The selectable features can be set manually as explained below, or with the RF feature programmer.
To set features using the RF programmer, follow the instructions packaged with the programmer.
Factory default settings are indicated by bold text.
Note : The method of manual override can either be selected to operate from the valet switch or operate as custom code.
Be certain to place a check mark indicating the method used in the box located on the last page of the owner's manual.
NOTE: Keyless Entry Models with no horn output will Flash the Parking Lights instead of chirp where chirp is indicated.
Also, No data will be indicated if a feature is not available for a particular model. The unit will enter the feature but no selection will be available.
RF Programmable Feature Bank 1 Is For Transmitter Programming See Transmitter Programming Guide.
RF Programmable Features Bank 2 Is Alarm Selectable Features:
Feature Selection
1 Chirp
1st DoorL/UL
1 Sec.
2nd Accy Lock
Not Available
3rd Accy. UL
Not Available
4th Headlights
Not Available
5th Passive Locks
Not Available
6th Pass/Act Arm
Not Available
7th Siren/Horn
Not Available
8th Horn Chirp
Not Available
9th O/R Method
Not Available
10th 2 Step U/L
Not Available
11th Chp Del Tx
Not Available
12th Voltage/Hd Wire
Not Available
13th Trigger Circuits
Not Available
14th Lock/Unlock Poll
Not Available
15th Aux Ch 5 Sel
Not Available
16th Aux Ch 6 Sel
Not Available
17th Aux Ch 7 Sel
Not Available
18th Trigger Delay
Not Available
When using the RF programmer, enter the program mode as follows:
Turn the ignition on
Press and release valet switch 3 times
turn ignition off then on
Press and hold valet switch for 5 seconds
Siren and or lights chirp/flash 2 times indicating access to RF feature program mode.
2 Chirps
3 Chirps
4 Chirps
3.5 Sec.
1 Sec L, Dbl. U/L
Dbl L, 1 Sec UL
Model PRO-9056

Installation Manual

5 Chirps
6 Chirps
Dbl L, Dbl UL
1 S l/350mS ul
