Power Plate pro6 Assembly Instructions Manual page 5

Temporary Guide Bolts (4)
screw into Air Bellows first
Air Bellow (4)
Temporary
Guide Bolts
© Copyright 2010 Power Plate International
Power Plate Assembly –
Looking at the Platform assembly
upside-down, notice the 4 "Air
Bellows" in each corner.
Temporary Guiding bolts need to be
inserted into each Air Bellow. The
Temporary Guide bolt screws into the
threaded opening on top of the Air
Bellow, these bolts will "guide" the
platform into place when mounting
the Platform to the Column, and line
up the holes to attach the Securing
bolts.
pro6
Securing
Bolts
