Denon ADV-700 Service Manual

Hide thumbs Also See for ADV-700:
Table of Contents

Advertisement

Quick Links

QQ
3 7 63 1515 0
TE
L 13942296513
SAFETY PRECAUTIONS ................................................... 2
SPECIFICATIONS .............................................................. 2
REPLACING TRAVERSE UNIT ..................................... 3~5
DISASSEMBLY ............................................................. 6~10
CAUTION IN SERVICING ................................................ 10
ELECTRICAL ADJUSTMENT .......................................... 11
BLOCK DIAGRAMS .................................................... 12,13
LEVEL DIAGRAMS ..................................................... 14,15
CLOCK FLOW .................................................................. 16
SEMICONDUCTORS ................................................ 17~46
PRINTED WIRING BOARDS .................................... 47~54
NOTE FOR PARTS LIST ................................................. 55
PARTS LIST OF P.W.B. UNIT .................................. 56~71
EXPLODED VIEW ............................................................. 72
PARTS LIST OF EXPLODED VIEW ................................ 73
PARTS LIST OF DVD MECHANISM UNIT ..................... 74
EXPLODED VIEW OF DVD MECHANISM ...................... 75
POINTS OF GREASING .................................................. 76
www
Some illustrations using in this service manual are slightly different from the actual set.
.
http://www.xiaoyu163.com
SERVICE MANUAL
MODEL
DVD SURROUND RECEIVER

- TABLE OF CONTENTS -

x
u163
14-14, AKASAKA 4-CHOME, MINATO-KU, TOKYO 107-8011 JAPAN
Telephone: 03 (3584) 8111
2 9
8
ADV-700
Q Q
3
6 7
1 3
1 5
PACKING VIEW ................................................................ 77
PACKING & ACCESSORIES ........................................... 77
WIRING DIAGRAM ........................................................... 78
SCHEMATIC DIAGRAMS ......................................... 81~88
(4/8) 1U-3358-1
(7/8) 1U-3360
co
.
9 4
2 8
For U.S.A. , Canada &
Europe model
Hi-Fi Component
0 5
8
2 9
9 4
2 8
DVD MAIN UNIT (1/2) ........................... 81
DVD MAIN UNIT (2/2) ........................... 82
MAIN UNIT (1/2) .................................... 83
MAIN UNIT (2/2) .................................... 84
REG UNIT ............................................. 84
AUDIO REG UNIT ................................. 84
PROT/FAN UNIT .................................... 84
POSISTOR UNIT ................................... 84
D-BRIDGE UNIT .................................... 84
VIDEO UNIT .......................................... 85
COMPONENT UNIT ............................... 85
SCART UNIT ......................................... 85
OPT UNIT .............................................. 85
DISPLAY UNIT ...................................... 86
H/P UNIT ............................................... 86
SUB TRANS UNIT ................................. 86
DSP UNIT (1/2) ..................................... 87
DSP UNIT (2/2) ..................................... 88
m
X0115 842 NC 0108
9 9
9 9

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the ADV-700 and is the answer not in the manual?

Questions and answers

Related Manuals for Denon ADV-700

Summary of Contents for Denon ADV-700

  • Page 1: Table Of Contents

    3 7 63 1515 0 For U.S.A. , Canada & Europe model Hi-Fi Component SERVICE MANUAL ADV-700 MODEL DVD SURROUND RECEIVER L 13942296513 — TABLE OF CONTENTS — SAFETY PRECAUTIONS ........... 2 PACKING VIEW ..............77 SPECIFICATIONS .............. 2 PACKING &...

  • Page 2: Safety Precautions

    ADV-700 3 7 63 1515 0 SAFETY PRECAUTIONS The following check should be performed for the continued protection of the customer and service technician. LEAKAGE CURRENT CHECK Before returning the unit to the customer, make sure you make either (1) a leakage current check or (2) a line to chassis resistance check.

  • Page 3: Diagnostics Of Optical Pickup And Replacing Traverse Unit

    ADV-700 3 7 63 1515 0 DIAGNOSTICS OF OPTICAL PICKUP AND REPLACING TRAVERSE UNIT Make failure diagnostics of the Optical Pickup as follows. If the laser drive current becomes more than 1.5 times of the initial value, the Optical Pickup should be replaced.
  • Page 4 ADV-700 3 7 63 1515 0 Note for Handling the Laser Pick-up The protection for the damage of laser diode. If you want to change the optical device unit from any other units, you must keep the following. (1) It should be done at the desk already took measures the static electricity in care of removing the OPU's (Optical device unit) connector cable.
  • Page 5 ADV-700 3 7 63 1515 0 Optical Pick-up Diagnostics and Replacement When repairing, carry out failure diagnostics by following the procedure described below. If the present value of the laser drive current is 50% up to initial value, it is the point of the pickup replacement.

  • Page 6: Disassembly

    ADV-700 3 7 63 1515 0 DISASSEMBLY ( Follow the procedure below in reverse order when reassembling ) 1. Top Cover 1) Remove 4 screws on both sides. 2) Remove 6 screws on the rear panel. 3) Detach the Cover as shown in the arrow direction.
  • Page 7 ADV-700 3 7 63 1515 0 3. DSP PWB 1) Remove 4 screws fixing the DSP PWB. 2) Disconnect FFC x 3 from the DSP PWB. DSP P.W.B. 4. DVD Mecha. Unit 1) Remove 4 screws on the DVD Mecha. Unit.

  • Page 8: Model

    ADV-700 3 7 63 1515 0 6. Video PWB 1) Disconnect FFC x 2, 11P Connector, and 3P Connector from the Video PWB. 3P Connector 2) Detach the Video PWB from the PWB Holder. 11P Connector (Europe Model) 10P Connector (USA, Canada Model) Video P.W.B.

  • Page 9: Disassembly

    ADV-700 3 7 63 1515 0 TRAVERSE UNIT DISASSEMBLY (Follow the procedure below in reverse order when reassembling) Caution: The optical pickup can be damaged easily by static electricity charged on human body. Take necessary anti-static measures when repairing around the optical pickup.

  • Page 10: Caution In Servicing

    ADV-700 3 7 63 1515 0 3. Traverse Unit disassembly (1) Remove 24P FFC (CX241), 15P FFC (CX151), 24P FFC (CX241) 5P PH WIRE (CX051) and 3P PH WIRE (CX031) connecting with from the DVD Main P.W.B. (2) Remove 4 screws of fixing Damper.

  • Page 11: Electrical Adjustment

    ADV-700 3 7 63 1515 0 ELECTRICAL ADJUSTMENT The following adjustment is electrical adjustments. These adjustments are to be performed after replacing the printed circuit boards. 1. Video Output (Interlace) Adjustment Measurement Point Adjustment Point Mode Disc Video Output Pin Terminal...

  • Page 12: Block Diagrams

    ADV-700 BLOCK DIAGRAMS 3 7 6 3 1 5 1 5 0 ADV-700 BLOCK DIAGRAM (1/2) (Mechanism section) 8M FLASH ROM [HY29F080T] 16M SDRAM x2 4M DRAM 4M DRAM HRESET FRONTEND DISC SERVO ATAPI 24P FFC PROCESSOR PROCESSOR INTERFACE...

  • Page 13: Block Diagrams

    ADV-700 3 7 6 3 1 5 1 5 0 ADV-700 BLOCK DIAGRAM (2/2) (E2 ONLY) 1U-3359-5,6 BA7660(Europe model only) MUTE 1U-3359-3 1U-3359-1 MUTE UADV-7 (DVD ENGINE ) BA4053(E2 ONLY) MUTE DVD MECHA FRONT-END CIRCUIT MUTE MUTE FL TUBE...

  • Page 14: Level Diagrams

    ADV-700 LEVEL DIAGRAMS 3 7 6 3 1 5 1 5 0 FRONT STEREO H.P .F. INPUT A/D IN A/D IN D/A OUT REV. BUFF. PRE. POWER E.VOL TONE REV. AMP REV. AMP BUFF.AMP L.P .F. MIX AMP M62446 (1/3) fc=80Hz.12dB/OCT...
  • Page 15 ADV-700 3 7 6 3 1 5 1 5 0 SUBWOOFER D/A OUT BUFF. PRE. LINE LINE E.VOL L.P .F. M62446 (3/3) FROM MUT- − − MUT- PREOUT 1 3 9 4 2 2 9 6 5 1 3...

  • Page 16: Clock Flow

    ADV-700 CLOCK FLOW 3 7 6 3 1 5 1 5 0 A/D SWitch IC113 CODEC SN74HC244 IC107 IC109 IC108 LC89055W CS49329 AK4527VQ SN74LV244A (17) SW1 CKOUT(13) MCLK(44) (15) SW2 BCK(14) (25)SCLKN1,(28)CMPCLK SCLK(43) (13) SW3 LRCK(15) (26)LRCLKN1,(29)CMPREQ LRCLK(42) DATAO(16)

  • Page 17: Semiconductors

    ADV-700 3 7 63 1515 0 SEMICONDUCTORS IC's Note: Abbreviation ahead of IC No. indicates the name of P .W.B. DVD: DVD Main P .W.B. MA: Main P.W.B. D/V: Display / Video P.W.B. DSP P .W.B. M30624FG (MA: IC101)
  • Page 18 ADV-700 3 7 63 1515 0 Port Name Symbol Function RESERVED(DENON BUS) Arbitration input on DENON BUS (same as serial data) 50/60 Detect input of power pulse (50/60 Hz) FAN ON/OFF Fan motor drive output IN JOGB JOG pulse input B for function switching...
  • Page 19 ADV-700 3 7 63 1515 0 Port Name Symbol Function D14/P16 89055 CSFLAG Signal change detect input from DIR D13/P15 REMOTE IR remote control input D12/P14 /SYR Reset output to RDS IC of tuner D11/P13 INTREQ IN Open drain operation (L: output, H: switch to input)
  • Page 20 ADV-700 3 7 63 1515 0 ES4408F (DVD: IC101) HCS3FX# HCS1FX# HIOCS16# HRD#/DCI_ACK# HWR#/DCI_CLK LA10 LA11 HIORDY LA12 HRST# LA13 HIRQ/DCI_ERR# LA14 HRDQ# LA15 HWRQ#/DCI_REQ# LA16 HD15 HD14 LA17 LA18 HD13 LA19 HD12 LA20 HD11 LA21 HD10 RESET# TDMDX/RSEL...
  • Page 21 ADV-700 3 7 63 1515 0 Pin No. Pin Name Function Pin No. Pin Name Function DMA 3 DRAM address bus YUV 2 8-bit YUV output DMA 4 DRAM address bus YUV 3 8-bit YUV output DMA 5 DRAM address bus...
  • Page 22 ADV-700 3 7 63 1515 0 Pin No. Pin Name Function 3.6V power supply HA 2 Host address bus Peripheral protection voltage AUX 0 Auxiliary port, (SDATA) I/O AUX 1 Auxiliary port, (SCLK) O AUX 2 Auxiliary port, (VFD DATA) I/O 3.6V power supply...
  • Page 23 ADV-700 3 7 63 1515 0 TC9453F (DVD: IC505) LPFN LPFO VCOF SLCO1 Analog Digital to Driver TESM9 TEST2 RFCD RFDVD TESM4 1bit DAC from Digital RFCT DIGI Output RFZ1 for CD-DA RF-Amp. Servo TESM3 TEZ1 (servo signal) AWIN...
  • Page 24 ADV-700 3 7 63 1515 0 Pin No. Pin Name Function µcom address enable signal, Fail-safe pin µcom data read signal, Fail-safe pin /MRD µcom data write signal, Fail-safe pin /MWR µcom chip enable signal, Fail-safe pin /MCE µcom interrupt signal, Open drain pin /MINT µcom data bus...
  • Page 25 ADV-700 3 7 63 1515 0 Pin No. Pin Name Function BD12 External RAM data in/output GND for 5V BD13 External RAM data in/output BD14 External RAM data in/output BD15 External RAM data in/output   3.3V digital power...
  • Page 26 ADV-700 3 7 63 1515 0 TC9469BF (DVD: IC508) Buffer DRAM 256kw/128kw/64kw (4Mbit/2Mbit/1Mbit) CSEL (NC) /PDIAG./DASP (NC) (H-IF) (LRCK)PDA0 CD-IF & Buffer IORDY DVD-IF PSYCN.PDROM (BCK)PDA1 Address HDRQ PDCK Input (DA1)PDA2 /HDAK Selecter HEDda HD10 (C2P1)PDA3 PDA8 H-FIFO /IOCS16...
  • Page 27 ADV-700 3 7 63 1515 0 Pin No. Pin Name Function      GND pin Buffer address output Buffer address output Buffer address output Buffer address output Buffer address output  GND pin GND pin GND pin...
  • Page 28 ADV-700 3 7 63 1515 0 Pin No. Pin Name Function µcom address input µcom address input µcom address input /MCE Chip enable signal input  µcom chip read signal input /MRD  GND pin µcom write signal input /MWR µcom interrupt signal output, open drain, pull-up R built-in...
  • Page 29 ADV-700 3 7 63 1515 0 TMP95CW64F-**** (DVD: IC511) P33/A11 P05/D5 P32/A10 P04/D4 P31/A9 P03/D3 P30/A8 P02/D2 P47/A7 P01/D1 P46/A6 P00/D0 P45/A5 P44/A4 P96/TOA/TOB P43/A3 P95/TIB/INT8 P42/A2 P94/TIA/INT7 P41/A1 P93/TO9 P40/A0 P92/TO8 P50/RD P91/TI9/INT6 P51/WR P90/TI8/INT5 P52/HWR P75/TO7/INT4 (GND)VSS...
  • Page 30 ADV-700 3 7 63 1515 0 Pin No. Pin Name Symbol Function INT3 FG signal input from TA8493F BRKN Brake signal output to TA8493F Not used INT5 SLIDE_PULSE Pulse counter input of slide P-LOW PLL filter switching output PLLD...
  • Page 31 ADV-700 3 7 63 1515 0 TA1293F (DVD: IC501) P1TN DFTN P1TP P1FN P1FP LDP1 GNDR P1DI P1CI P1BI P1AI LDP2 P2AI P2BI P2CI VccS P2DI RFSW GNDS P2FP P2FN P2TP P2TN VccP TA1293F Terminal Function Pin No. Pin Name...
  • Page 32 ADV-700 3 7 63 1515 0 Pin No. Pin Name Function Used connecting with VrA Used connecting with VrA DFTN DPD defect, L: DPD out = Mute RF ripple center output RF ripple output Bottom of RF ripple Peak of RF ripple...
  • Page 33 ADV-700 3 7 63 1515 0 16M SDRAM (TSOP)-8 (DVD: IC103, 104) K4S161622D-TC80 W981616AH-8 Terminal Function Pin No. Pin Name Symbol Function Power Supply/Ground Power and ground for the input buffer and the core logic Data Input/Output Data input/output are mutiplexed on the same pin...
  • Page 34 ADV-700 3 7 63 1515 0 ADV7172KST (DVD: IC701) COMP1 DAC A DAC B TOP VIEW DAC C DAC D CSO_HSO DAC E Terminal Function Pin No. Pin Name Function P7-P0 8-Bit 4:2:2 Multiplexed YCrCb Pixel Port (P7-P0). CLOCK TTL Clock Input .(27 MHz reference clock)

  • Page 35: Terminal Function

    ADV-700 3 7 63 1515 0 BA5952AFP (DVD: IC504) VINFC MUTE Terminal Function CFCErr1 BIAS CFCErr2 VINTK Pin No. Name Function Pin No. Name Function VINSL+ CTKerr1 Focus driver input VINFC VOTK+ Tracking driver output(+) VINSL- CTKerr2 CFCerr1 Cap.connecting pin for error amp filter...
  • Page 36 ADV-700 3 7 63 1515 0 LC89055W (DS: IC107) LC89055W Terminal Function Pin Name Function DISEL Data input terminal (select input pin of DIN0, DIN1) DOUT Input bi-phase data through output terminal DIN0 Amp built-in coaxial/optical input correspond data input terminal...
  • Page 37 ADV-700 3 7 63 1515 0 CS493292-CL (DS: IC109) A0, SCCLK AUDATA2 DATA7, EMAD7, GPIO7 DATA6, EMAD6, GPIO6 DATA5, EMAD5, GPIO5 RESET DATA4, EMAD4, GPIO4 AGND Top View DGND2 FILT1 DATA3, EMAD3, GPIO3 FILT2 DATA2, EMAD2, GPIO2 CLKSEL DATA1, EMAD1, GPIO1...
  • Page 38 ADV-700 3 7 63 1515 0 AK4527BVQ (DS: IC108) SDOS DZF2/OVF RIN+ SMUTE RIN- BICK LIN+ AK4527BVQ LRCK LIN- SDTI1 ROUT1 Top View SDTI2 LOUT1 SDTI3 ROUT2 SDTO LOUT2 DAUX ROUT3 LOUT3 AK4527BVQ Terminal Funtion Port Name Function SDOS...
  • Page 39 ADV-700 3 7 63 1515 0 SN74LV574APW (DS: IC103) SN74LVC574APW (DS: IC104) SN74LV244APW (DS: IC105) SN74LVC244APW (DS: IC112) SN74HCT244APW (DS: IC106, 113) L 13942296513 ML6427 (D/V: IC310, 311) V CCO RGB V CCO CV V CC SWAP CVU SWAP CVF...
  • Page 40 ADV-700 3 7 63 1515 0 AD1854 (DS: IC401) Terminal Function Pin Name Function Pin No. DGND Digital Ground. DGND DVDD MCLK Master Clock Input. MCLK SDATA CLATCH Latch input for control data. CLATCH BCLK CCLK Control clock input for control data.
  • Page 41 ADV-700 3 7 63 1515 0 BA7625 (D/V : IC 302, 303) NJU4053B V (D/V: IC308) BA7626 (D/V : IC 301) (Europe model only) Monitor OUT CTL A VOUT1 OGIC Inhibit Inhibit CTL E CTL B OGIC VOUT2 CTL D...
  • Page 42 ADV-700 3 7 63 1515 0 LC72720NM (MA: IC106) VREF BIPHASE DIFFRENTIAL REFERENCE DETECTOR DETECTOR DECODER DECODER VOLTAGE MPXIN SC-BANDPASS FILTER Vdda ANTI- (57kHz) ALIASING COMPARATOR D (Ð 90°) Vssa SMOOTHING CLOCK FILTER FILTER RECOVERY FLOUT (D-YCO) D-PLL COIN...
  • Page 43 ADV-700 3 7 63 1515 0 M51957BFP (MA: IC104) TC74HC32AF (MA: IC102) Output: Open Collector µA 25 µA Input Output Input Output Delay-Cap 1.25 V Delay-Cap TC9164AN (MA: IC501) S29590A (MA: IC103) TEST L-COM R-COM1 L-COM R-COM L-COM R-COM2...
  • Page 44 ADV-700 3 7 63 1515 0 PQ070XZ01Z (DVD: IC112) 4M DRAM (SOJ)-35 (DVD: IC507,509) IS41C16256 M11B416256A DC input DC output Terminal Function VIEW I/O0 I/O15 Specific IC I/O1 I/O14 On/Off control Output voltage Name Function I/O2 I/O13 adjustment (V...
  • Page 45 ADV-700 3 7 63 1515 0 TRANSISTORS 2SA1037K DTA114EK 2SB709A DTC Series DTA144TK DTA Series 2SC2412K DTC114EK 2SD601A DTC114YK KTC2875B DTC143TK DTC144EK DTC323TK VIEW VIEW 10kohm /Ω 10kohm /Ω DTC114EK 10kohm /Ω 47kohm /Ω DTC114YK 10kohm /Ω 10kohm /Ω...
  • Page 46 ADV-700 3 7 63 1515 0 FL DISPLAY 15ST36GN (D/V: FL701) Pin Assignment Pin No, Connection Pin No, Connection Note: 1. Fn: Filament 2. nG: Grid 3. Pn: Anode L 13942296513 4. NP: No Pin 5. NX: No Connection...

  • Page 47: Printed Wiring Boards

    ADV-700 PRINTED WIRING BOARDS 3 7 6 3 1 5 1 5 0 GU-3333 DVD MAIN P.W.B. Ass'y 1 3 9 4 2 2 9 6 5 1 3 w w w u 1 6 3 COMPONENT SIDE INTERNAL LAYER...
  • Page 48 ADV-700 3 7 6 3 1 5 1 5 0 1 3 9 4 2 2 9 6 5 1 3 w w w u 1 6 3 INTERNAL LAYER FOIL SIDE...
  • Page 49 ADV-700 3 7 6 3 1 5 1 5 0 1U-3358 MAIN P.W.B. Ass'y 15 14 1 3 9 4 2 2 9 6 5 1 3 w w w u 1 6 3 COMPONENT SIDE...
  • Page 50 ADV-700 3 7 6 3 1 5 1 5 0 1 3 9 4 2 2 9 6 5 1 3 w w w u 1 6 3 FOILSIDE http://www.xiaoyu163.com...
  • Page 51 ADV-700 3 7 6 3 1 5 1 5 0 1U-3359 DISPLAY P.W.B. Ass'y 1 3 9 4 2 2 9 6 5 1 3 w w w u 1 6 3 COMPONENT SIDE...
  • Page 52 ADV-700 3 7 6 3 1 5 1 5 0 1 3 9 4 2 2 9 6 5 1 3 w w w u 1 6 3 FOIL SIDE...
  • Page 53 ADV-700 3 7 6 3 1 5 1 5 0 1U-3360 DSP P.W.B. Ass'y 1 3 9 4 2 2 9 6 5 1 3 w w w u 1 6 3 COMPONENT SIDE...
  • Page 54 ADV-700 3 7 6 3 1 5 1 5 0 1 3 9 4 2 2 9 6 5 1 3 w w w u 1 6 3 FOIL SIDE...

  • Page 55: Note For Parts List

    ADV-700 3 7 63 1515 0 NOTE FOR PARTS LIST Part indicated with the mark " " are not always in stock and possibly to take a long period of time for supplying, or in some case supplying of part may be refused.

  • Page 56: Parts List Of P.w.b. Unit

    ADV-700 3 7 63 1515 0 PARTS LIST OF P.W.B. UNIT GU-3333Z DVD MAIN P.W.B. UNIT ASS'Y Ref. No. Part No. Part Name Remarks Ref. No. Part No. Part Name Remarks SEMICONDUCTORS GROUP R116-122 247 2009 941 Carbon chip 6.8kohm 1/16W...
  • Page 57 ADV-700 3 7 63 1515 0 Ref. No. Part No. Part Name Remarks Ref. No. Part No. Part Name Remarks R711 247 2018 903 Carbon chip 0ohm 1/16W RM73B--0R0K R551,552 247 2009 983 Carbon chip 10kohm 1/16W RM73B--103J R553-557...
  • Page 58 ADV-700 3 7 63 1515 0 Ref. No. Part No. Part Name Remarks Ref. No. Part No. Part Name Remarks C143-145 257 0512 903 Ceramic chip 0.1uF/25V CK73F1E104Z C231 257 0509 929 Ceramic chip 1000pF/50V CK73B1H102K C146 257 0509 929 Ceramic chip 1000pF/50V...
  • Page 59 ADV-700 3 7 63 1515 0 Ref. No. Part No. Part Name Remarks Ref. No. Part No. Part Name Remarks Q'ty C580 257 0501 927 Ceramic chip 0.015uF/50V CK73B1H153K OTHER PARTS GROUP C582-589 257 0512 903 Ceramic chip 0.1uF/25V...

  • Page 60: Model

    ADV-700 3 7 63 1515 0 Note: The symbols in the column “Remarks” indicate the following destinations. E3: U.S.A./Canada model 1U-3358/3358A MAIN P.W.B. UNIT ASS'Y E2: Europe model Ref. No. Part No. Part Name Remarks Ref. No. Part No.
  • Page 61 ADV-700 3 7 63 1515 0 Ref. No. Part No. Part Name Remarks Ref. No. Part No. Part Name Remarks R159 247 2010 985 Carbon chip 27kohm 1/16W RM73B--273J R557,558 247 2012 925 Carbon chip 100kohm 1/16W RM73B--104J for E2...
  • Page 62 ADV-700 3 7 63 1515 0 Ref. No. Part No. Part Name Remarks Ref. No. Part No. Part Name Remarks R703 247 2007 943 Carbon chip 1kohm 1/16W RM73B--102J R770 247 2007 943 Carbon chip 1kohm 1/16W RM73B--102J R704...
  • Page 63 ADV-700 3 7 63 1515 0 Ref. No. Part No. Part Name Remarks Ref. No. Part No. Part Name Remarks C118 254 4536 915 Electrolytic 47uF/10V CE04W1A470M (SMG/RE3) C559 257 0512 903 Ceramic chip 0.1uF/25V CK73F1E104Z for E2 C566,567 257 0501 901 Ceramic chip 0.01uF/50V...
  • Page 64 ADV-700 3 7 63 1515 0 Ref. No. Part No. Part Name Remarks Ref. No. Part No. Part Name Remarks Q'ty C733,734 257 0511 917 Ceramic chip 0.022uF/50V CK73F1H223Z OTHER PARTS GROUP C735 257 0503 925 Ceramic chip 10pF/50V...

  • Page 65: Model

    ADV-700 3 7 63 1515 0 1U-3359/3359A DISP/VIDEO P.W.B. UNIT ASS'Y Note: The symbols in the column “Remarks” indicate the following destinations. E3: U.S.A./Canada model E2: Europe model Ref. No. Part No. Part Name Remarks Q'ty Ref. No. Part No.
  • Page 66 ADV-700 3 7 63 1515 0 Ref. No. Part No. Part Name Remarks Ref. No. Part No. Part Name Remarks R336 247 2006 960 Carbon chip 470ohm 1/16W RM73B--471J R408 247 2011 900 Carbon chip 33kohm 1/16W RM73B--333J R337-339...
  • Page 67 ADV-700 3 7 63 1515 0 Ref. No. Part No. Part Name Remarks Ref. No. Part No. Part Name Remarks R721-723 247 2018 903 Carbon chip 0ohm 1/16W RM73B--0R0K C354 254 4538 939 Electrolytic 47uF/16V CE04W1C470M (SMG/RE3) R726,727 247 2009 983 Carbon chip 10kohm 1/16W...
  • Page 68 ADV-700 3 7 63 1515 0 Ref. No. Part No. Part Name Remarks Ref. No. Part No. Part Name Remarks Q'ty C441 257 0509 929 Ceramic chip 1000pF/50V CK73B1H102K CY171 205 1006 080 17P FFC connector base for E3...
  • Page 69 ADV-700 3 7 63 1515 0 1U-3360 DSP P.W.B. UNIT ASS'Y Ref. No. Part No. Part Name Remarks Ref. No. Part No. Part Name Remarks SEMICONDUCTORS GROUP R104 247 2008 955 Carbon chip 3kohm 1/16W RM73B--302J R105 247 2009 912 Carbon chip 5.1kohm 1/16W...
  • Page 70 ADV-700 3 7 63 1515 0 Ref. No. Part No. Part Name Remarks Ref. No. Part No. Part Name Remarks R401-403 247 2009 983 Carbon chip 10kohm 1/16W RM73B--103J C109,110 257 0512 903 Ceramic chip 0.1uF/25V CK73F1E104Z R404 247 2008 913 Carbon chip 2kohm 1/16W...
  • Page 71 ADV-700 3 7 63 1515 0 Ref. No. Part No. Part Name Remarks Ref. No. Part No. Part Name Remarks C195 257 0506 951 Ceramic chip 100pF/50V CC73CH1H101J C634,635 254 4524 969 Electrolytic 3.3uF/50V CE04W1H3R3M (SMG/RE3) C196 254 4522 916 Electrolytic 10uF/35V...

  • Page 72: Exploded View

    ADV-700 EXPLODED VIEW 3 7 6 3 1 5 1 5 0 Europe model U.S.A. & Canada model 1 3 9 4 2 2 9 6 5 1 3 w w w u 1 6 3 http://www.xiaoyu163.com...

  • Page 73: Parts List Of Exploded View

    ADV-700 3 7 63 1515 0 Note: The symbols in the column “Remarks” indicate the following destinations. E3: U.S.A./Canada model PARTS LIST OF EXPLODED VIEW E2: Europe model Ref. No. Part No. Part Name Remarks Q'ty Ref. No. Part No.

  • Page 74: Parts List Of Dvd Mechanism Unit

    ADV-700 3 7 63 1515 0 PARTS LIST OF DVD MECHANISM UNIT Ref. No. Part No. Part Name Remarks Q'ty Ref. No. Part No. Part Name Remarks Q'ty 1A 337 0093 016 Mecha unit Ass'y 48 474 4302 002 Screw 3×8 BSS (A)

  • Page 75: Exploded View Of Dvd Mechanism

    ADV-700 EXPLODED VIEW OF DVD MECHANISM 3 7 6 3 1 5 1 5 0 1 3 9 4 2 2 9 6 5 1 3 w w w u 1 6 3...

  • Page 76: Points Of Greasing

    ADV-700 POINTS OF GREASING 3 7 6 3 1 5 1 5 0 1 3 9 4 2 2 9 6 5 1 3 w w w u 1 6 3 http://www.xiaoyu163.com...

  • Page 77: Http://Www.xiaoyu163.Com

    ADV-700 3 7 63 1515 0 PACKING VIEW L 13942296513 Note: The symbols in the column “Remarks” indicate the following destinations. E3: U.S.A./Canada model PARTS LIST OF PACKING & ACCESSORIES E2: Europe model Ref. No. Part No. Part Name...

  • Page 78: Wiring Diagram

    ADV-700 WIRING DIAGRAM 3 7 6 3 1 5 1 5 0 1U-3359-2 DISPLAY UNIT OPT UNIT TUNER PACK H/P UNIT 1U-3359-1 1U-3359-7 CX102(PH) CY271(FFC P=1.25) CX271(FFC P=1.25) CX211(FFC P=1.25) CY211(FFC P=1.25) DVD-Y INTREC_IN (27) INTREC_IN GND A1 V.GND...

  • Page 79: Measuring Method And Waveforms

    ADV-700 3 7 63 1515 0 MEASURING METHOD AND WAVEFORMS To check the waveforms on the Servo P.W.B., the GND ( ) probe of the oscilloscope to Vref point. (Except for Inner SW, TRVSW) NOTES Measuring Disc: DVD/DVDT-S01 CD/TCD-784 (It is better to use wires for extending between the probe and test points.)
  • Page 80 ADV-700 WAVE FORMS 3 7 63 1515 0 DVD PLAY (INNER) DVD PLAY DVDT-S01 HF (RFI) Vref V = 0.5 V/div CD PLAY (INNER) CD PLAY TCD-784A HF (RFI) Vref V = 0.5 V/div SERCH TO OUTER CHAPTER (DVD/CD) LOADING...
  • Page 81 http://www.xiaoyu163.com SCHEMATIC DIAGRAMS(1/8) 3 7 6 3 1 5 1 5 0 1 3 9 4 2 2 9 6 5 1 3 + B LINE SIGNAL LINE w w w WARNING NOTICE u 1 6 3 Parts marked with this symbol have critical characteristics.
  • Page 82 http://www.xiaoyu163.com SCHEMATIC DIAGRAMS(1/8) 3 7 6 3 1 5 1 5 0 1 3 9 4 2 2 9 6 5 1 3 + B LINE SIGNAL LINE w w w WARNING NOTICE u 1 6 3 Parts marked with this symbol have critical characteristics.

  • Page 83: Schematic Diagrams

    http://www.xiaoyu163.com 3 7 6 3 1 5 1 5 0 SCHEMATIC DIAGRAMS(1/8) L 1 3 9 4 2 2 9 6 5 1 3 u 1 6 3 http://www.xiaoyu163.com...
  • Page 84 http://www.xiaoyu163.com 3 7 6 3 1 5 1 5 0 L 1 3 9 4 2 2 9 6 5 1 3 u 1 6 3 http://www.xiaoyu163.com...
  • Page 85 http://www.xiaoyu163.com 3 7 6 3 1 5 1 5 0 L 1 3 9 4 2 2 9 6 5 1 3 NOTICE ALL RESISTANCE VALUES IN OHM. k=1,000 OHM M=1,000,000 ALL CAPACITANCE VALUES IN MICRO FARAD. P=MICRO-MICR EACH VOLTAGE AND CURRENT ARE MEASUERD AT MO SIGN CONDITION.

  • Page 86: (1/8) Gu-3333-1 Dvd Main Unit (1/2)

    http://www.xiaoyu163.com 3 7 6 3 1 5 1 5 0 L 1 3 9 4 2 2 9 6 5 1 3 + B LINE SIGNAL LINE WARNING Parts marked with this symbol have critical characteristics. ,000,000 OHM Use ONLY replacement parts recommended by the manufacture. RO-MICRO FARAD MO SIGNAL INPUT CAUTION:...

  • Page 87: Gu-3333-1 Dvd Main Unit (2/2)

    http://www.xiaoyu163.com SCHEMATIC DIAGRAMS(2/8) 3 7 6 3 1 5 1 5 0 1 3 9 4 2 2 9 6 5 1 3 + B LINE - B LINE SIGNAL LINE w w w WARNING NOTICE u 1 6 3 Parts marked with this symbol have critical characteristics.
  • Page 88 http://www.xiaoyu163.com SCHEMATIC DIAGRAMS(2/8) 3 7 6 3 1 5 1 5 0 1 3 9 4 2 2 9 6 5 1 3 + B LINE - B LINE SIGNAL LINE w w w WARNING NOTICE u 1 6 3 Parts marked with this symbol have critical characteristics.
  • Page 89 http://www.xiaoyu163.com 3 7 6 3 1 5 1 5 0 SCHEMATIC DIAGRAMS(2/8) L 1 3 9 4 2 2 9 6 5 1 3 u 1 6 3 http://www.xiaoyu163.com...
  • Page 90 http://www.xiaoyu163.com 3 7 6 3 1 5 1 5 0 L 1 3 9 4 2 2 9 6 5 1 3 u 1 6 3 http://www.xiaoyu163.com...
  • Page 91 http://www.xiaoyu163.com 3 7 6 3 1 5 1 5 0 L 1 3 9 4 2 2 9 6 5 1 3 NOTICE ALL RESISTANCE VALUES IN OHM. k=1,000 ALL CAPACITANCE VALUES IN MICRO FARA EACH VOLTAGE AND CURRENT ARE MEAS CONDITION.

  • Page 92: (2/8) Gu-3333-1 Dvd Main Unit (2/2)

    http://www.xiaoyu163.com 3 7 6 3 1 5 1 5 0 L 1 3 9 4 2 2 9 6 5 1 3 + B LINE - B LINE SIGNAL LINE WARNING Parts marked with this symbol have critical characteristics. k=1,000 OHM M=1,000,000 OHM Use ONLY replacement parts recommended by the manufacture.
  • Page 93 http://www.xiaoyu163.com SCHEMATIC DIAGRAMS(3/8) 3 7 6 3 1 5 1 5 0 1 3 9 4 2 2 9 6 5 1 3 + B LINE - B LINE SIGNAL LINE NOTICE WARNING w w w Parts marked with this symbol have critical characteristics.
  • Page 94 http://www.xiaoyu163.com SCHEMATIC DIAGRAMS(3/8) 3 7 6 3 1 5 1 5 0 1 3 9 4 2 2 9 6 5 1 3 + B LINE - B LINE SIGNAL LINE NOTICE WARNING w w w Parts marked with this symbol have critical characteristics.
  • Page 95 http://www.xiaoyu163.com 3 7 6 3 1 5 1 5 0 SCHEMATIC DIAGRAMS(3/8) L 1 3 9 4 2 2 9 6 5 1 3 u 1 6 3 http://www.xiaoyu163.com...
  • Page 96 http://www.xiaoyu163.com 3 7 6 3 1 5 1 5 0 L 1 3 9 4 2 2 9 6 5 1 3 u 1 6 3 http://www.xiaoyu163.com...
  • Page 97 http://www.xiaoyu163.com 3 7 6 3 1 5 1 5 0 L 1 3 9 4 2 2 9 6 5 1 3 NOTICE ALL RESISTANCE VALUES IN OHM. k=1,00 ALL CAPACITANCE VALUES IN MICRO FAR EACH VOLTAGE AND CURRENT ARE MEA CONDITION.

  • Page 98: (3/8) 1U-3358-1 Main Unit (1/2)

    http://www.xiaoyu163.com 3 7 6 3 1 5 1 5 0 L 1 3 9 4 2 2 9 6 5 1 3 + B LINE - B LINE SIGNAL LINE WARNING Parts marked with this symbol have critical characteristics. M. k=1,000 OHM M=1,000,000 OHM Use ONLY replacement parts recommended by the manufacture.
  • Page 99 http://www.xiaoyu163.com SCHEMATIC DIAGRAMS(4/8) 3 7 6 3 1 5 1 5 0 1 3 9 4 2 2 9 6 5 1 3 WARNING: NOTICE Parts marked with this symbol have critical characteristics. ALL RESISTANCE VALUES IN OHM. k=1,000 OHM M=1,000,000 OHM Use ONLY replacement parts recommended by the manufacture.
  • Page 100 http://www.xiaoyu163.com SCHEMATIC DIAGRAMS(4/8) 3 7 6 3 1 5 1 5 0 1 3 9 4 2 2 9 6 5 1 3 WARNING: NOTICE Parts marked with this symbol have critical characteristics. ALL RESISTANCE VALUES IN OHM. k=1,000 OHM M=1,000,000 OHM Use ONLY replacement parts recommended by the manufacture.
  • Page 101 http://www.xiaoyu163.com 3 7 6 3 1 5 1 5 0 SCHEMATIC DIAGRAMS(4/8) L 1 3 9 4 2 2 9 6 5 1 3 u 1 6 3 http://www.xiaoyu163.com...
  • Page 102 http://www.xiaoyu163.com 3 7 6 3 1 5 1 5 0 L 1 3 9 4 2 2 9 6 5 1 3 u 1 6 3 http://www.xiaoyu163.com...
  • Page 103 http://www.xiaoyu163.com 3 7 6 3 1 5 1 5 0 L 1 3 9 4 2 2 9 6 5 1 3 NOTICE ALL RESISTANCE VALUES IN OHM. k=1,000 OHM M=1,000,000 OHM ALL CAPACITANCE VALUES IN MICRO FARAD. P=MICRO-MICRO FARAD EACH VOLTAGE AND CURRENT ARE MEASUERD AT MO SIGNAL INPUT CONDITION.

  • Page 104: 3358-2 Reg Unit

    http://www.xiaoyu163.com 3 7 6 3 1 5 1 5 0 L 1 3 9 4 2 2 9 6 5 1 3 WARNING: Parts marked with this symbol have critical characteristics. Use ONLY replacement parts recommended by the manufacture. CAUTION: Before returning the unit to the customer, make sure you make either (1) a leakage current check or (2) a line to chassis resistance check.
  • Page 105 http://www.xiaoyu163.com SCHEMATIC DIAGRAMS(5/8) 3 7 6 3 1 5 1 5 0 1 3 9 4 2 2 9 6 5 1 3 + B LINE SIGNAL LINE WARNING: NOTICE w w w Parts marked with this symbol have critical characteristics. ALL RESISTANCE VALUES IN OHM.
  • Page 106 http://www.xiaoyu163.com SCHEMATIC DIAGRAMS(5/8) 3 7 6 3 1 5 1 5 0 1 3 9 4 2 2 9 6 5 1 3 + B LINE SIGNAL LINE WARNING: NOTICE w w w Parts marked with this symbol have critical characteristics. ALL RESISTANCE VALUES IN OHM.
  • Page 107 http://www.xiaoyu163.com 3 7 6 3 1 5 1 5 0 SCHEMATIC DIAGRAMS(5/8) L 1 3 9 4 2 2 9 6 5 1 3 u 1 6 3 http://www.xiaoyu163.com...
  • Page 108 http://www.xiaoyu163.com 3 7 6 3 1 5 1 5 0 L 1 3 9 4 2 2 9 6 5 1 3 u 1 6 3 http://www.xiaoyu163.com...
  • Page 109 http://www.xiaoyu163.com 3 7 6 3 1 5 1 5 0 L 1 3 9 4 2 2 9 6 5 1 3 NOTICE ALL RESISTANCE VALUES IN OHM. k=1,0 ALL CAPACITANCE VALUES IN MICRO FA EACH VOLTAGE AND CURRENT ARE ME CONDITION.

  • Page 110: (5/8) 1U-3359-3 Video Unit

    http://www.xiaoyu163.com 3 7 6 3 1 5 1 5 0 L 1 3 9 4 2 2 9 6 5 1 3 + B LINE SIGNAL LINE WARNING: Parts marked with this symbol have critical characteristics. HM. k=1,000 OHM M=1,000,000 OHM Use ONLY replacement parts recommended by the manufacture.
  • Page 111 http://www.xiaoyu163.com SCHEMATIC DIAGRAMS(6/8) 3 7 6 3 1 5 1 5 0 1 3 9 4 2 2 9 6 5 1 3 WARNING: Parts marked with this symbol have critical characteristics. Use ONLY replacement parts recommended by the manufacture. CAUTION: Before returning the unit to the customer, make sure you make either (1) a leakage current check or (2) a line to chassis resistance check.
  • Page 112 http://www.xiaoyu163.com SCHEMATIC DIAGRAMS(6/8) 3 7 6 3 1 5 1 5 0 1 3 9 4 2 2 9 6 5 1 3 WARNING: Parts marked with this symbol have critical characteristics. Use ONLY replacement parts recommended by the manufacture. CAUTION: Before returning the unit to the customer, make sure you make either (1) a leakage current check or (2) a line to chassis resistance check.
  • Page 113 http://www.xiaoyu163.com 3 7 6 3 1 5 1 5 0 SCHEMATIC DIAGRAMS(6/8) L 1 3 9 4 2 2 9 6 5 1 3 u 1 6 3 http://www.xiaoyu163.com...
  • Page 114 http://www.xiaoyu163.com 3 7 6 3 1 5 1 5 0 L 1 3 9 4 2 2 9 6 5 1 3 u 1 6 3 http://www.xiaoyu163.com...
  • Page 115 http://www.xiaoyu163.com 3 7 6 3 1 5 1 5 0 L 1 3 9 4 2 2 9 6 5 1 3 u 1 6 3 http://www.xiaoyu163.com...

  • Page 116: (6/8) 1U-3359-1 Display Unit

    http://www.xiaoyu163.com 3 7 6 3 1 5 1 5 0 WARNING: Parts marked with this symbol have critical characteristics. Use ONLY replacement parts recommended by the manufacture. CAUTION: Before returning the unit to the customer, make sure you make either (1) a leakage current check or (2) a line to chassis resistance check.

  • Page 117: Dsp Unit (1/2)

    http://www.xiaoyu163.com SCHEMATIC DIAGRAMS(7/8) 3 7 6 3 1 5 1 5 0 1 3 9 4 2 2 9 6 5 1 3 + B LINE - B LINE SIGNAL LINE w w w WARNING: NOTICE u 1 6 3 Parts marked with this symbol have critical characteristics.
  • Page 118 http://www.xiaoyu163.com SCHEMATIC DIAGRAMS(7/8) 3 7 6 3 1 5 1 5 0 1 3 9 4 2 2 9 6 5 1 3 + B LINE - B LINE SIGNAL LINE w w w WARNING: NOTICE u 1 6 3 Parts marked with this symbol have critical characteristics.
  • Page 119 http://www.xiaoyu163.com 3 7 6 3 1 5 1 5 0 SCHEMATIC DIAGRAMS(7/8) L 1 3 9 4 2 2 9 6 5 1 3 u 1 6 3 http://www.xiaoyu163.com...
  • Page 120 http://www.xiaoyu163.com 3 7 6 3 1 5 1 5 0 L 1 3 9 4 2 2 9 6 5 1 3 u 1 6 3 http://www.xiaoyu163.com...
  • Page 121 http://www.xiaoyu163.com 3 7 6 3 1 5 1 5 0 L 1 3 9 4 2 2 9 6 5 1 3 NOTICE ALL RESISTANCE VALUES IN OHM. k=1,000 ALL CAPACITANCE VALUES IN MICRO FARA EACH VOLTAGE AND CURRENT ARE MEAS CONDITION.
  • Page 122 http://www.xiaoyu163.com 3 7 6 3 1 5 1 5 0 L 1 3 9 4 2 2 9 6 5 1 3 + B LINE - B LINE SIGNAL LINE WARNING: Parts marked with this symbol have critical characteristics. k=1,000 OHM M=1,000,000 OHM Use ONLY replacement parts recommended by the manufacture.
  • Page 123 http://www.xiaoyu163.com SCHEMATIC DIAGRAMS(8/8) 3 7 6 3 1 5 1 5 0 1 3 9 4 2 2 9 6 5 1 3 NOTICE ALL RESISTANCE VALUES IN OHM. k=1,000 OHM M=1,000,000 OHM ALL CAPACITANCE VALUES IN MICRO FARAD. P=MICRO-MICRO FARAD EACH VOLTAGE AND CURRENT ARE MEASUERD AT MO SIGNAL INPUT CONDITION.
  • Page 124 http://www.xiaoyu163.com SCHEMATIC DIAGRAMS(8/8) 3 7 6 3 1 5 1 5 0 1 3 9 4 2 2 9 6 5 1 3 NOTICE ALL RESISTANCE VALUES IN OHM. k=1,000 OHM M=1,000,000 OHM ALL CAPACITANCE VALUES IN MICRO FARAD. P=MICRO-MICRO FARAD EACH VOLTAGE AND CURRENT ARE MEASUERD AT MO SIGNAL INPUT CONDITION.
  • Page 125 http://www.xiaoyu163.com 3 7 6 3 1 5 1 5 0 SCHEMATIC DIAGRAMS(8/8) L 1 3 9 4 2 2 9 6 5 1 3 u 1 6 3 http://www.xiaoyu163.com...
  • Page 126 http://www.xiaoyu163.com 3 7 6 3 1 5 1 5 0 L 1 3 9 4 2 2 9 6 5 1 3 u 1 6 3 http://www.xiaoyu163.com...
  • Page 127 http://www.xiaoyu163.com 3 7 6 3 1 5 1 5 0 NOTICE ALL RESISTANCE VALUES IN OHM. k=1,000 OHM M=1,000,000 OHM ALL CAPACITANCE VALUES IN MICRO FARAD. P=MICRO-MICRO FARAD EACH VOLTAGE AND CURRENT ARE MEASUERD AT MO SIGNAL INPUT CONDITION. CIRCUIT AND PARTS ARE SUBJECT TO CHANGE WITHOUT PRIOR NOTICE.
  • Page 128 http://www.xiaoyu163.com 3 7 6 3 1 5 1 5 0 L 1 3 9 4 2 2 9 6 5 1 3 + B LINE - B LINE SIGNAL LINE SCHEMATIC DIAGRAMS(8/8) u 1 6 3 1U-3360 DSP UNIT (2/2) http://www.xiaoyu163.com...

Table of Contents
