Digital Camera

User's Guide
This manual covers the firmware versions below.
Camera: Ver. 2.01 Controller: Ver. 2.00
Thank you for purchasing this CASIO product.
• Before using it, be sure to read the precautions contained in this User's Guide.
• Keep the User's Guide in a safe place for future reference.
• For the most up-to-date information about this product, visit the official EXILIM Website
at http://www.exilim.com/
EN

Advertisement

Table of Contents
loading

Related Manuals for Casio EX-FR100

Summary of Contents for Casio EX-FR100

  • Page 1: Digital Camera

    This manual covers the firmware versions below. Camera: Ver. 2.01 Controller: Ver. 2.00 Thank you for purchasing this CASIO product. • Before using it, be sure to read the precautions contained in this User’s Guide. • Keep the User’s Guide in a safe place for future reference.

  • Page 2: Accessories

    As you unpack your camera, check to make sure that all accessories shown below are included. If anything is missing, contact your original retailer. Hinge Unit Camera Controller • Comes pre-attached to (EX-FR100) (EX-FR100CT) the camera. USB-AC adaptor Tripod nut Carabiner strap...

  • Page 3: Read This First

    CASIO COMPUTER CO., LTD. is forbidden under copyright laws. • CASIO COMPUTER CO., LTD. shall not be held liable for any damages or lost profits suffered by you or any third party due to the use or malfunction of this product.

  • Page 4: Table Of Contents

    Quick Start Basics What you can do with your CASIO camera ......12 Using the Attachment ......... . . 15 Controller .
  • Page 5  Advanced Recording Settings Using the REC Menu ..........52 Recording Beautiful Portraits .
  • Page 6 Configuring Wireless Connection Settings ......82 Having Images Shot with the Camera Sent  to a Smartphone Automatically .
  • Page 7 Formatting Built-in Memory or a Memory Card ....(Format) . 115 Resetting the Camera to Factory Defaults ....(Reset) . 115 Checking the Current Camera Firmware Version .

  • Page 8: General Guide

    General Guide The numbers in parentheses indicate the pages where each item is explained. Camera Controller bk bl bm cmcnco cp Camera [FREE] lever (page 16) Carabiner strap   [USB] port attachment bar  Wireless LAN connection  (pages 20, 23) (page 18) lamp (page 77) [USB] cover...

  • Page 9: Monitor Screen Contents And How To Change Them

    Monitor Screen Contents and How to Change Them The monitor screen uses various indicators, icons, and values to keep you informed of the camera’s status. • The sample screens in this section are intended to show you the locations of all the indicators and figures that can appear on the monitor screen in various modes.
  • Page 10 . Movie Recording Focus mode (page 59)  Movie quality (pages 49, 56)  Movie recording time (page 50)  NOTE • If you do not perform any operation for about three seconds during snapshot recording or movie recording, icons will become transparent. .

  • Page 11: Movie Playback

    NOTE • The folder name and file name in the upper right corner of the monitor screen has the meaning described below (page 108). Example: 100-0023: 23rd image file in the folder named “100CASIO”. . Movie Playback Movie recording time (page 62) ...

  • Page 12: Quick Start Basics

    Quick Start Basics What you can do with your CASIO camera Your CASIO camera is packed with a powerful selection of features and functions to make recording of digital images easier, including the following main functions. . Shooting A variety of shooting styles The camera connects to the controller using Bluetooth ®...
  • Page 13 . Viewing Highlight Photo You can configure camera settings to automatically select snapshot highlights and generate a collage of them. *See page for more information. Highlight Movie You can configure camera settings to automatically select snapshot and movie highlights, and create a movie of them.
  • Page 14 . Simultaneous Use of Two Cameras Multi Camera Mode You can register two cameras on the controller and operate them both at the same time or individually. *See page for more information. Quick Start Basics...

  • Page 15: Using The Attachment

    Using the Attachment You can configure the camera to suit your specific needs by attaching the hinge unit, which enables attachment of the controller, and other included and optionally available attachments. This way you can configure the camera to suit your specific needs.

  • Page 16: Hinge Unit

    Hinge Unit . To use the hinge unit as a stand . To change the shooting direction by 90 degrees While pulling down on the camera’s [FREE] [FREE] lever lever, rotate the camera clockwise 90 degrees until you hear a click. •...

  • Page 17: Tripod Nut

    Remove the hinge unit from the camera. . To attach the hinge unit to the camera Align the camera’s operation lamp with the A mark on the hinge unit. Rotate the camera clockwise about 15 degrees until its operation lamp is aligned with the B mark on the hinge unit.

  • Page 18: Carabiner Strap

    Carabiner Strap Pass the carabiner strap belt around the controller’s carabiner strap attachment bar. Pass the belt through the buckle to flap secure it. Pull on the belt until the belt flap is passed all the way through the buckle. Hook the flap on the buckle.

  • Page 19: Using The Touch Panel

    Using the Touch Panel The monitor screen of the camera is a touch panel. Monitor Screen This means you can perform the following operations by touching the screen with your fingers. Touch Momentarily touching the screen with your finger. Touch the screen to select an icon or menu item, and to configure settings.

  • Page 20: First, Charge The Battery Prior To Use

    NOTE • Applying a commercially available LCD protective sheet will reduce the operation sensitivity of the monitor screen. First, charge the battery prior to use. The camera and the controller each have a built-in rechargeable lithium ion battery. The batteries are not charged when you purchase the camera, so you will need to charge both the camera and controller before using them.
  • Page 21 NOTE • If you turn on the camera or controller while charging with the USB-AC adaptor, you will be able to perform normal recording operations. In this case, however, charging of the camera will be stopped while it is turned on. .
  • Page 22 IMPORTANT! • A battery that has not been used for a long time and/or ambient temperature can cause charging to take longer than normal. These conditions may also cause the operation lamp to flash red. If this happens, refer to page 141. •...
  • Page 23 . To charge using a USB connection to a computer While the camera and controller are turned off, connect in the sequence shown below   [USB] port Computer (power turned on) USB port Micro USB cable [USB] cover (included with camera) When plugging in the connectors, orient this marking as described below.
  • Page 24 . Operation Lamp Indications While power is off Operation Lamp Status Meaning Lit red Charging Charging stopped due to abnormal internal Flashing red temperature, USB-AC adaptor problem, battery problem (page 141), timer operation. Unlit Charging complete While power is on •...
  • Page 25 IMPORTANT! • The first time you connect the camera or controller to your computer with the USB cable, an error message may appear on your computer. If this happens, disconnect and then reconnect the USB cable. • A battery that has not been used for a long time, certain types of computers, and connection conditions can cause charging to take longer than normal.
  • Page 26 Checking the Current Battery Level As battery power is consumed, a battery indicator on the monitor screen indicates its current level as shown below. Level High Camera Battery Indicator Controller * White Indicator Color White indicates battery power is low. Charge the battery as soon as possible. indicates that the battery is about to go dead.

  • Page 27: Turning Power On And Off

    Turning Power On and Off . Camera-Controller Wireless Connection The camera and controller communicate over a Bluetooth wireless technology connection. Once you perform the “pairing” operation required for Bluetooth wireless technology connection, the camera and controller will automatically connect to each other whenever you turn them on.
  • Page 28 • Note the precautions below to ensure stable communication between the camera and controller. – Make sure nothing is blocking the gray areas as shown in the illustrations. – Point the back of the controller at the camera. – Make sure there are no obstacles in the path between the camera and controller.

  • Page 29: Configuring Basic Settings The First Time You Turn On The Camera

    Toggling Between the REC Mode and PLAY Mode “ ” (Show Icons) In the REC mode, touch “ ” (PLAY). • If “ ” (PLAY) is not displayed on the screen, you can touching the To enter the Review image (page 61), or switch PLAY mode to the PLAY mode by touching “...
  • Page 30 Touch the date display format you want. Example: July 10, 2017 YY/MM/DD 17/7/10 DD/MM/YY 10/7/17 MM/DD/YY 7/10/17 Set the date and the time. • Touch the value you want to change (year, month, day, hour, minute) and then touch “ ”, “...

  • Page 31: Preparing A Memory Card

    Preparing a Memory Card Though the camera has built-in memory that can be used to store images and movies, you probably will want to purchase a commercially available memory card for greater capacity. The camera does not come with a memory card. Images recorded while a memory card is loaded are saved to the memory card.

  • Page 32: To Load A Memory Card

    • Never insert anything besides a supported memory card (page 31) into the memory card slot. • Should water or any foreign object ever get into the card slot, immediately turn off the camera, and contact your retailer or nearest CASIO authorized service center. Quick Start Basics...

  • Page 33: To Format (Initialize) A New Memory Card

    . To replace the memory card Press the memory card and then release it. This will cause it to pop out of the memory card slot slightly. Pull the card out the rest of the way and then insert another one. •...

  • Page 34: To Shoot A Snapshot

    To Shoot a Snapshot Your camera has a variety of different recording modes to suit various shooting conditions and objectives (page 41). This section explains general shooting procedures using the auto recording mode. Selecting an Auto Recording Mode You can select one of two auto recording modes (Auto or Premium Auto Pro) according to your digital imaging needs.

  • Page 35: To Shoot A Snapshot

    To shoot a snapshot Point the camera at the subject. If you are using Premium Auto Pro, an icon will appear on the monitor screen describing the type of shot the camera has detected. • You can change display the zoom screen by holding two fingers against the screen and spreading them apart (page 48).
  • Page 36 . Shooting with Premium Auto Pro • Some menu items are not available while Premium Auto Pro is in use (page 52). • In addition to shutter speed and ISO sensitivity, the camera automatically executes the following operation as required when shooting with Premium Auto Pro. –...

  • Page 37: Viewing Snapshots

    Viewing Snapshots Use the following procedure to view snapshots on the camera’s monitor screen. • For information about how to play back movies, see page 62. Touch “ ” (PLAY) to enter the PLAY mode. “ ” (PLAY) This will display one of the snapshots currently stored in memory.

  • Page 38: Deleting Snapshots And Movies

    Deleting Snapshots and Movies If memory becomes full, you can delete snapshots and movies you no longer need in order to free up storage and record more images. IMPORTANT! • Remember that a file (image) delete operation cannot be undone. .

  • Page 39: Snapshot Shooting Precautions

    Snapshot Shooting Precautions Operation • If unwanted light is shining onto the lens, shade the lens with your hand when shooting an image. Monitor Screen when Shooting Snapshots • Subject brightness conditions can cause monitor screen response to slow and can cause digital noise in the monitor screen image.

  • Page 40: Recording Images

    Recording Images Touching the monitor screen in the REC mode will display a screen for configuring REC mode settings. To configure REC mode settings Press [ ] (Power) to turn on the camera and enter the REC mode. • If the camera is in the PLAY mode, touch “ ”...

  • Page 41: Selecting A Recording Mode

    Selecting a Recording Mode The camera has a variety of different recording modes. In the REC mode, touch the “ ” (Show Recording mode icon Icons). Touch the recording mode icon. Touch the icon of the recording mode you want to use.

  • Page 42: Shooting A Burst Of Images

    Shooting a Burst of Images (High Speed CS) Use the procedure below to shoot a burst of images. In the REC mode, touch “ ” (Show Icons). Touch the recording mode icon. Touch “Õ” (High Speed CS). Touch the scene that matches what you want to shoot. Scene Description High Speed CS 30 fps High-speed shooting of 30 images in one second.

  • Page 43: Shooting With Artistic Effects

    Shooting with Artistic Effects (Art Shot) A variety of artistic effects help to make even common, ordinary subjects become more novel and exciting. Scene Description Dark edges and altered hues make images look like they Toy Camera were shot by a toy camera. Soft Focus Overall blurring for a soft and romantic effect.

  • Page 44: Shooting Scenes Of An Activity At A Fixed Interval

    Shooting Scenes of an Activity at a Fixed Interval (Interval Shooting) You can use Interval Shooting to shoot snapshots and movies automatically at a specified interval. REC Screen Scene Description Icon Display Standard Shoots at a fixed interval. Intelligent Shoots after determining the optimum setup. Hiking Shoots using a setup optimized for hiking.
  • Page 45 Touch an item and then change its setting. Allows selection of one of the shooting intervals below. Interval 5 sec, 15 sec, 30 sec, 1 min, 2 min t³: Shoots five snapshots followed by a five-second movie. ³ Only: Shoots a five-second movie. Audio is also recorded with Shooting Style this setting.
  • Page 46 NOTE • Anti-shake is applied in accordance with the current camera settings. However, image anti-shake is not applied. • The current shooting setup, including zoom, cannot be changed while shooting with this function. • If the camera battery goes dead during an Interval Shooting operation, the operation will terminate.
  • Page 47 . To stop an Interval Shooting operation On the controller, press any button to recover from the sleep state. Touch “ ” icon. Touch “Yes”. This stops the Interval Shooting operation. . To shoot images manually during an Interval Shooting operation You can shoot snapshots and movies manually even while an Interval Shooting operation is in progress.

  • Page 48: Shooting With Zoom

    Shooting with Zoom Your camera is equipped with digital zoom, that lets you zoom an image up to 4X. Note that a digital process is used to enlarge the center of the image, so there is deterioration of image quality. Perform the required screen operation to change the zoom factor as desired.

  • Page 49: To Record A Movie

    To record a movie The following procedure explains how to record a movie. In the REC mode, touch “ ” (Show Icons). Touch “MENU”. Touch “ ”, “ ” until you find “Movie Quality”, and then touch to select it. Touch the item whose setting you want to change.
  • Page 50 Press [0] (Movie). Recording time This will start recording. • Monaural audio is also recorded during movie recording while “FHD(30p)” or “STD” is selected for the movie quality setting. • When “FHD(30p)” or “STD” is selected for the movie quality setting, you can touch a point on the controller screen while movie recording is in progress to focus on that point.
  • Page 51 Movie Recording Focus Position When the focus mode setting is “AF” or “PF”, recording is performed using pan focus, which provides a deep depth of field and suppresses image blurring. When the focus mode setting is “Macro”, the image is automatically focused and fixed before recording starts.

  • Page 52: Advanced Recording Settings

    Advanced Recording Settings The following are menu operations you can use to configure various camera settings. Using the REC Menu . Example Menu Screen Operation In the REC mode, touch “ ” (Show Icons). Touch “MENU”. This will display the menu screen. •...

  • Page 53: Recording Beautiful Portraits

    Recording Beautiful Portraits (Make-up) Procedure Enter the REC mode * MENU * “ r REC MENU” Tab * Make-up Make-up enables adjustment of human skin tone hues and texture, and softening of facial shadows caused by harsh sunlight for better looking portraits. Skin Tone “Tan +6”...

  • Page 54: Reducing Blur Due To Camera Movement During Movie Recording

    Using Focus Lock Subject to be focused on Use “focus lock” when you want to focus on a particular person or object. To use focus lock, configure the camera settings below. Touch Shooting: AF Only Focus Mode: AF or Macro Touch the subject you want to focus on.

  • Page 55: Changing The Image Size

    Changing the Image Size (Image Size) Procedure Enter the REC Mode * MENU * “ r REC MENU” Tab * Image Size This setting can be used to configure snapshot image size. Suggested Print Image Size REC Screen Size and Description (Pixels) Icon Display...

  • Page 56: Movie Image Quality Settings

    Movie Image Quality Settings (Movie Quality) Procedure Enter the REC Mode * MENU * “ r REC MENU” Tab * Movie Quality This setting can be used to configure movie image quality settings and to select either normal movie recording or High Speed Movie recording. For information about movie image quality settings, see page 49.

  • Page 57: Adjusting White Balance

    Adjusting White Balance (White Balance) Procedure Enter the REC Mode * MENU * “ r REC MENU” Tab * White Balance You can adjust white balance to match the source of light available where you are shooting and avoid the blue cast that results when shooting outdoors when it is cloudy, and the green cast that results when shooting under fluorescent lighting.

  • Page 58: Specifying Iso Sensitivity

    Specifying ISO Sensitivity (ISO) Procedure Enter the REC Mode * MENU * “ r REC MENU” Tab * ISO ISO sensitivity is a measure of sensitivity to light. Setting Description Auto Adjusts sensitivity automatically according to conditions Lower Slow shutter speed Less noise ISO64 sensitivity...

  • Page 59: Selecting A Focus Mode

    Selecting a Focus Mode (Focus) Procedure Enter the REC Mode * MENU * “ r REC MENU” Tab * Focus Changing to a different focus mode can help to achieve better focus. Focus Mode Approximate Focus Range REC Screen Settings Type of Shot Icon Display Snapshot...

  • Page 60: Self-Shooting

    Self-shooting (Mirror Image) Procedure Enter the REC Mode * MENU * “ r REC MENU” Tab * Mirror Image Turning on this function displays the controller monitor image as a mirror image. This comes in handy when using the controller to compose self-shot images. The image is recorded in normal orientation (not mirror imaged).

  • Page 61: Turning On Image Review

    Turning on Image Review (Review) Procedure Enter the REC Mode * MENU * “ r REC MENU” Tab * Review While Review is turned on, the camera will display an image immediately after it is recorded. Type 1 Displays a full-screen view of the image for about one second. Displays a review image in the lower left corner (when the controller is in landscape orientation) or the upper left corner (in portrait orientation) Type 2...

  • Page 62: Viewing Snapshots And Movies

    Viewing Snapshots and Movies Viewing Snapshots See page 37 for the procedure for viewing snapshots. Viewing a Movie Touch “ ” (PLAY) to enter the PLAY mode. Image quality Flick left or right across the screen image to scroll through the movies until the one you want is displayed.

  • Page 63: Viewing The Image Menu

    Viewing the Image Menu The image menu shows multiple images on a single screen. In the PLAY mode, touch “ ” or squeeze your fingers on the screen. This displays the image menu. • Touch “ ”, “ ”, or flick upwards or downwards to scroll to the next page of images.

  • Page 64: Creating A Movie Of A Day's Images

    Creating a Movie of a Day’s Images (Highlight Movie) You can configure camera settings to automatically select snapshot and movie highlights, and create a movie of them. Images included in a Highlight Movie are selected based on their highlight scores and shooting condition information recorded along with the images.
  • Page 65 • Only FHD(30p) quality movies that have been recorded with this camera or with a CASIO EX-FR10 camera can be used in a Highlight Movie. Even if a movie was recorded with this camera, it cannot be used in a Highlight Movie if it is HS240 or STD quality.

  • Page 66: Creating A Collage Of A Day's Snapshots

    Creating a Collage of a Day’s Snapshots (Highlight Photo) You can configure camera settings to automatically select snapshot highlights and generate a collage of them. The snapshots included in a Highlight Photo are selected automatically based on their high light scores and shooting condition information recorded along with the snapshots.

  • Page 67: Changing The Highlight Score Of An Image

    NOTE • An image whose highlight score is “0” is never included in a Highlight Photo. • When there are more than 9,999 snapshots shot on the same date stored on the memory card, Highlight Photo will select photos from those numbered 1 to 9999. •...

  • Page 68: Creating A Time Lapse Movie

    Creating a Time Lapse Movie (Time Lapse) This function creates a Time Lapse Movie up to 10 minutes long by combining snapshots shot with the camera on a particular date, in the order they were shot. In the PLAY mode, touch “ ”...
  • Page 69 NOTE • A Time Lapse Movie is FHD(30p) movie quality, with an aspect ratio of 16:9. If an image with an aspect ratio that is not 16:9 is incorporated into a Time Lapse Movie, the top and bottom of the image will be cropped as required. •...

  • Page 70: Other Playback Functions (Play)

    Other Playback Functions (PLAY) The following are menu operations you can use to configure various camera settings. Using the PLAY Menu . Example Menu Screen Operation In the PLAY mode, touch “ ” (Show Icons). Touch “MENU”. This will display the menu screen. •...

  • Page 71: Rotating An Image

    Rotating an Image (Rotation) Procedure Enter the PLAY Mode * MENU * Rotation Flick left or right to display the image you want to rotate. Touch “ ”. This will rotate the image 90 degrees to the left. When the image is in the orientation you want, touch “ ”.

  • Page 72: Connecting The Camera With A Smartphone (Wireless Connection)

    Connecting the Camera with a Smartphone (Wireless Connection) Controlling Your Camera with a Smartphone Your camera has both Bluetooth wireless technology and wireless LAN capabilities built in. After establishing a wireless connection with a smartphone, you can perform the operations described in the table below. Requires installation of the EXILIM Connect app on your smartphone.
  • Page 73 With this function: You can do this: View on phone View snapshots stored in camera memory on a smartphone, and copy snapshots and movies to a smartphone for viewing. You can also view snapshots and movies in camera memory on a computer, and copy them to a computer (page 81).

  • Page 74: Using A Wireless Mode

    • Note that to view the EXILIM Connect User’s Guide (PDF), you will have to install Adobe Reader. Consult CASIO authorized service center if you are unable to open to display the PDF format User’s Guide. • Note that EXILIM Connect User’s Guides may not be available in all languages. If you cannot find a EXILIM Connect User’s Guide in your native language, please...

  • Page 75: Getting Ready To Establish A Connection Between A Smartphone And Your

    For information about OS versions (Android and iOS) supported by the EXILIM Connect app, visit the Google Play or the App Store download site, or the Official CASIO Digital Camera Website (http://www.exilim.com/). . App operation guarantees No guarantees are made concerning the ability to operate the EXILIM Connect app on any particular smartphone or tablet.

  • Page 76: Establishing A Wireless Connection For The First Time

    Establishing a Wireless Connection for the First Time The first time you establish a wireless connection between the camera and a smartphone, you need to use the procedure below to configure wireless connection settings. This operation is required for the first connection only. .
  • Page 77 NOTE • “Auto Send” (page 82) will be turned on after you configure wireless connection settings on the camera and smartphone. • Turning off the camera also terminate the Bluetooth wireless technology connection. . Smartphone that does not support Bluetooth Smart Configure smartphone wireless LAN connection settings (input the camera SSID and password).
  • Page 78 . What to do if you are unable to establish a wireless LAN connection between the camera and a smartphone. This problem may be caused when the smartphone is already wirelessly connected to one of the networks or devices below. Go to your smartphone’s Wi-Fi settings and select this camera’s SSID.

  • Page 79: Using A Smartphone As A Camera Remote Controller (Shoot With Phone)

    Using a Smartphone as a Camera Remote Controller (Shoot with phone) This function lets you remotely shoot a snapshot or movie with the camera using a smartphone. You also can perform remote zoom and other operations as well. . Bluetooth Wireless Technology Connection Perform one of the operations below.

  • Page 80: Sending A Snapshot Or Movie File From Camera Memory To A Smartphone

    Sending a Snapshot or Movie File from Camera Memory to a Smartphone (Send Selected Image) You can select one more snapshot and/or movie file in camera memory and send it to a smartphone. You can select up to 50 files, totaling no more than 500MB for a single send.

  • Page 81: Viewing Snapshots And Movies In Camera Memory On A Smartphone

    Viewing Snapshots and Movies in Camera Memory on a Smartphone (View on phone) You can connect the camera to a smartphone over wireless LAN to view and download snapshots and movies in camera memory on up to eight connected smartphones. You can also view snapshots and movies in camera memory on a computer, and copy them to a computer.

  • Page 82: Configuring Wireless Connection Settings

    Configuring Wireless Connection Settings This section explains wireless mode operations and setting items. Touch the “ ” (Wireless) icon. This will display the wireless mode screen. • Pressing the shutter button will return to the screen that was displayed before the wireless mode screen.

  • Page 83: Specifying Images To Be Sent By Auto Send

    NOTE • Auto Send can be used only with a smartphone that supports Bluetooth Smart. Both a Bluetooth and wireless LAN connection are required between the camera and smartphone to auto send camera images. • You can specify the size of the image sent to the smartphone using “Resize When Sending”...

  • Page 84: Resizing Snapshots Before Sending Them To A Smartphone

    Resizing Snapshots before Sending Them to a Smartphone (Resize When Sending) Procedure ” (Wireless) * Wireless settings * Resize When Sending “ This feature can be use to resize snapshots before they are sent to a smartphone using “Shoot with phone” or “Send to phone”. Images are converted to 3M size before being sent.

  • Page 85: Unpairing The Camera From A Smartphone

    NOTE • Changing the wireless LAN password will terminate the connection with the smartphone. To reconnect with the smartphone, configure wireless connection settings (page 76). If your smartphone does not support Bluetooth Smart, perform the operations below to change your smartphone’s Wi-Fi settings. –...

  • Page 86: Using Two Cameras At The Same Time (Multi Camera Mode)

    Using Two Cameras at the Same Time (Multi Camera Mode) What you can do with two cameras You can register two cameras on the controller and operate them both at the same time or individually. Feature Description Simultaneous shooting with You could point one camera at yourself and the two cameras other camera at a scene, and simultaneously...

  • Page 87: Preparing A Second Camera To Be Registered On The Controller

    • In addition to the camera that comes with the controller, you can also register the camera model below on the controller. – EX-FR100* or EX-FR200 camera Update the camera’s firmware to the latest version. Preparing a Second Camera to be Registered on the...
  • Page 88 NOTE • Up to two cameras can be registered at one time. To add a new camera while two cameras are already registered, you will need to first unregister one of the registered cameras. • A message will appear if camera registration fails, and then the display will return to the screen that was shown before you touched the “...
  • Page 89 . Camera Connection Priority (Camera Priority) Turning on the controller when there are two cameras registered will cause the controller to try and connect with one of the cameras. You can use the procedure to specify a “main camera”, which is the one the controller will always connect with first. On the menu screen, touch the “...

  • Page 90: Multi Camera Mode

    Multi Camera Mode “ ” will be displayed on the controller when there are two cameras registered on it. Touch “ ” to start the connection operation with Camera 2. Connecting the controller with two cameras will enter the Multi Camera Mode, in which the controller can control both cameras.
  • Page 91 . Exiting the Multi Camera Mode Exit the Multi Camera Mode whenever you want to use the controller with a single camera. Touch “ ” on the screen. Touch the screen of the camera you want to use. This exits the Multi Camera Mode and displays the image of the camera you selected above.

  • Page 92: Shooting With The Multi Camera Mode

    Shooting with the Multi Camera Mode This section provides an overview of how to shoot images using the Multi Image screen and the Single Image screen in the Multi Camera Mode. For more detailed information, see “To Shoot a Snapshot” (page 34). •...
  • Page 93 NOTE • Simultaneous shooting with both cameras is not possible while either of the cameras is recording a movie. . Shooting with a Single Camera You can use the operations below to shoot on either one of the cameras while viewing images of both cameras on the Multi Image screen.
  • Page 94 . Multi Image Screen Operations • You cannot configure camera REC mode settings while the Multi Image screen is displayed. To configure such settings, touch “ ” or “ ” to display the Single Image screen of the camera whose REC mode settings you want to configure, and then touch the REC Mode icon.

  • Page 95: Shooting With The Single Image Screen

    Shooting with the Single Image Screen You can use the operations below to shoot with either one of the cameras while viewing its image on the Single Image screen. Camera 1 or Camera 2 REC screen Switches to the Multi Image screen.
  • Page 96 . Single Image Screen Operations • Menu screen, REC mode screen, and wireless mode settings you configure for Camera 1 or Camera 2 on the Single Image screen are maintained when you return to Multi Image screen and even when you exit the Multi Camera Mode. •...

  • Page 97: Viewing Snapshots And Movies In The Multi Camera Mode

    Viewing Snapshots and Movies in the Multi Camera Mode This section provides an overview of how to view images using the Multi Image screen and the Single Image screen in the Multi Camera Mode. For more detailed information, see “Viewing Snapshots and Movies” (page 62). Multi Image Screen Operations You can use this screen to display the playback screens of the two cameras side by side (or above and below in the case of portrait orientation) and view snapshots and...
  • Page 98 . To playback movies shot with both cameras simultaneously On the Camera 1 or Camera 2 screen, display the movie you want to view. While there is a movie displayed on the playback screen of both Camera 1 and Camera 2, “ ”...

  • Page 99: Single Image Screen Operations

    Single Image Screen Operations You can use the operations below to view snapshots or movies of either Camera 1 or Camera 2 on the Single Image screen. Camera 1 or Camera 2 PLAY screen Switches to the Multi Image screen. Switches the Single Image screen between the two cameras.

  • Page 100: Printing

    Printing Professional Print Service You can take a memory card that contains the images you want to print to a professional print service and have them printed. Printing on a Home Printer You can use a printer equipped with a memory card slot to print images directly from a memory card.

  • Page 101: Using The Camera With A Computer

    Using the Camera with a Computer Things you can do using a computer... You can perform the operations described below while the camera is connected to a computer. Save images to a • Save images and view them manually computer and (USB connection) (pages 102, 105).

  • Page 102: Viewing And Storing Images On A Computer

    Viewing and Storing Images on a Computer You can connect the camera to your computer in order to view and store images (snapshot and movie files). Never use your computer to modify, delete, move, or rename any image files that are in the camera’s built-in memory or on its memory card. Doing so can cause problems with the camera’s image management data, which will make it impossible to play back images on the camera and can drastically alter remaining memory capacity.
  • Page 103 Windows 10 users: Click “Start” and then “Explorer”. Next, in the sidebar, click “PC”. Windows 8.1 users: Click “Desktop” and then “Explorer”. Windows 7, Windows Vista users: Click “Start” and then “Computer”. Double-click “Removable Disk”. • Your computer recognizes the memory card loaded in the camera (or built-in memory if there is no card) as a removable disk.
  • Page 104 . To view images you copied to your computer Double-click the copied “DCIM” folder to open it. Double-click the folder that contains the images you want to view. Double-click the image file you want to view. • For information about file names, see “Memory Folder Structure” on page 109. •...

  • Page 105: Using The Camera With A Macintosh

    Using the Camera with a Macintosh Operating When you want to do this: Required Software System Version Save images to your Macintosh and view them OS X Installation not required. there manually Save images to your Photos or iPhoto, which comes Macintosh automatically/ OS X bundled with some Macintosh...
  • Page 106 . To connect the camera to your computer and save files On the camera, hold down [ [USB] port (Power) for about two seconds to turn off power. Next, use the micro USB cable that comes with the camera to connect it to your computer’s USB port.
  • Page 107 . To view copied images Double-click the camera’s drive icon. Double-click the “DCIM” folder to open it. Double-click the folder that contains the images you want to view. Double-click the image file you want to view. • For information about file names, see “Memory Folder Structure” on page 109. •...

  • Page 108: Files And Folders

    Files and Folders The camera creates a file each time you shoot a snapshot, record a movie, or perform any other operation that stores data. Files are grouped by storing them in folders. Each file and folder has its own unique name. •...

  • Page 109: Memory Card Data

    File System (DCF). . About DCF The following operations are supported for DCF-compliant images. Note, however, that CASIO makes no performance guarantees concerning these operations. • Transferring this camera’s DCF-compliant images to another manufacturer’s camera and view them. • Printing this camera’s DCF-compliant images on another manufacturer’s printer.
  • Page 110 . Built-in Memory and Memory Card Data Handling Precautions • Whenever copying memory contents to your computer, you should copy the DCIM folder and all of its contents. A good way to keep track of multiple DCIM folders is to change their names to dates or something similar after you copy them to your computer.

  • Page 111: Other Settings (Set Up)

    Other Settings (Set Up) This section explains menu items that you can use to configure settings and perform other operations in both the REC mode and PLAY mode. For information about menu operations, see page 52. Adjusting Monitor Screen Brightness (Screen) Procedure MENU * “...

  • Page 112: Locking The Camera Or Controller Screen Orientation

    Locking the Camera or Controller Screen Orientation (Rotation Lock) Procedure MENU * “ Setup” Tab * Rotation Lock You can use this setting to fix the orientation of the camera or controller screen image, or allow the orientation to be detected and automatically rotated as required. The camera detects its orientation when you are shooting, and stores orientation information along with the image data.

  • Page 113: Using The Vibration Function

    Using the Vibration Function (Vibration) Procedure MENU * “ Setup” Tab * Vibration While “On” is selected for this function, the controller will vibrate whenever any one of the events described below occurs. • When a “Type 1” review image is displayed on the controller immediately after shooting •...

  • Page 114: Specifying The Date Style

    Specifying the Date Style (Date Style) Procedure MENU * “ Setup” Tab * Date Style You can select from among three different styles for the date. Example: July 10, 2017 YY/MM/DD 17/7/10 DD/MM/YY 10/7/17 MM/DD/YY 7/10/17 Specifying the Display Language (Language) Procedure MENU * “...

  • Page 115: Formatting Built-In Memory Or A Memory Card

    Formatting Built-in Memory or a Memory Card (Format) Procedure MENU * “ Setup” Tab * Format If a memory card is loaded in the camera, this operation will format the memory card. It will format built-in memory if no memory card is loaded. •...

  • Page 116: Checking The Current Camera Firmware Version

    Checking the Current Camera Firmware Version (Version) Procedure MENU * “ Setup” Tab * Version Selecting this menu item displays the camera model name, the version of firmware installed on the camera. • Check this screen after updating the camera’s firmware to confirm that updating was actually performed.

  • Page 117: Appendix

    • The battery is intended for use with a CASIO Digital Camera only. Use with any other device creates the risk of the battery damage, or deterioration of battery performance and service life.
  • Page 118 DANGER • Failure to observe any of the following precautions creates the risk of battery overheating, fire, and explosion. – Never use or leave the battery near open flame. – Do not expose the battery to heat or fire. – Make sure the battery is oriented correctly when charging it. –...
  • Page 119 2. If you are using the USB-AC adapter to power the camera, unplug the power plug from the power outlet. 3. Contact your retailer or nearest CASIO authorized service center. . Keep Away From Fire • Never expose the camera to fire, which can cause it to explode and creates the risk of fire and personal injury.
  • Page 120 • Except when disposing of the camera, never try to take it apart or modify it in any way. Doing so creates the risk of electric shock, burn injury, and other personal injury. Be sure to leave all internal inspection, maintenance, and repair up to your retailer or nearest CASIO authorized service center. Appendix...

  • Page 121: Memory Cards

    2. If you are using the USB-AC adapter to power the camera, unplug the power plug from the power outlet. 3. Contact your retailer or nearest CASIO authorized service center. . Memory Cards • Memory cards are small and present a risk of accidentally being swallowed by infants and young children.
  • Page 122 Grasp the power plug and pull. . Built-in Rechargeable Battery • If battery charging does not end normally within the specified charging time, stop charging anyway and contact your local CASIO authorized service center. Continued charging creates the risk of battery overheating, fire, and explosion.

  • Page 123: Monitor Screen

    CAUTION . Locations To Be Avoided • Never leave the camera in any of the following types of locations. Doing so creates the risk of fire and electric shock. – Areas subject to large amounts of humidity or dust – Food preparation areas or other locations where oil smoke is present –...

  • Page 124: Shock Resistant, Splashproof, Dustproof

    IMPORTANT! • The shock resistance, splashproofing, and dustproofing of this product are based on CASIO test results, and do not constitute any guarantee that the product will perform, will not be damaged, or will not malfunction under such conditions. . Precautions before Underwater Use This camera can be used to shoot images underwater up to a depth of 1.5 meters...
  • Page 125 • Close the [CARD] cover and [USB] cover securely into place. • Never open or close the [CARD] cover or [USB] cover while near water or in an area exposed to sea breezes. Also avoid opening or closing the covers while your hands are wet.
  • Page 126 • In order to maintain splashproofing, replacement of the camera’s gaskets is recommended once each year. Note that you will be charged for gasket replacement. Contact a CASIO authorized service center or your original retailer for gasket replacement. Appendix...
  • Page 127 • CASIO COMPUTER CO., LTD. shall not be held liable for any accident that may occur while the camera is being used underwater. • CASIO COMPUTER CO., LTD. shall not be held liable for any damages or for any accident (personal injury, etc.) that occurs while using the camera underwater.

  • Page 128: Precautions During Use

    Precautions During Use . Data Error Precautions Your digital camera is manufactured using precision digital components. Any of the following creates the risk of corruption of data in camera memory. – Removing the memory card while the camera is performing some operation –...

  • Page 129: Caring For Your Camera

    Use the wireless function of this product only as specifically described in this manual. Any other use is unintended use, and CASIO COMPUTER CO., LTD. shall be held in no way liable for any damages arising out of unintended use.
  • Page 130 Use of this camera in a country or area other than where it was originally purchased runs the risk of being in violation of local radio laws and other laws. Note that CASIO COMPUTER CO., LTD. shall not be held in any way liable for any such violations.
  • Page 131 • The Bluetooth word mark and logos are registered trademarks owned by ® Bluetooth SIG, Inc. and any use of such marks by CASIO COMPUTER CO., LTD. is under license. Other trademarks and trade names are those of their respective owners.
  • Page 132 . Open Source Software This product includes software that is licensed under the license conditions below. OpenVG 1.1 Reference Implementation Copyright (c) 2007 The Khronos Group Inc. Permission is hereby granted, free of charge, to any person obtaining a copy of this software and /or associated documentation files (the "Materials "), to deal in the Materials without restriction, including without limitation the rights to use, copy, modify, merge, publish, distribute, sublicense, and/or sell copies of the Materials,...
  • Page 133 and distribution as defined by Sections 1 through 9 of this document. "Licensor" shall mean the copyright owner or entity authorized by the copyright owner that is granting the License. "Legal Entity" shall mean the union of the acting entity and all other entities that control, are controlled by, or are under common control with that entity.
  • Page 134 "Contributor" shall mean Licensor and any individual or Legal Entity on behalf of whom a Contribution has been received by Licensor and subsequently incorporated within the Work. 2. Grant of Copyright License. Subject to the terms and conditions of this License, each Contributor hereby grants to You a perpetual, worldwide, non-exclusive, no-charge, royalty-free, irrevocable copyright license to reproduce, prepare Derivative Works of, publicly display, publicly perform, sublicense, and distribute the...
  • Page 135 within a display generated by the Derivative Works, if and wherever such third-party notices normally appear. The contents of the NOTICE file are for informational purposes only and do not modify the License. You may add Your own attribution notices within Derivative Works that You distribute, alongside or as an addendum to the NOTICE text from the Work, provided that such additional attribution notices cannot be construed as modifying the License.
  • Page 136 9. Accepting Warranty or Additional Liability. While redistributing the Work or Derivative Works thereof, You may choose to offer, and charge a fee for, acceptance of support, warranty, indemnity, or other liability obligations and/or rights consistent with this License. However, in accepting such obligations, You may act only on Your own behalf and on Your sole responsibility, not on behalf of any other Contributor, and only if You agree to indemnify, defend, and hold each Contributor harmless for any liability...
  • Page 137 See the License for the specific language governing permissions and limitations under the License. Apache License Version 2.0, January 2004 http://www.apache.org/licenses/ TERMS AND CONDITIONS FOR USE, REPRODUCTION, AND DISTRIBUTION 1. Definitions. "License" shall mean the terms and conditions for use, reproduction, and distribution as defined by Sections 1 through 9 of this document.
  • Page 138 to that Work or Derivative Works thereof, that is intentionally submitted to Licensor for inclusion in the Work by the copyright owner or by an individual or Legal Entity authorized to submit on behalf of the copyright owner. For the purposes of this definition, "submitted" means any form of electronic, verbal, or written communication sent to the Licensor or its representatives, including but not limited to communication on electronic mailing lists, source code control systems,...
  • Page 139 attribution notices from the Source form of the Work, excluding those notices that do not pertain to any part of the Derivative Works; and (d) If the Work includes a "NOTICE" text file as part of its distribution, then any Derivative Works that You distribute must include a readable copy of the attribution notices contained within such NOTICE file, excluding those notices that do not pertain to any part of the Derivative Works, in at least one...
  • Page 140 8. Limitation of Liability. In no event and under no legal theory, whether in tort (including negligence), contract, or otherwise, unless required by applicable law (such as deliberate and grossly negligent acts) or agreed to in writing, shall any Contributor be liable to You for damages, including any direct, indirect, special, incidental, or consequential damages of any character arising as a result of this License or out of the use or inability to use the...

  • Page 141: Power Supply

    If problems persist after you perform the above steps or if the battery fails to charge after 5 hours, it could mean that the battery is faulty. Contact your nearest CASIO authorized service center. Appendix...

  • Page 142: Battery Precautions

    Battery Precautions . Precautions during Use • Operation provided by a battery under cold conditions is always less than operation under normal temperatures. This is due to the characteristics of the battery, not the camera. • Charge the battery in an area where the temperature is within the range of 15°C to 35°C (59°F to 95°F).

  • Page 143: Disposing Of The Camera

    • The battery of this camera is built-in and cannot be replaced by you. Contact your retailer or a CASIO authorized service center to have the battery replaced. • Make sure that the camera is turned off before removing the battery.
  • Page 144 . Controller Remove the four screws that secure the back of the controller. Holding the back cover in the circled area, rotate in the direction of the arrow to remove the cover. Rotate the cover on the end of the controller in the direction indicated by the arrow to remove it.
  • Page 145 Hook your fingertip at the location indicated in the illustration and lift the battery up to remove it. . Old Rechargeable Battery Handling Precautions • Insulate the positive and negative terminals with tape, etc. • Do not peel the covering off of the battery. •...

  • Page 146: Using A Memory Card

    Using a Memory Card See page 31 for information about supported memory cards and how to load a memory card. . Using a Memory Card • If a memory card starts to behave abnormally during image playback, you can restore normal operation by reformatting it (page 115). However, it is recommended that you always take along multiple memory cards whenever using the camera far away from the home or office.

  • Page 147: Reset Initial Default Settings

    Reset Initial Default Settings The tables in this section show the initial default settings on menus that appear in the REC mode and PLAY mode when you reset the camera (page 115). • A dash (–) indicates an item whose setting is not reset or an item for which there is no reset setting.

  • Page 148: Wireless Settings

    . Setup Menu Screen Language – Info Sleep 5 min Rotation Camera: Off Format – Lock Controller: Off Reset – Camera Version – Sound Multi-Pairing – Vibration Adjust – Date Style – . Wireless settings Auto Send Auto Send File T Only Settings Resize When...

  • Page 149: When Things Don't Go Right

    Check to make sure that the battery is charged and try turning power on again a number of times. If power still does not turn on, contact your retailer or a CASIO authorized service center. Power will not turn Use a thin object to press the [RESET] buttons (page 8) near off.
  • Page 150 Problem Possible Cause and Recommended Action There is digital Sensitivity may have been increased automatically for a dark noise in images. subject, which increases the chance of digital noise. Use a light or some other means to illuminate the subject. A recorded image 1)Camera power may have been turned off before the save was not saved.
  • Page 151 Problem Possible Cause and Recommended Action File Deletion A file cannot be The file may be protected. A protected image cannot be deleted. deleted. Wireless Connection I can’t establish a 1)The camera cannot connect with a smartphone if they are wireless connection.
  • Page 152 If the same message appears after you turn power back on, contact your retailer or a CASIO authorized service center. There are various The monitor screen shows indicators and other information indicators and about shooting conditions and the image you are recording.

  • Page 153: Display Messages

    Display Messages Access timed out. Appears when a connection could not be established with a Connection smartphone. dropped. This message appears when the camera or controller battery Battery is low. goes dead. Camera connection was A Bluetooth connection between the camera and controller lost.
  • Page 154 The file could not A Highlight Photo or Highlight Movie could not be generated be created. because there are not enough applicable images. There are no files. There are no files in built-in memory or on the memory card. This file cannot be The file you are trying to access is corrupted or is a type that played.

  • Page 155: Number Of Snapshots/Movie Recording Time

    Number of Snapshots/Movie Recording Time Snapshot microSD Image Size Approximate Built-in Memory Memory Card (Pixels) File Size Recording Capacity Recording Capacity 12M (4000 3000) 4.13 MB 2286 5M (2560 1920) 2.99 MB 4283 Movies Maximum Built-in Recording File Size of Maximum File Image Size / Approximate Data...
  • Page 156 Built-in memory capacity after formatting (Approx. 49.9MB) When using a 16GB microSDHC memory card (SanDisk Corporation). Number of image and recording time values depend on the memory card you are using. The data transfer rate of built-in memory is not sufficient for FHD(30p) movies. Whenever possible use an Ultra High-Speed Type memory card (pages 31, 51).

  • Page 157: Specifications

    Specifications File Format Snapshots: JPEG (Exif Version 2.3; DCF 2.0 standard) Movies: MOV format, H.264/AVC standard, IMA-ADPCM (monaural) Recording Media Built-in Memory (Image Storage Area: 49.9MB*) microSD/microSDHC/microSDXC * Built-in memory capacity after formatting Recorded Image Sizes Snapshots: 12M (4000 3000), 5M (2560 1920) Movies: FHD(30p) (1920...
  • Page 158 White Balance Auto, Daylight, Overcast, Shade, Daywhite Fluorescent, Daylight Fluorescent, Tungsten, Manual WB Sensitivity Snapshots: (Standard Output Auto, ISO 64, ISO 100, ISO 200, ISO 400, ISO 800, Sensitivity) ISO 1600, ISO 3200 Movies: Auto Communication Bluetooth: function (Camera) • Communication standard: Bluetooth ver2.1+EDR Output class: Class 2 Bluetooth Smart...
  • Page 159 • Recording Medium: 16GB microSDHC memory card (SanDisk Corporation UHS-I series) In accordance with CIPA (Camera and Imaging Products Association) standards In accordance with CASIO standards One-image scroll approximately every 10 seconds • The above values are based a new battery, starting from a full charge. Repeated charging shortens battery life.
  • Page 160 . USB-AC adaptor (AD-C53U) Input 100 to 240 V AC, 50/60 Hz, 100 mA Output 5.0 V DC, 650 mA Operating Temperature 5 to 35°C (41 to 95°F) Requirements Dimensions 53 (W) 21 (H) 45 (D) mm (2.1" (W) 0.83" (H) 1.8"...
  • Page 161 For more details, contact your customer service representative. Hereby, Casio Europe GmbH, Casio-Platz 1, 22848 Norderstedt, Germany, declares that this Digital Camera Model EX-FR100, EX-FR100CT is in compliance with the essential requirements and other relevant provisions of Directive 1999/5/EC. CAUTION Risk of explosion if battery is replaced by an incorrect type.
  • Page 162 0 mm from all persons and must not be co-located or operating in conjunction with any other antenna or transmitter. Declaration of Conformity Model Number: EX-FR100, EX-FR100CT Trade Name: CASIO Responsible party: Industrial Handheld Division Casio America, Inc.
  • Page 163 CASIO COMPUTER CO., LTD. 6-2, Hon-machi 1-chome Shibuya-ku, Tokyo 151-8543, Japan MA1608-A 2016...

Table of Contents
