Model PRO-900
Owner's Manual
3 Channel Remote
Car Starter
FEATURES :
w 1 Three Button Programmable RF Transmitters
w 1 5 Button Programmable Transceiver
w Three Channel Transceiver (capable of accepting 4 transmitters)
w Keyless Entry Outputs (+) and (-)
w On-Board Start Relay
w On-Board Accessory Relay
w On-Board Ignition 1 Relay
w On-Board Ignition 2 Relay
w Ignition 2 Relay Selectable On or Off During Cranking
w On-Board Parking Light Relay
w Ignition 3 / Shock By-Pass / GM VAT Output (relay required)
w Tach Signal Learning Circuit
w Two ( + ) and Two ( - ) Safety Shutdown Circuits
w Alarm By-Pass Output
w Accessory Outputs (Pulse Before & After Start, During Crank & After Shut Down)
w Selectable Steady or Flashing Parking Lights for Run Indication
w Selectable 5, 10, 15, 20 Minute Run Time
w Selectable 1 Sec., 3.5 Sec., or 1 Sec./Dbl 1 Sec. Door Lock Output Pulse
128-6846
1 of 4
Advertisement
Related Manuals for Audiovox PRO-900
Summary of Contents for Audiovox PRO-900
- Page 1 Model PRO-900 Owner’s Manual 3 Channel Remote Car Starter FEATURES : w 1 Three Button Programmable RF Transmitters w 1 5 Button Programmable Transceiver w Three Channel Transceiver (capable of accepting 4 transmitters) w Keyless Entry Outputs (+) and (-)
- Page 2 KEYLESS ENTRY 1. The Lock button on the transmitter is used to lock the vehicle's doors, the Unlock button is used to unlock the vehicle's doors. To lock or unlock the doors simply press and release the desired function button one time. As a keyless entry unit, for your convenience, the parking lights will flash once when the doors are locked and twice when the door are unlocked.
- Page 3 The Lock LED Indicates: When the lock button on the transmitter is pressed and the command is received and acted upon by the unit in the vehicle, this LED will light Red and the transmitter will beep once, then will continue flash once every 10 seconds so you, at a glance, can determine the status of your vehicle or determine the state it was last left in.
- Page 4 Audiovox accessories. If the accessory is a second two way Audiovox Remote Start Unit, perhaps installed in a second vehicle, then the vehicle will act upon the command but only the prime transmitter for that vehicle will indicate the command was acted upon.
