 3 2.5 How to edit cfg$mac file ........................
  • Page 3 Configuration File HTTP/HTTPS/FTP/TFTP ..........................33 18.1 Generate the configuration file for Htek IP Phones ................ 33 18.1.1 Select manual mode to generate CFG file ................33 18.1.2 Select File Input mode to generate CFG file ................35 18.2 Upgrade cfgmac file via HTTP/TPFP/FTP/HTTPS ................. 39 19.Making Ringtone Notes ...........................
  • Page 4 Table of Contents 21.1 How to custom the wallpaper1-wallpaper6? ................... 48 21.2 How to custom the screensaver1- screensaver3? ................. 48 21.3 How to custom the weblogo? ......................48 21.4 How to customthe eights meuns(.png)in the main menu? .............. 48 21.5 How to customthe ...Icon.png? ...................... 48 21.6 How to custom the lcdlogo_color.png? ..................

  • Page 5: Introduction

    MAC based configuration file. When Htek IP Phone boots up or reboots, it will issue a request for these configuration files named “factory000x.bin” --> “cfg000x.xml” -->”cfgMAC” --> “cfgMAC.xml “, in which “000x” is the Device Code.

  • Page 6: Obtain Configuration Files

    UC826 0009 factory0009.bin/cfg0009.xml Process of Htek products are as follows: factory000x.bin -----used for factory default configuration for ODM/OEM cfg000x.xml ----- used for update the common configuration which doesn’t include the account information. cfg001fc1xxxxxx ---- this file is a private format for each device cfg001fc1xxxxxx.xml------used for configuration for each device.

  • Page 7: Obtain Phone Information

    IP address of the SIP server. Contact your system administrator for SIP account information. 2.3 Manage configuration files Auto provision enables Htek IP Phone to update automatically via downloading configuration files. Before provisioning, you may need to edit and customize your configuration file which is composed of many configuration parameters.
  • Page 8 Manage Configuration The line beginning with “#” is considered to be the annotation, and it’s easy to understand each P value. The parameters commonly edited in the cfg$mac file are described as follows: ############################################################################### ##### ## Configuration template for UC860 firmware version 1.0.3.70 ############################################################################### ##### ###############################################################################...
  • Page 9 Manage Configuration # Primary SIP Server(eg:sip.mycompany.com or IP address) # String P47 = {$server_host.line.1} # Failover SIP Server (Optional, used when primary server no response) # String P967 = # Second Failover SipServer (Optional, used when Failover SIP Server no response) P8851 = # Prefer Primary SIP Server (Yes-will register to Primary SIP Server if Failover registration expires) # Prefer Primary SIP Server (In Use).
  • Page 10 Manage Configuration # DNS Mode. 0 - A Record, 1 - SRV, 2 - NAPTR/SRV # Number: 0-2 # Mandatory P103 = 0 # User ID Is Phone Number.0 - No, 1 - Yes # Number:0, 1 P63 = 0 # SIP Registration.

  • Page 11: How To Edit Cfgmac.xml File

    You need to download cfg.xml file from IP Phone webpage(Management->Configuration->Download xml file) or download this cfgmac.xml file from website www.htek.com, then change the file name to cfgmac.xml(mac is IP Phone address), and open the cfgmac.xml, See the below screen shot:...
  • Page 12 Manage Configuration <?xml version="1.0" encoding="UTF-8" ?> <hl_provision version="1"> <mac para="Mac">001fc11a0012</mac> <config version="1"> <!--Account1/Basic--> <P271 para="Account1.Active"></P271> <P47 para="Account1.Sipserver"></P47> <P967 para="Account1.FailoverSipserver"></P967> <P8851 para="Account1.SecondFailoverSipserver"></P8851> <P4567 para="Account1.PreferPrimaryServer"></P4567> <P48 para="Account1.OutboundProxy"></P48> <P130 para="Account1.SipTransport"></P130> <P52 para="Account1.NatTraversal"></P52> <P20000 para="Account1.Lable"></P20000> <P35 para="Account1.SipUserId"></P35> <P36 para="Account1.AuthenticateID"></P36> <P34 para="Account1.AuthenticatePassword"></P34> <P3 para="Account1.DispalyName"></P3> <P103 para="Account1.DnsMode"></P103> <P63 para="Account1.UserIdIsPhoneNumber"></P63>...

  • Page 13: Encrypt Configuration Files

    Encrypt Configuration Files 3. Encrypt Configuration Files Htek Configuration Generator allows user to encrypt the generated configuration file with AES 128-bit encryption. It allows user to choose not to encrypt the configuration file in Windows version, but it is recommended to use encryption for security reason.

  • Page 14: Customize Resource Files

    Customize Resource Files 4. Customize Resource Files Htek IP Phone allows you to customize some resource files, such as the ring tone file, language package file and the logo files. For how to customize these resource files, the procedure is as follows: 4.1 Customizering tone...

  • Page 15: Customize Web Language

    56. 4.3 Customize web language Htek IP Phone supports multiple language, you can modify the language and add a new language to the phone’s webpage. The following table lists all available languages, associated language files and language template file:...

  • Page 16: Customizing Wallpaper

    For more information on customizing web language file, please refer to << Web Language custom guide>>in page 58. 4.4 Customizing wallpaper You can customize Htek UC840P/UC842/UC860P/UC862 IP phones' wallpaper. Below table shows wallpaper's format and resolution for UC840P/UC842/UC860P/UC862 IP phones: Phone model photo format resolution...

  • Page 17: Customizing Screensaver

    5. Upgrade resource files Htek IP phone supports upgrade resource files through URL(support HTTP(s) server). The files contain hlpres.tar, Language.tar, ring4.bin, ring5.bin, ring6.bin, ring7.bin, ring8.bin, exp_pres.tar, Screensaver and wallpaper. For how to configure these files URL as follow: 5.1 How to configure URL for hlpres.tar...

  • Page 18: How To Configure Url For Language.tar

    Customize Resource Files P20176=http(s)://192.168.0.254/hlpres.tar 5.2 How to configure URL for Language.tar You can change the Language server configuration parameter to locate the file: P20175=http(s)://192.168.0.254/Language.tar 5.3 How to configure URL for exp_pres.tar You can change the exp_pres server configuration parameter to locate the file: P20177=http(s)://192.168.0.254/exp_pres.tar 5.4 How to configure Path for ringx.bin You can change the Ring server configuration Path, and IP Phone will get the files: ring4.bin, ring5.bin,...

  • Page 19: Upgrade Firmware

    6.1 Configuring HTTP Server Htek IP Phone supports using FTP, TFTP, HTTP and HTTPS protocols to obtain the address of provision server. Default way is HTTP. For how to configure a HTTP server, as follows: You can download a free HTTP server from http://httpd.apache.org/or use Microsoft IIS web server.
  • Page 20 (5) Restart the UC8xx, IP Phone will restart and automatically get firmware files from HTTP server. NOTES: (1) We recommend you to use Htek HTTP server, or you can also use your own TFTP/HTTP/FTP/HTTPS server for upgrade and provisioning procedures.

  • Page 21: Obtain Provisioning Server's Address

    (3) Firmware upgrade takes 3 to 8 minutes over Internet, or just 1 minute on a LAN. We recommend you to upgrade the FW in a controlled LAN environment. 7. Obtain Provisioning Server's Address Htek IP Phone supports to obtain the provisioning server address in below 3 ways:  Plug and Play (PnP) Server ...
  • Page 22 Obtain Provisioning Server's Address Configuration in Flash. If you set “No”, or don’t set DHCP option 128/66/150 in your DHCP server, the phone will obtain the provisioning server address from the setting “Config Server Path”. For examples, when the setting is: The phone will get the configuration file from 192.168.0.254/cfgthrough HTTP protocol.

  • Page 23: Update Mode

    Update Mode For examples: The phone will check the configuration file and the firmware every 10080 minutes (7 days). If there are the new cfg files or the new firmware, the phone will upgrade automatically. 8. Update mode Update mode sets the desired time for phone to perform the auto provisioning process. Below is the introduction of the 3 update modes in detail: ...
  • Page 24 Update Mode The phone will perform auto provisioning process when receiving a SIP NOTIFY message which contains the header “Event: check-sync”. If the header of the SIP NOTIFY message contains an additional string “reboot=true”, the phone will reboot immediately and then perform the auto provisioning process. For this update mode, it requires the server supports.

  • Page 25: Download And Verify Configurations

    You can verify the update via phone user interface after auto provisioning, or you can verify it via web user interface During the auto provisioning process, you can monitor the downloading requests and response messages by a wireshark tool. Some examples show as follows: Example1: Htek UC860P IP Phone downloads configuration files from TFTP server.
  • Page 26 Download and Verify Configurations Example2: Htek UC860P IP Phone downloads configuration files from FTP server. Example3: Htek UC860P IP Phone downloads configuration files from HTTP server.

  • Page 27: Firmware And Configuration File Prefix And Postfix

    Firmware and Configuration File Prefix and Postfix 10. Firmware and Configuration File Prefix and Postfix Htek IP Phone Support Prefix and Postfix for both firmware and configuration files. Parameter P232 and P233 are for Prefix and Postfix for Firmware, respectively. Parameter P234 and P235 are for Prefix and Postfix for Configuration file, respectively.

  • Page 28: Firmware Server And Configuration File Server

    Firmware Server and Configuration File Server If the firmware version is 1.0.3.73 or later than 1.0.3.73, the firmware BASIC NAME as follows:  fw860.rom Service provider can use “hl_” as prefix, and “_1.0.3.73” as postfix, the above files will be changed to: ...

  • Page 29: Pre_Configuration And Configuration Redirection

    After we inform you that the devices have been entered into our central provisioning database, please take out a few devices to test. Upon powering up, they should contact our provisioning server fm. htek.com first, and then get redirected to your TFTP/FTP/HTTP/HTTPS server and pull out the configuration files and the...

  • Page 30: Automatic Provisioning Within Lan

    14. Automatic Provisioning Within LAN Htek products support DHCP Option 66 or 128 or 150 for automatic provisioning within a Local Area Network. The provisioning server URL is embedded inside standard option 66 or 128 or 150 of DHCP responses.

  • Page 31: Troubleshooting

    Troubleshooting 15. Troubleshooting This part provides guidance to help you solve problems you might encounter when deploying phones. If you require additional information or assistance with the deployment, please contact your system administrator. When the phone fail to download configuration files. ...

  • Page 32: Glossary

    Glossary 16. Glossary MAC Address: A Media Access Control address (MAC address) is a unique identifier assigned to network interfaces for communications on the physical network segment. DHCP: Dynamic Host Configuration Protocol (DHCP) is a network configuration protocol for hosts on Internet Protocol (IP) networks.

  • Page 33: How To Edit Cfg000X.xml

    ------> cfg0009 For example, if you have a Htek device UC862 and you want to configure its memory key 1 as BLF to monitor extension 1002, you can realize this by following two methods. 1.Create a new XML file and add configuration parameters.
  • Page 34 Manage Firmware and Download Configuration File Step 3: Refer to << parameter list >>, you can get detailed description of this parameter. According to description of parameter, we know parameter P42200 should be 3, parameter P42300 should be 1002 and parameter P42500 should be *20*. Step 4: Edit cfg0000.xml as follow...
  • Page 35 Manage Firmware and Download Configuration File Step 5: Put this XML configuration file in your config server path. Step 6: Restart phone to apply to the settings. 2.Edit relevant parameter in the template file(template.xml) Step 1:Login webpage, enter Function Keys -> Memory Key Step 2 : Configure options you want, for example Step 3: click “saveset”...
  • Page 36 Manage Firmware and Download Configuration File Step 6: Change the xml file’s name to cfg0000.xml. Step 7: Put this XML configuration file in your config server path. Step 8: Restart phone to apply to the settings.

  • Page 37: Http/Https/Ftp/Tftp

    FTP Server:192.168.0.240 TFTP Server:192.168.0.240 Tool: HLCFGTool.exe 18.1 Generate the configuration file for Htek IP Phones There are two modes to generate the configuration file 18.1.1Select manual mode to generate CFG file Generally, it is used to generate the general config file.
  • Page 38 Generate Configuration File with HLLite Tool Step 1:Select a template; Step 2: Modify the value to you want, such as change the web log in password from admin to Dd123478 Step 3: Click the CFG Option Tag, Select the CFG file type; Step 4: File sequential or listing MAC address, such as bellow: According to the displayed number, will generate 272(270+2) CFG files.

  • Page 39: Select File Input Mode To Generate Cfg File

    Generate Configuration File with HLLite Tool Step 6: CFG files Generation finished. 18.1.2 Select File Input mode to generate CFG file In this way, it can be used to generate basic config, moreover, it also can be used to config account information.
  • Page 40 Generate Configuration File with HLLite Tool Account 1: sip user id(P35); Authenticate ID(P36); Authenticate password(P34); Name(P3) Account 2: sip user id(P735); Authenticate ID(P736); Authenticate password(P734); Name(P703) Step 3: Define a set of variable to assign value to this parameter name, must use this format {$...}. About the variable name, you can decide by yourself.
  • Page 41 Generate Configuration File with HLLite Tool You can select Save To a Template for feature use after editing finished. Step 3: Click the CFG Option Tag, Select the CFG file type; Step 4: Click the File Input Tag, Select the .csv file type, such as sample.csv.
  • Page 42 Generate Configuration File with HLLite Tool Step 5: Click the Brose button, select a Destination Path: Step 6: Click the Go button, application start to generate CFG files. Step 7: CFG files Generation finished.

  • Page 43: Upgrade Cfgmac File Via Http/Tpfp/Ftp/Https

    Generate Configuration File with HLLite Tool 18.2 Upgrade cfgmac file via HTTP/TPFP/FTP/HTTPS Step 1:Login Htek IP device’s webpage, ManagementAuto Provision： Via HTTP mode: Via TFTP mode: Via FTP mode:...
  • Page 44 Generate Configuration File with HLLite Tool Via HTTPS mode: You can select the upgrade Mode what you want. Step 7: Restart the Htek IP device. e.g:You can see the request logs on the server: Test result:...
  • Page 45 Generate Configuration File with HLLite Tool...

  • Page 46: Making Ringtone Notes

    Making Ringtone Notes 19. Making Ringtone Notes Prepare: Tool: Ringtool.exe Ring file format: wav 1. To make ring tone for UC8xx 1.1 Double click Ringtool.exe 1.2 Select the Maximum Length and Output Filename: For example, 16 seconds, ring 2.bin 1.3 Click Select to Input the desired ring tone file, and then click Generate Ringfile. Then, you will get Ringfile Created.
  • Page 47 Making Ringtone Notes 1.4 Now, you get the ring2.bin, also you can rename it as ring5.bin, or other the one you want to replace. 1.5 Upload the ring file by TFTP or HTTP, the ringtone is replaced successfully.

  • Page 48: Lcd And Web Language Custom Guide

    LCD and Web GUI Custom Guide 20.LCD and Web Language Customization Guide 20.1. Guide onLCD Language customization. 1) You need to contact us about how to obtain the Language.tar file. 2) Unzip the Language.tar using 7-zip tool. 3) Open the Language folder: Note: The file name must be "...

  • Page 49: Web Language Custom Guide

    LCD and Web GUI Custom Guide  Select the Language folder Compress Language.tar package using 7-zip tool and Cover the originalDelete the Language folder Note: If you use UltraEdit, it can generate .xml.bak file after saved .so you need to delete .xml.bak file. If you want to put your language on the front of other languages, you can also rename the file, for example: 20.2.Web Language custom guide 1) You need to contact us about how to obtain the Language.tar file...
  • Page 50 LCD and Web GUI Custom Guide Note: The file name must be " digital_letter" at the beginning, the format of the file name is the order of the on the Web. 4. For example custom Chinese Language If your country's language is not existing in the language folder, you can upload a new xml file with correct naming format.

  • Page 51: Lcdand Web Gui Custom Guide

    LCD and Web GUI Custom Guide  Select the Language folder Compress Language.tar package using 7-zip tool and Cover the originalDelete the Language folder Note: If you use UltraEdit, it can generate.xml.bak file after saved .so you need to delete.xml.bak file. If you want to put your language on the front of other languages, you can also rename the file, for example: When you finished the Language.tar, you must send the Language.tar package to us, then we provide the firmware to you.

  • Page 52: How To Custom The Wallpaper1-Wallpaper6

    21.7 How to customize the lcdlogo_bw.png? This logo is only applicable to UC802, UC803, UC804, UC806 Open hlpres folderyou can custom the lcdlogo_bw.png (dimension:100*11 size: through Photoshop tools make the size smaller) Select the hlpres folderCompress hlpres.tar package.
  • Page 53 LCD and Web GUI Custom Guide Note: The photo’s name and format must be the same as before; The size of hlpres file is not more than 2M. When you finished the hlpres.tar, you must send the hlpres.tar package to us,then we provide the firmware to you.

  • Page 54: Firmware Upgrade

    Firmware Upgrade 22.Firmware Upgrade Please note: If the firmware version is 1.0.3.73 or later than 1.0.3.73,you must put the upgrade files(include fw8xx.rom,img_8xx.bin ) into the server path. Later than 1.0.3.73 version upgrade steps and earlier than 1.0.3.73 version is the same. 22.1.
  • Page 55 Firmware Upgrade 6) Go to File -> Configure -> Security to change the TFTP server's default setting from "Receive Only" to "Transmit Only" for the firmware upgrade. 1) Start the TFTP server, Configure the Firmware Server Path with the IP address(192.168.0.240 is TFTP server) in the UC8xx’s web configuration page.

  • Page 56: Upgrade Through Ftp

    Firmware Upgrade 2) SaveSet the change and restart the IP Phone. 3) You can test your TFTP server by another PC which is in the same LAN segment. For examples, in PC which IP address is 192.168.0.126, type command: TFTP -i 192.168.0.240 GET fw860.rom f:/fw860.rom If your TFTP server is OK, something like “Transfer successful:”...

  • Page 57: Upgrade Through Https

    Firmware Upgrade 6) Click the SaveSet and then click Restart in the webpage. 22.3. Upgrade through HTTPS 1) Installing and configuring an Apache HTTPS Server in local computer. 2) Unzip the firmware file and put all of them under the root/fm directory of the HTTPS Server. 3) Visiting “HTTPS:\\192.168.0.45\fm\fw860.rom on localhost by browser”...

  • Page 58: Parameter List

    Parameter List 23.Parameter List Web Setting Path Permitted Descriptions Parameter Values Account(1)->basic->Acc Number: 0, 1 Account Active (In Use). 0 - No, 1 - Yes P271 ount Active Account(1)->basic->Prim PrimarySIP It configures the primary SIP server when ary SIP Sserver Server(eg:sip the network is locallan 、remotestun or .mycompany.
  • Page 59 Parameter List Account(1)->basic-> Number:0, 1 OutgoingCallWithout Registration.0 - No, 1 P109 OutgoingCallWithout - Yes Registration Account(1)->basic-> number Local SIP Port (default 5060) Local SIP Port Account(1)->basic-> Use Number:0, 1 Use Random Port.0 - No, 1 - Yes Random Port Account(1)->basic-> String Voice Mail User ID(User ID for voice mail Voice Mail UserID...
  • Page 60 Parameter List Account-> Advanced -> Number:0, 1 DTMF Via RFC2833.0 - no, 1 - yes P851 DTMF Via RFC2833 Account (1)-> Advanced Number:0, 1 DTMF Via SIP INFO.0 - no, 1 - yes P852 -> DTMF Via SIP INFO Account (1)-> Advanced Number:0, 1 Send Flash Event.0 - no, 1 - yes ->...
  • Page 61 Parameter List -> Auto Answer Account (1)-> Advanced Number: 0, 1 Allow Auto Answer by Call-Info.0 - no, 1 - P298 -> Allow Auto Answer by Call-Info Account (1)-> Advanced Number: 0, 1 Turn off Speaker on remote disconnect.0 - P299 ->...
  • Page 62 Parameter List -> Refuse-Return-Code NOT-FOUND-404, 2 - REFUSE-603 Account (1)-> Advanced string Direct Call Pickup Code P4705 ->Direct Call Pickup Code Account (1)-> string Group Call Pickup Code P4706 Advanced->Group Call Pickup Code Account (1)-> Advanced Number: 0, 1 Feature Key Sync. 0 - Disable, 1 - Enable P8633 ->...
  • Page 63 Parameter List Account(2)->basic->Use Number:0, 1 User ID Is Phone Number.0 - No, 1 - Yes P763 r ID Is Phone Number Account(2)->basic->SIP Number:0, 1 SIP Registration. 0 - No, 1 - Yes P731 Registration Account(2)->basic-> Number:0, 1 Unregister On Reboot.0 - No, 1 - Yes P752 Unregister On Reboot Account(2)->basic->...
  • Page 64 Parameter List Account(2)->Codec-> Number: 96 iLBC Payload Type (from 96 to 127, default P391 iLBC Payload Type to 127 is 97) Account(2)->Advanced- Number:96-1 P779 DTMF Payload Type，default is 97 > DTMF Payload Type Account (2)-> Advanced Number:0, 1 DTMF IN Audio.0 - no, 1 - yes P860 ->...
  • Page 65 Parameter List Account (2)-> Advanced Number: 0, 1 Anonymous Call Rejection.0 - no, 1 - yes P446 -> Anonymous Call Rejection Account (2)-> Advanced Number: 0, 1 Check SIP User ID.0 - no, 1 - yes P458 -> Check SIP User ID Account (2)->...
  • Page 66 Parameter List Account (2)-> Advanced Number: 0, 1 SIP Server Type. 0 - Default, 1 - BroadSoft P8792 -> SIP Server Type Account (2)-> Advanced Number: 0, 1 100 reliable retransmissions. 0 - Disable, 1 P8812 -> 100 reliable - Enable retransmissions Account (2)->...
  • Page 67 Parameter List Account(3)->basic->Auth String can be identical to or different from SIP P505 enticate ID User ID Account(3)->basic-> String purposely not displayed for P506 Authenticate Password securityprotection Account(3)->basic->Na String The Local phone name showing on the P507 other phone when calling Account(3)->basic->DN Number: 0-2 DNS Mode (0 - A Record, 1 - SRV, 2 -...
  • Page 68 Parameter List listed order PCMA, 9 - G.722, 18 - G.729A/B. Account(3)->Codec-> Number up to 10/20/30/40/50/60 for G711/G726/G P737 Voice Frames Per TX 723/other codecs respectively Account(3)->Codec-> Number:0, 1 G723 Rate (0 - 6.3kbps encoding rate, 1 - P559 G723 Rate 5.3kbps encoding rate) Account(3)->Codec->...
  • Page 69 Parameter List Account (3)-> Advanced Number: 0, 1 Use # As Dial Key.0 - no, 1 - yes P1672 -> Use # As Dial Key Account (3)-> Advanced string Dial plan (dial plan prefix string) P4202 -> Dial Plan Account (3)-> Advanced Number: 0, 1 Subscribe for MWI.0 - no,do not send P515...
  • Page 70 Parameter List -> Hook Flash Timing-> Minimum Account (3)-> Advanced Number Maximum Hook Flash Timing P1812 -> Hook Flash Timing-> Maximum Account (3)-> Advanced Number 100, 100 - Standard, 104 - World Call, 106 - P524 -> Special Feature 104, 106 NETHID Account (3)->...
  • Page 71 Parameter List Account(4)->basic->Bac string Backup Outbound Proxy (This is Usually P20050 kup Outbound Proxy Set as IP address) Account(4)->basic->SIP Number: 0-2 0 - UDP, 1 - TCP, 2 - TLS P1030 Transport Account(4)->basic->NAT Number: 0-2 0 - No, 1 - STUN 2 - No, but send keep P614 Traversal alive...
  • Page 72 Parameter List Account(4)->Codec-> Number: Preferred Vocoder in listed order. choice 3. P653 Preferred Vocoder in 2, 4, 8, 9, 18 0 - PCMU, 2 - G.726-32, 4 - G.723.1, 8 - listed order PCMA, 9 - G.722, 18 - G.729A/B. Account(4)->Codec->...
  • Page 73 Parameter List Account (4)-> Advanced Number 0-2 Jitter Buffer Length.0 - low, 1 - medium, 2 - P1232 -> Jitter Buffer Length high Account (4)-> Advanced Number Account Ring Tone (0 - default, 1 - P623 -> Account Ring Tone 0,1,2,3,4,5,6, Ring1.bin, 2 - Ring2.bin, 3 - Ring3.bin, 4 - Ring4.bin, 5 - Ring5.bin, 6 - Ring6.bin, 7 -...
  • Page 74 Parameter List ->UAC Specify 0 - omit(Recommended) Refresher Account (4)-> Advanced Number: 1, 2 UAS Specify Refresher. 1 - UAC, 2 - UAS P633 -> UAS Specify (When UAC did not) Refresher Account (4)-> Advanced Number: 0, 1 Force INVITE (Always refresh with INVITE P631 ->...
  • Page 75 Parameter List Account(5)->basic->Fail String Failover SIP Server (Optional, used when P20364 over SIP Server primary server no response) Account(5)->basic->Sec String Second Failover SipServer(Optional, used P20366 ond Failover SIP Server when Failover SIP Server no response) Account(5)->basic->Pref Number: 0, 1 Prefer Primary SIP Server (In Use). 0 - No, P20368 er Primary SIP Sserver 1 - Yes...
  • Page 76 Parameter List Account(5)->basic-> Number:0, 1 RPort.0 - No, 1 - Yes P140 RPort Account(5)->basic-> Number:0, 1 RFC 2543 Hold.0 - No, 1 - Yes P1104 RFC 2543 Hold Account(5)->Codec-> Number: Preferred Vocoder in listed order. choice 1. P20392 Preferred Vocoder in 2, 4, 8, 9, 18 0 - PCMU, 2 - G.726-32, 4 - G.723.1, 8 - listed order...
  • Page 77 Parameter List -> Proxy Require Account (5)-> Advanced String Used in SIP/SDP message if specified P20430 ->Use NAT IP Account (5)-> Advanced Number 0-2 SRTP Mode 0 = Disabled, 1 = Enabled but P20432 -> SRTP Mode not forced, 2 = Enabled and forced VAD.0 - no, 1 –...
  • Page 78 Parameter List Account (5)-> Advanced Number Session Expiration (default is 180 P1734 ->Session Expiration seconds) Account (5)-> Advanced Number Min-Session-Expiration (default and P1727 -> Min-SE minimum is 90 seconds) Account (5)-> Advanced Number Caller Request Timer (Request for timer P1728 ->...
  • Page 79 Parameter List Feature Key Sync. 0 - Disable, 1 – Enable. Account (5)-> Advanced Number: 0, 1 P20468 -> Feature Key Sync It defines whether to enable Broad soft, DND&FWD synchronization or not.0 stands for Disabled, 1 stands for Enabled. SIP Send Mac.0 - Disable,1 –...
  • Page 80 Parameter List send by IPphone will contain “user = phone”. Account(6)->basic->SIP Number:0, 1 SIP Registration. 0 - No, 1 - Yes P20385 Registration Account(6)->basic-> Number:0, 1 Unregister On Reboot.0 - No, 1 - Yes P20387 Unregister On Reboot Account(6)->basic-> number Register Expiration (in minutes.
  • Page 81 Parameter List iLBC mode Account(6)->Codec-> Number:96 iLBC Payload Type (from 96 to 127, default P20415 iLBC Payload Type to 127 is 97) Account(6)->Advanced- P20417 ： Number DTMF Payload Type，default is 97 > DTMF Payload Type 96-127 Account (6)-> Advanced Number:0, 1 DTMF IN Audio.0 - no, 1 - yes P20419 ->...
  • Page 82 Parameter List SUBBSCRIBE for ,Message Waiting indication Send Anonymous,0 – no,1 – yes Account (6)-> Advanced Number: 0, 1 P1821 -> Send Anonymous Account (6)-> Advanced Number: 0, 1 Anonymous Call Rejection.0 - no, 1 - yes P20447 -> Anonymous Call Rejection Account (6)->...
  • Page 83 Parameter List Account (6)-> Advanced Number: 0-2 Share Line. 0 - Disable, 1 - Broadsoft, 2 - P20455 -> Share Line Account (6)-> Advanced Number: 0, 1 SIP Server Type. 0 - Default, 1 - BroadSoft P20457 -> SIP Server Type Account (6)->...
  • Page 84 Parameter List >Static IP Address-> 15/P16 Subnet Mask Network->Basic->WAN- Number Default Gateway P17/P18/P >Static IP Address-> 19/P20 Default Gateway Network->Basic->WAN- Number Primary DNS P21/P22/P >Static IP Address-> 23/P24 Primary DNS Network->Basic->WAN- Number Secondary DNS P25/P26/P >Static IP Address-> 27/P28 Secondary DNS Network->Basic->WAN- String PPPoE account ID...
  • Page 85 Parameter List Port->Port Map-> LAN IP Network->Basic->PC Numbrt LAN Port P166-P173 Port->Port Map-> LAN Port Network->Basic->PC Number:0-2 Protocol (0 - UDP, 1 - TCP ,2 - TCP/UDP) P174-P181 Port->Port Map-> Protocol Network->Advanced->LL Number:0 ,1 Active (0 - Disable, 1 - Enable) P5438 DP->active Network->Advanced->LL...
  • Page 86 Parameter List Local RTP Port-> Min Rtp Port Network->Advanced->Ot String STUN Server (url or ip:port) hers-> STUN Server Network->Advanced->Ot Number Keep-ative Interval (seconds default:20) hers-> Keep-active Interval Function Keys-> Line Number: Key Type(0 -N/A, 1 - Line, 2 - Speed dial, P41200 Key->...
  • Page 87 Parameter List Desking, 33 - ACD, 34 - Zero Touch,47 - MultiCast Paging) Function Keys-> Line string Value P41301 Key-> Line key 2-> Value Function Keys-> Line String Label P41401 Key-> Line key 2-> Label Function Keys-> Line Number:0,1, 255 - Auto, 0 - Account 1, 1 - Account 2, 2 - P41501 Key->...
  • Page 88 Parameter List 26 - URL Record, 27 – Paging, 28 - Group Listening, 29 - Public Hold, 30 - Private Hold, 31 - Shine Line, 32 - Hot Desking, 33 - ACD, 34 - Zero Touch,47 - MultiCast Paging) Function Keys-> Line string Value P41303...
  • Page 89 Parameter List Transfer, 20 – Hold, 21 - DND, 22 - Redial, 23 - Call Return, 24 – SMS, 25 - Record, 26 - URL Record, 27 – Paging, 28 - Group Listening, 29 - Public Hold, 30 - Private Hold, 31 - Shine Line, 32 - Hot Desking, 33 - ACD, 34 - Zero Touch,47 - MultiCast Paging) Function Keys->...
  • Page 90 Parameter List Group, 17 - Conference, 18 - Forward, 19 - Transfer, 20 – Hold, 21 - DND, 22 - Redial, 23 - Call Return, 24 – SMS, 25 - Record, 26 - URL Record, 27 – Paging, 28 - Group Listening, 29 - Public Hold, 30 - Private Hold, 31 - Shine Line, 32 - Hot Desking, 33 - ACD, 34 - Zero Touch,47 -...
  • Page 91 Parameter List XML Browser, 15 - LDAP, 16 - BroadSoft Group, 17 - Conference, 18 - Forward, 19 - Transfer, 20 – Hold, 21 - DND, 22 - Redial, 23 - Call Return, 24 – SMS, 25 - Record, 26 - URL Record, 27 – Paging, 28 - Group Listening, 29 - Public Hold, 30 - Private Hold, 31 - Shine Line, 32 - Hot Desking, 33 - ACD, 34 - Zero Touch,47 -...
  • Page 92 Parameter List Key-> Line key 11->Exten Function Keys-> Line Number: Key Type(0 -N/A, 1 - Line, 2 - Speeddial, P20235 Key-> Line key 12->Type 0-47 3 - BLF, 4 - BLF List, 5 - Voicemail, 6 - Direct Pickup, 7 - Group Pickup, 8 - Call Park, 9 - Intercom, 10 - DTMF, 11 - Frefix, 12 - Local Group, 13 - XML Group, 14 - XML Browser, 15 - LDAP, 16 - BroadSoft...
  • Page 93 Parameter List Function Keys-> Line String Label P20242 Key-> Line key 13-> Label Function Keys-> Line Number:0,1, 255 - Auto, 0 - Account 1, 1 - Account 2, 2 - P20243 Key-> Line key 13-> 2,3,255 Account 3, 3 - Account 4 Account Function Keys->...
  • Page 94 Parameter List Group Listening, 29 - Public Hold, 30 - Private Hold, 31 - Shine Line, 32 - Hot Desking, 33 - ACD, 34 - Zero Touch,47 - MultiCast Paging) Function Keys-> Line string Value P20251 Key-> Line key 15-> Value Function Keys->...
  • Page 95 Parameter List Park, 9 - Intercom, 10 - DTMF, 11 - Frefix, 12 - Local Group, 13 - XML Group, 14 - XML Browser, 15 - LDAP, 16 - BroadSoft Group, 17 - Conference, 18 - Forward, 19 - Transfer, 20 – Hold, 21 - DND, 22 - Redial, 23 - Call Return, 24 –...
  • Page 96 Parameter List Account Function Keys-> Line Sting Pickup Code P20269 Key-> Line key 18->Exten Function Keys-> Line Number: Key Type(0 -N/A, 1 - Line, 2 - Speeddial, P20270 Key-> Line key 19->Type 0-47 3 - BLF, 4 - BLF List, 5 - Voicemail, 6 - Direct Pickup, 7 - Group Pickup, 8 - Call Park, 9 - Intercom, 10 - DTMF, 11 - Frefix, 12 - Local Group, 13 - XML Group, 14 -...
  • Page 97 Parameter List Key-> Line key 20-> Value Function Keys-> Line String Label P20277 Key-> Line key 20-> Label Function Keys-> Line Number:0,1, 255 - Auto, 0 - Account 1, 1 - Account 2, 2 - P20278 Key-> Line key 20-> 2,3,255 Account 3, 3 - Account 4 Account...
  • Page 98 Parameter List 23 - Call Return, 24 – SMS, 25 - Record, 26 - URL Record, 27 – Paging, 28 - Group Listening, 29 - Public Hold, 30 - Private Hold, 31 - Shine Line, 32 - Hot Desking, 33 - ACD, 34 - Zero Touch,47 - MultiCast Paging) Function Keys->...
  • Page 99 Parameter List Key-> Line key 24->Type 0-47 3 - BLF, 4 - BLF List, 5 - Voicemail, 6 - Direct Pickup, 7 - Group Pickup, 8 - Call Park, 9 - Intercom, 10 - DTMF, 11 - Frefix, 12 - Local Group, 13 - XML Group, 14 - XML Browser, 15 - LDAP, 16 - BroadSoft Group, 17 - Conference, 18 - Forward, 19 - Transfer, 20 –...
  • Page 100 Parameter List Function Keys-> Line Number:0,1, 255 - Auto, 0 - Account 1, 1 - Account 2, 2 - P20303 Key-> Line key 25-> 2,3,255 Account 3, 3 - Account 4 Account Function Keys-> Line Sting Pickup Code P20304 Key-> Line key 25->Exten Function Keys->Line Number:...
  • Page 101 Parameter List MultiCast Paging) Function Keys-> Line string Value P20311 Key-> Line key 27-> Value Function Keys-> Line String Label P20312 Key-> Line key 27-> Label Function Keys-> Line Number:0,1, 255 - Auto, 0 - Account 1, 1 - Account 2, 2 - P20313 Key->...
  • Page 102 Parameter List Group, 17 - Conference, 18 - Forward, 19 - Transfer, 20 – Hold, 21 - DND, 22 - Redial, 23 - Call Return, 24 – SMS, 25 - Record, 26 - URL Record, 27 – Paging, 28 - Group Listening, 29 - Public Hold, 30 - Private Hold, 31 - Shine Line, 32 - Hot Desking, 33 - ACD, 34 - Zero Touch,47 -...
  • Page 103 Parameter List 30->Exten Function Keys-> Line Number: Key Type(0 -N/A, 1 - Line, 2 - Speeddial, P20330 Key-> Line key 31->Type 0-47 3 - BLF, 4 - BLF List, 5 - Voicemail, 6 - Direct Pickup, 7 - Group Pickup, 8 - Call Park, 9 - Intercom, 10 - DTMF, 11 - Frefix, 12 - Local Group, 13 - XML Group, 14 - XML Browser, 15 - LDAP, 16 - BroadSoft...
  • Page 104 Parameter List Key-> Line key 32-> Label Function Keys-> Line Number:0,1, 255 - Auto, 0 - Account 1, 1 - Account 2, 2 - P20338 Key-> Line key 32-> 2,3,255 Account 3, 3 - Account 4 Account Function Keys-> Line Sting Pickup Code P20339...
  • Page 105 Parameter List Private Hold, 31 - Shine Line, 32 - Hot Desking, 33 - ACD, 34 - Zero Touch,47 - MultiCast Paging) Function Keys-> Line string Value P20346 Key-> Line key 34-> Value Function Keys-> Line String Label P20347 Key-> Line key 34-> Label Function Keys->...
  • Page 106 Parameter List 12 - Local Group, 13 - XML Group, 14 - XML Browser, 15 - LDAP, 16 - BroadSoft Group, 17 - Conference, 18 - Forward, 19 - Transfer, 20 – Hold, 21 - DND, 22 - Redial, 23 - Call Return, 24 – SMS, 25 - Record, 26 - URL Record, 27 –...
  • Page 107 Parameter List Function Keys-> Memory Number: Key Type(0 -N/A, 1 - Line, 2 - Speeddial, P42201 Key -> Memory key 0-47 3 - BLF, 4 - BLF List, 5 - Voicemail, 6 - 2->Type Direct Pickup, 7 - Group Pickup, 8 - Call Park, 9 - Intercom, 10 - DTMF, 11 - Frefix, 12 - Local Group, 13 - XML Group, 14 - XML Browser, 15 - LDAP, 16 - BroadSoft...
  • Page 108 Parameter List Pickup Code Function Keys-> Memory Number: Key Type(0 -N/A, 1 - Line, 2 - Speeddial, P42203 Key -> Memory key 0-47 3 - BLF, 4 - BLF List, 5 - Voicemail, 6 - 4->Type Direct Pickup, 7 - Group Pickup, 8 - Call Park, 9 - Intercom, 10 - DTMF, 11 - Frefix, 12 - Local Group, 13 - XML Group, 14 - XML Browser, 15 - LDAP, 16 - BroadSoft...
  • Page 109 Parameter List Key -> Memory key 5-> Pickup Code Function Keys-> Memory Number: Key Type(0 -N/A, 1 - Line, 2 - Speeddial, P42205 Key -> Memory key 0-47 3 - BLF, 4 - BLF List, 5 - Voicemail, 6 - 6->Type Direct Pickup, 7 - Group Pickup, 8 - Call Park, 9 - Intercom, 10 - DTMF, 11 - Frefix,...
  • Page 110 Parameter List Function Keys-> Memory Sting Pickup Code P42506 Key -> Memory key 7-> Pickup Code Function Keys->Memory Number: Key Type(0 -N/A, 1 - Line, 2 - Speeddial, P42207 Key -> Memory key 0-47 3 - BLF, 4 - BLF List, 5 - Voicemail, 6 - 8->Type Direct Pickup, 7 - Group Pickup, 8 - Call Park, 9 - Intercom, 10 - DTMF, 11 - Frefix,...
  • Page 111 Parameter List Account Function Keys-> Memory Sting Pickup Code P42508 Key -> Memory key 9->Pickup Code Function Keys-> Memory Number: Key Type(0 -N/A, 1 - Line, 2 - Speeddial, P42209 Key -> Memory key 0-47 3 - BLF, 4 - BLF List, 5 - Voicemail, 6 - 10->Type Direct Pickup, 7 - Group Pickup, 8 - Call Park, 9 - Intercom, 10 - DTMF, 11 - Frefix,...
  • Page 112 Parameter List Programmable key-> 6,7,9,12,13,1 Pickup,7 - Group Pickup, 9 - Intercom, 12 - softkey2->Type 4,16,18,21,2 Local Group, 13 - XML Group,14 - XML 2,23,24,36,3 Browser, 16 - BroadSoft Group, 18 - Forward, 21 – DND, 22 - Redial, 23 - Call 7,38,39,40,4 1,42,43,44,4 Return, 24 - SMS,36 - History, 37 -...
  • Page 113 Parameter List Programmable key-> 2,3,255 Account 3, 3 - Account 4 softkey4-> Account Function Keys-> String Value P43403 Programmable key-> softkey4-> Value Function Keys-> Number:0,2, Type (0 - N/A, 2 - Speed Dial, 6 - Direct P43204 Programmable 6,7,9,12,13,1 Pickup,7 - Group Pickup, 9 - Intercom, 12 - key->Up->Type 4,16,18,21,2 Local Group, 13 - XML Group,14 - XML...
  • Page 114 Parameter List 5,46 Directory, 38 - Menu, 39 - NewSMS, 40 - Status, 41 - Switch Account Up, 42 - Switch Account Down, 43 - Local Phone Book, 44 - BroadSoft Phone Book, 45 - XML Phone Book, 46 - NetWork Call Log) Function Keys->...
  • Page 115 Parameter List Function Keys-> Number:0,2, Type (0 - N/A, 2 - Speed Dial, 6 - Direct P43209 Programmable key-> 6,7,9,12,13,1 Pickup,7 - Group Pickup, 9 - Intercom, 12 - Cancel->Type 4,16,18,21,2 Local Group, 13 - XML Group,14 - XML 2,23,24,36,3 Browser, 16 - BroadSoft Group, 18 - Forward, 21 –...
  • Page 116 Parameter List Function Keys-> Number:0,1, 255 - Auto, 0 - Account 1, 1 - Account 2, 2 - P43310 Programmable key-> 2,3,255 Account 3, 3 - Account 4 CONF-> Account Function Keys-> String Value P43410 Programmable key-> CONF-> Value Function Keys-> Number:0,2, Type (0 - N/A, 2 - Speed Dial, 6 - Direct P43213...
  • Page 117 Parameter List XML Browser, 15 - LDAP, 16 - BroadSoft Group, 17 - Conference, 18 - Forward, 19 - Transfer, 20 – Hold, 21 - DND, 22 - Redial, 23 - Call Return, 24 – SMS, 25 - Record, 26 - URL Record, 27 – Paging, 28 - Group Listening, 29 - Public Hold, 30 - Private Hold, 31 - Shine Line, 32 - Hot Desking, 33 - ACD, 34 - Zero Touch,47 -...
  • Page 118 Parameter List Account Function Keys->EXP Sting Pickup Code P60010 KEY ->Expansion1 -> page1 ->key 2-> Pickup Code Function Keys->EXP Number: Key Type(0 -N/A, 1 - Line, 2 - Speeddial, P60011 KEY ->Expansion1 -> 0-47 3 - BLF, 4 - BLF List, 5 - Voicemail, 6 - page1 ->key 3 ->Type Direct Pickup, 7 - Group Pickup, 8 - Call Park, 9 - Intercom, 10 - DTMF, 11 - Frefix,...
  • Page 119 Parameter List Desking, 33 - ACD, 34 - Zero Touch,47 - MultiCast Paging) Function Keys->EXP string Value P60017 KEY ->Expansion1 -> page1 ->key 4 -> Value Function Keys->EXP string Label P60018 KEY ->Expansion1 -> page1 ->key 4 ->Label Function Keys->EXP Number:0,1, 255 - Auto, 0 - Account 1, 1 - Account 2, 2 - P60019...
  • Page 120 Parameter List Function Keys->EXP Number: Key Type(0 -N/A, 1 - Line, 2 - Speeddial, P60026 KEY ->Expansion1 -> 0-47 3 - BLF, 4 - BLF List, 5 - Voicemail, 6 - page1 ->key 6 ->Type Direct Pickup, 7 - Group Pickup, 8 - Call Park, 9 - Intercom, 10 - DTMF, 11 - Frefix, 12 - Local Group, 13 - XML Group, 14 - XML Browser, 15 - LDAP, 16 - BroadSoft...
  • Page 121 Parameter List Function Keys->EXP string Label P60033 KEY ->Expansion1 -> page1 ->key 7 ->Label Function Keys->EXP Number:0,1, 255 - Auto, 0 - Account 1, 1 - Account 2, 2 - P60034 KEY ->Expansion1 -> 2,3,255 Account 3, 3 - Account 4 page1 ->key 7 ->...
  • Page 122 Parameter List Group, 17 - Conference, 18 - Forward, 19 - Transfer, 20 – Hold, 21 - DND, 22 - Redial, 23 - Call Return, 24 – SMS, 25 - Record, 26 - URL Record, 27 – Paging, 28 - Group Listening, 29 - Public Hold, 30 - Private Hold, 31 - Shine Line, 32 - Hot Desking, 33 - ACD, 34 - Zero Touch,47 -...
  • Page 123 Parameter List page1 ->key 10 -> Account Function Keys->EXP Sting Pickup Code P60050 KEY ->Expansion1 -> page1 ->key 10-> Pickup Code Function Keys->EXP Number: Key Type(0 -N/A, 1 - Line, 2 - Speeddial, P60051 KEY ->Expansion1 -> 0-47 3 - BLF, 4 - BLF List, 5 - Voicemail, 6 - page1 ->key 11->Type Direct Pickup, 7 - Group Pickup, 8 - Call Park, 9 - Intercom, 10 - DTMF, 11 - Frefix,...
  • Page 124 Parameter List Private Hold, 31 - Shine Line, 32 - Hot Desking, 33 - ACD, 34 - Zero Touch,47 - MultiCast Paging) Function Keys->EXP string Value P60057 KEY ->Expansion1 -> page1 ->key 12 -> Value Function Keys->EXP string Label P60058 KEY ->Expansion1 ->...
  • Page 125 Parameter List Function Keys->EXP Number: Key Type(0 -N/A, 1 - Line, 2 - Speeddial, P60066 KEY ->Expansion1 0-47 3 - BLF, 4 - BLF List, 5 - Voicemail, 6 - -> page1 ->key Direct Pickup, 7 - Group Pickup, 8 - Call 14->Type Park, 9 - Intercom, 10 - DTMF, 11 - Frefix, 12 - Local Group, 13 - XML Group, 14 -...
  • Page 126 Parameter List KEY ->Expansion1 -> page1 ->key 15 -> Value Function Keys->EXP string Label P60073 KEY ->Expansion1 -> page1 ->key 15 ->Label Function Keys->EXP Number:0,1, 255 - Auto, 0 - Account 1, 1 - Account 2, 2 - P60074 KEY ->Expansion1 ->...
  • Page 127 Parameter List 12 - Local Group, 13 - XML Group, 14 - XML Browser, 15 - LDAP, 16 - BroadSoft Group, 17 - Conference, 18 - Forward, 19 - Transfer, 20 – Hold, 21 - DND, 22 - Redial, 23 - Call Return, 24 – SMS, 25 - Record, 26 - URL Record, 27 –...
  • Page 128 Parameter List KEY ->Expansion1 -> 2,3,255 Account 3, 3 - Account 4 page1 ->key 18 -> Account Function Keys->EXP Sting Pickup Code P60090 KEY ->Expansion1 -> page1 ->key 18-> Pickup Code Function Keys->EXP Number: Key Type(0 -N/A, 1 - Line, 2 - Speeddial, P60091 KEY ->Expansion1 0-47...
  • Page 129 Parameter List Group Listening, 29 - Public Hold, 30 - Private Hold, 31 - Shine Line, 32 - Hot Desking, 33 - ACD, 34 - Zero Touch,47 - MultiCast Paging) Function Keys->EXP string Value P60097 KEY ->Expansion1 -> page1 ->key 20 -> Value Function Keys->EXP string Label...
  • Page 130 Parameter List Code Function Keys->EXP Number: Key Type(0 -N/A, 1 - Line, 2 - Speeddial, P60106 KEY ->Expansion1 -> 0-47 3 - BLF, 4 - BLF List, 5 - Voicemail, 6 - page2 ->key 2 ->Type Direct Pickup, 7 - Group Pickup, 8 - Call Park, 9 - Intercom, 10 - DTMF, 11 - Frefix, 12 - Local Group, 13 - XML Group, 14 - XML Browser, 15 - LDAP, 16 - BroadSoft...
  • Page 131 Parameter List page2 ->key 3 -> Value Function Keys->EXP string Label P60113 KEY ->Expansion1 -> page2 ->key 3 ->Label Function Keys->EXP Number:0,1, 255 - Auto, 0 - Account 1, 1 - Account 2, 2 - P60114 KEY ->Expansion1 -> 2,3,255 Account 3, 3 - Account 4 page2 ->key 3 ->...
  • Page 132 Parameter List XML Browser, 15 - LDAP, 16 - BroadSoft Group, 17 - Conference, 18 - Forward, 19 - Transfer, 20 – Hold, 21 - DND, 22 - Redial, 23 - Call Return, 24 – SMS, 25 - Record, 26 - URL Record, 27 – Paging, 28 - Group Listening, 29 - Public Hold, 30 - Private Hold, 31 - Shine Line, 32 - Hot Desking, 33 - ACD, 34 - Zero Touch,47 -...
  • Page 133 Parameter List KEY ->Expansion1 -> 2,3,255 Account 3, 3 - Account 4 page2 ->key 6 -> Account Function Keys->EXP Sting Pickup Code P60130 KEY ->Expansion1 -> page2 ->key 6-> Pickup Code Function Keys->EXP Number: Key Type(0 -N/A, 1 - Line, 2 - Speeddial, P60131 KEY ->Expansion1 ->...
  • Page 134 Parameter List Group Listening, 29 - Public Hold, 30 - Private Hold, 31 - Shine Line, 32 - Hot Desking, 33 - ACD, 34 - Zero Touch,47 - MultiCast Paging) Function Keys->EXP string Value P60137 KEY ->Expansion1 -> page2 ->key 8 -> Value Function Keys->EXP string Label...
  • Page 135 Parameter List Code Function Keys->EXP Number: Key Type(0 -N/A, 1 - Line, 2 - Speeddial, P60146 KEY ->Expansion1 -> 0-47 3 - BLF, 4 - BLF List, 5 - Voicemail, 6 - page2 ->key 10->Type Direct Pickup, 7 - Group Pickup, 8 - Call Park, 9 - Intercom, 10 - DTMF, 11 - Frefix, 12 - Local Group, 13 - XML Group, 14 - XML Browser, 15 - LDAP, 16 - BroadSoft...
  • Page 136 Parameter List page2 ->key 11 -> Value Function Keys->EXP string Label P60153 KEY ->Expansion1 -> page2 ->key 11 ->Label Function Keys->EXP Number:0,1, 255 - Auto, 0 - Account 1, 1 - Account 2, 2 - P60154 KEY ->Expansion1 -> 2,3,255 Account 3, 3 - Account 4 page2 ->key 11 ->...
  • Page 137 Parameter List XML Browser, 15 - LDAP, 16 - BroadSoft Group, 17 - Conference, 18 - Forward, 19 - Transfer, 20 – Hold, 21 - DND, 22 - Redial, 23 - Call Return, 24 – SMS, 25 - Record, 26 - URL Record, 27 – Paging, 28 - Group Listening, 29 - Public Hold, 30 - Private Hold, 31 - Shine Line, 32 - Hot Desking, 33 - ACD, 34 - Zero Touch,47 -...
  • Page 138 Parameter List KEY ->Expansion1 -> 2,3,255 Account 3, 3 - Account 4 page2 ->key 14 -> Account Function Keys->EXP Sting Pickup Code P60170 KEY ->Expansion1 -> page2 ->key 14-> Pickup Code Function Keys->EXP Number: Key Type(0 -N/A, 1 - Line, 2 - Speeddial, P60171 KEY ->Expansion1 ->...
  • Page 139 Parameter List Group Listening, 29 - Public Hold, 30 - Private Hold, 31 - Shine Line, 32 - Hot Desking, 33 - ACD, 34 - Zero Touch,47 - MultiCast Paging) Function Keys->EXP string Value P60177 KEY ->Expansion1 -> page2 ->key 16 -> Value Function Keys->EXP string Label...
  • Page 140 Parameter List Code Function Keys->EXP Number: Key Type(0 -N/A, 1 - Line, 2 - Speeddial, P60186 KEY ->Expansion1 -> 0-47 3 - BLF, 4 - BLF List, 5 - Voicemail, 6 - page2 ->key 18->Type Direct Pickup, 7 - Group Pickup, 8 - Call Park, 9 - Intercom, 10 - DTMF, 11 - Frefix, 12 - Local Group, 13 - XML Group, 14 - XML Browser, 15 - LDAP, 16 - BroadSoft...
  • Page 141 Parameter List page2 ->key 19 -> Value Function Keys->EXP string Label P60193 KEY ->Expansion1 -> page2 ->key 19 ->Label Function Keys->EXP Number:0,1, 255 - Auto, 0 - Account 1, 1 - Account 2, 2 - P60194 KEY ->Expansion1 -> 2,3,255 Account 3, 3 - Account 4 page2 ->key 19 ->...
  • Page 142 Parameter List Expansion4 P60601 – P60800 Expansion5 P60801 – P61000 Setting->Preference-> Number:0-10 Web Language (0 -English,1 -French,2 P2525 Web Language -German,3 -Spanish,4 -Portuguese,5 -Russian,6 -Italian,7-Polish,8-Turkish, 9 -ChineseSimplified,10 -ChineseTraditional) Setting->LCD Language Number:0-16 Web Language (0 -English,1 -French,2 P8621 -German,3 -Spanish,4 -Portuguese,5 -Russian,6 -Italian,7-Polish,8-Turkish, 9-Serbian,10--ChineseSimplified, 11–ChineseTraditional,12-Slovenian,13-Fa...
  • Page 143 Parameter List Setting->Preference-> Number:0,1 LED Status. MissCalls Status.0 - no, 1 - P3736 LED Status Setting ->MissCalls Status Setting->Preference-> Number:0,1 Incoming Call Show Mode (0 - Peer Name P8672 Incoming Call Show & Peer Number,1 - Peer Name & Peer Mode Number &...
  • Page 144 Parameter List Setting->Feature->Forw Number:0,1 Busy Always Forward (1 - on, 0 - off) P53110 ard-> Busy Setting->Feature->Forw String Target (Target number for transfer) P53111 ard-> Busy -> Target Setting->Feature->Forw String On Code P53112 ard-> Busy -> On Code Setting->Feature->Forw String Off Code P53113 ard->...
  • Page 145 Parameter List Setting->Feature-> Number:0,1, Transfer Mode via DSSkey(0 - Attended P3205 Transfer Settings-> Transfer, 1 - Blind Transfer, 2 - New Call) Transfer Mode via DSSkey Setting->Feature-> Number:0,1 Hold Transfer On Hook (1 - On,0 - Off) P3207 Transfer Settings-> Hold Transfer On Hook Setting->Feature->Call Number:0,1...
  • Page 146 Parameter List Ring-> Alert Ring File 1 2 - Ring 2.bin, 3 - Ring 3.bin, 4 - Ring 4.bin, 5 - Ring 5.bin, 6 - Ring 6.bin, 7 - Ring 7.bin, 8 - Ring 8.bin,) Setting->Feature-> Alert String Alert Ring Text 2 P1400 Ring->...
  • Page 147 Parameter List Setting->Feature-> Alert String Alert Ring Text 9 P20064 Ring-> Alert Ring Text 9 Setting->Feature-> Alert Number:0-8 Alert Ring File 9(0 - Default, 1 - Ring 1.bin, P20071 Ring-> Alert Ring File 9 2 - Ring 2.bin, 3 - Ring 3.bin, 4 - Ring 4.bin, 5 - Ring 5.bin, 6 - Ring 6.bin, 7 - Ring 7.bin, 8 - Ring 8.bin,) Setting->Feature->Alert...
  • Page 148 Parameter List Tones-> Confirmation Syntax: f1=freq@vol, f2=freq@vol, Tone c=on1/off1‐on2/off2‐on3/off3 freq: FREQUENCY in Hz on1/off1‐on2/off2 :cadence in Millisecond Setting->Feature-> String Call Waiting Tone P4005 Tones-> Call Waiting Syntax: f1=freq@vol, f2=freq@vol, Tone c=on1/off1‐on2/off2‐on3/off3 freq: FREQUENCY in Hz on1/off1‐on2/off2 :cadence in Millisecond Setting->Feature-> Number:0-3 SMS (Account.0 - Account 1, 1 - Account P58100...
  • Page 149 Parameter List n URL-> Open Busy sent out when busy-forward is enabled.) Forward Setting->Feature->Actio String Close Busy Forward (This message will be P3716 n URL-> Close Busy sent out when busy-forward is disabled.) Forward Setting->Feature->Actio String Open No Busy Forward (This message will P3717 n URL->...
  • Page 150 Parameter List n URL-> TransferFinished Setting->Feature->Actio String Transfe Failed (Transfer Failed) P3733 n URL-> Transfe Failed Setting->Date&Time-> Number:0,1 DHCP Time (0 - no, 1 - yes) P143 DHCP Time Setting->Date&Time-> Number Time Zone Time Zone #105 - -11 Samoa, 1 - -10 United States-Hawaii-Aleutian # 2 - -10 United States-Alaska-Aleutian, 3 - -9 United States-Alaska Time...
  • Page 151 Parameter List Palmas), 39 - 0 United Kingdom(London) # 40 - 0 Morocco, 41 - +1 Albania(Tirane),42 - +1 Austria(Vienna) # 43 - +1 Belgium(Brussels), 44 - +1 Caicos, 45 - +1 Chatam # 46 - +1 Croatia(Zagreb), 47 - +1 Czech Republic(Prague) # 48 - +1 Denmark(Kopenhaven), 49 - +1 France(Paris), 50 - +1 Germany(Berlin)
  • Page 152 Parameter List # 93 - +9 Japan(Tokyo), 94 - +9:30 Australia(Adelaide), 95 - +9:30 Australia(Darwin) # 96 - +10 Australia(Sydney,Melbourne,Canberra), 97 - +10 Australia(Brisbane) # 98 - +10 Australia(Hobart), 99 - +10 Russia(Vladivostok), 100 - +10:30 Australia(Lord Howe Islands) # 101 - +11 New Caledonia(Noumea), 102 - +12 New Zeland(Wellington,Auckland) # 103 - +12:45 New Zeland(Chatham Islands), 104 - +13 Tonga(Nukualofa)
  • Page 153 Parameter List PhoneBook->index 3-> Name Directory-> Remote String Phone Book URL P4404 PhoneBook->index 4-> Phone Book URL Directory-> Remote String Name P3314 PhoneBook->index 4-> Name Directory-> Remote String Phone Book URL P4405 PhoneBook->index 5-> Phone Book URL Directory-> Remote String Name P3315 PhoneBook->index 5->...
  • Page 154 Parameter List Display Name Directory->Broad Soft-> String BroadSoft Server P8521 Server Directory->Broad Soft-> Number BroadSoft server port number P8522 Server Directory->Broad Soft-> String BroadSoft server User name P8523 User Directory->Broad Soft-> String BroadSoft Server Password P8524 Password Directory->Calllog-> Number:0-5 Calllog Item (0 -Calllog 1,1 - Calllog 2,2 P8579 Calllog Item -Calllog 3,3 -Calllog 4,4 -Calllog 5,5...
  • Page 155 Parameter List Directory->MultiCast String Listening Address P20027 Paging->IP Address 4> Listening Address Directory->MultiCast Stirng Lable P20028 Paging-> IP Address 4> Lable Directory->MultiCast String Listening Address P20029 Paging->IP Address 5> Listening Address Directory->MultiCast Stirng Lable P20030 Paging-> IP Address 5> Lable Directory->MultiCast String Listening Address...
  • Page 156 Parameter List Management -> String Firmware Server Path P192 Auto Provision-> FirmwareUpgrade-> Firmware Server Path Management -> String Config Server Path P237 Auto Provision->Firmware Upgrade-> Config Server Path Management -> Number Allow DHCP Option P1145 Auto Provision->Firmware Upgrade-> Allow DHCP Option To Oerride Server (0 –...
  • Page 157 Parameter List Provision->Firmware Upgrade-> Set Common AES Key Management ->Auto Number:0,1 Self as Server (0 - No,1- Yes) P40001 Provision->Firmware Upgrade-> Self as Server Management ->Auto String Exp Upgrade Server P40002 Provision->Firmware Upgrade-> Exp Upgrade Server Management ->Auto String Phonebook XML Server Path P331 Provision->Phonebook XML Download->...
  • Page 158 Parameter List Community Management String SNMP Manager IP 1 P8153 Management->Auto Provision-> SNMP Service -> SNMP Manager IP 1 Management String SNMP Manager IP 2 P8154 Management->Auto Provision-> SNMP Service -> SNMP Manager IP 2 Management String SNMP Manager IP 3 P8155 Management->Auto Provision->...

This manual is also suitable for:

Uc803pUc804Uc802pUc803Uc804pUc806 ... Show all

Table of Contents
