- Page 1 30cm Self Adjusting Hand Push Lawnmower WEH30 193873001 Operator’s Manual & Parts List Please read & understand this manual, paying particular attention to the safety instructions, before use. 6 Nov 2015...
-
Page 3: Table Of Contents
TROUBLE SHOOTING PARTS DIAGRAM & LIST WARRANTY DECLARATION OF CONFORMITY For Spares or Support of your Webb product, please contact us: Tel: 01793 333212 (Mon – Fri 8.30am to 5.00pm) Email: customerservice@webblawnmowers.co.uk To view the full range or find out more information go to... -
Page 4: Specifications
INSTRUCTION MANUAL SPECIFICATIONS Model WEH30 Product Number 193873001 Height of Cut 10mm-40mm No. of Cutting Heights Number of Blades Collector Capacity 17 ltr Blade Material Hardened Steel Overall Dimensions (mm) H-670, W-490, L-520 Weight N.W 9.1kg - G.W 9.85kg The manufacturer reserves the right to change product specification and livery according... -
Page 5: Safety Instructions
Wear foot protection or sensible shoes or working with the cutting cylinder. when using the lawnmower SHARP ROTATING BLADES Model WEH30 Product Number 193873001 Keep all bystanders & animals at least 6 Height of Cut 10mm-40mm... - Page 6 INSTRUCTION MANUAL INSPECT YOUR MACHINE Check all bolts, nuts, and screws for ghtness before each use, especially those securing guards and drive mechanisms. Vibra on during use may cause these to loosen. Replace damaged, missing or failed parts before using. Warning labels carry important informa Replace any missing or damaged warning labels.
-
Page 7: Maintenance & Storage
MAINTENANCE & STORAGE WARNING Improper maintenance & storage of the machine may void your warranty. Keep the machine clean for better and safer performance. MAINTENANCE Before each use, check all nuts & bolts to be sure they are sufficiently tightened. We recommend only manufacturer original parts are used when maintaining this machine. - Page 8 INSTRUCTION MANUAL Top Handle Centre Handle Lower Handle Grass Collector Rear Rollers Cutting Cylinder Height Adjuster...
-
Page 9: Assembly
ASSEMBLY It is recommended that think gardening gloves are worn, when unpacking, adjusting, assembling and maintaining the lawnmower. Remove the Mixer and contents from the carton. Be sure the carton is empty before discarding. If you require any assistance with regards to the contents of the lawnmower contact us: Tel: 01793 333212 - Mon –... - Page 10 INSTRUCTION MANUAL STEP 2 – FITTING THE GRASS COLLECTOR 1. To fit the grass collector to your lawnmower, position the grass catcher onto the front protection cover. STEP 3 – ADJUSTING THE CUTTING HEIGHT The lawnmower can be set to any cutting height, between 10mm & 40mm. Depending on the height of the grass you are cutting;...
-
Page 11: Trouble Shooting
Wear gloves to protect hands cylinder & cutter bar. from blades and remove material. The cut is uneven? The blade may be damaged Visit your local Webb dealer to have the blade inspected. Height adjustment required Adjust to suitable even height. - Page 12 PARTS DIAGRAM...
- Page 13 RTS LIST...
-
Page 14: Ec Declaration Of Conformity
EC DECLARATION OF CONFORMITY We Handy Distribution Ltd - SN3 5HY (Importer) declare that the product: Designation: Hand Push Lawn Mower Model(s): WEH30 Type/Serial No. As per rating label on machine Complies with the following directives: Machinery Directive as last amended by EEC directive 2006/42/EC Annex... - Page 15 NOTES...
- Page 16 NOTES...
- Page 17 NOTES...
- Page 18 INSTRUCTION MANUAL This Service Book is provided with your Webb, to help you look after your purchase to our recommendations and enable you to take advantage of the 2 year manufacturer domestic warranty*. * Commercial/Professional & Hire users receive a 90 day warranty Present this service book to your authorised Webb repair dealer, whenever a service or a warranty appraisal is required.
- Page 19 SERVICE BOOK 1. Users Statement of Warranty Each new machine is warranted against defective material or assembly of material under normal usage. The warranty applies to the original purchaser, is not transferable and covers faulty parts and the labour involved in replacing and repairing those parts, which are of original manufacture.
- Page 20 It is the owner’s responsibility to ensure that their Webb machine is maintained at specific intervals. Any approved Webb service dealer can undertake a service, which are specialised in our products and will be aware of your particular machine and any technical updates which will save valuable time &...
- Page 21 SERVICE BOOK Your servicing Webb approved dealer will stamp & date the below relevant sections, when the correct service actions have been completed. PLEASE ENSURE THE SERVICE BOOK IS AVAILABLE FOR THE DEALER, DURING SERVICE WORK. 12 Months Date 24 Months...
- Page 22 INSTRUCTION MANUAL 48 Months 60 Months Date Date 72 Months 84 Months Date Date 96 Months 108 Months Date Date 120 Months 132 Months Date Date...
-
Page 23: Warranty Registration
& services we provide, including information that we believe is relevant to your and/or your machine. We value your trust by giving us this information about yourself and we are committed to protecting your privacy. From time to time Webb, its associated companies, authorised dealers or third parties working on our behalf may wish to contact you regarding our products, services, offers, technical improvements or just opinions, which may be used for marketing, research or analysis purposes. - Page 24 Webb Lawnmowers Murdock Road Dorcan Swindon Wiltshire SN3 5HY...
