ECS3510-28F
Installation Guide
28-Port Fast Ethernet
Fiber Access Switch
www.edge-core.com

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the ECS3510-28F and is the answer not in the manual?

Questions and answers

Related Manuals for Edge-Core ECS3510-28F

Summary of Contents for Edge-Core ECS3510-28F

  • Page 1 ECS3510-28F Installation Guide 28-Port Fast Ethernet Fiber Access Switch www.edge-core.com...
  • Page 3 NSTALLATION UIDE ECS3510-28F F THERNET IBER CCESS WITCH Layer 2 Switch with 24 100BASE-FX Single-fiber Ports, and 4 Combination Gigabit (RJ-45/SFP) Ports ECS3510-28F E062010-CS-R01 150200000112A...

  • Page 5: Compliances And Safety Statements

    OMPLIANCES AND AFETY TATEMENTS FCC - C LASS This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference when the equipment is operated in a commercial environment.
  • Page 6 OMPLIANCES AND AFETY TATEMENTS CE M (EEC) ECLARATION OF ONFORMANCE FOR AFETY This information technology equipment complies with the requirements of the Council Directive 89/336/EEC on the Approximation of the laws of the Member States relating to Electromagnetic Compatibility and 73/23/EEC for electrical equipment used within certain voltage limits and the Amendment Directive 93/ 68/EEC.
  • Page 7 OMPLIANCES AND AFETY TATEMENTS AFETY OMPLIANCE Warning: Fiber Optic Port Safety When using a fiber optic port, never look at the transmit laser while it is powered on. Also, never look directly at the fiber TX port and fiber CLASS I cable ends when they are powered on.
  • Page 8 OMPLIANCES AND AFETY TATEMENTS OWER AFETY Please read the following safety information carefully before installing the switch: Installation and removal of the unit must be carried out by qualified WARNING: personnel only. The unit must be connected to an earthed (grounded) outlet to comply with ◆...
  • Page 9 OMPLIANCES AND AFETY TATEMENTS Power Cord Set U.S.A. and Canada The cord set must be UL-approved and CSA certified. The minimum specifications for the flexible cord are: - No. 18 AWG - not longer than 2 meters, or 16 AWG. - Type SV or SJ - 3-conductor The cord set must have a rated current capacity of at least 10 A...
  • Page 10 OMPLIANCES AND AFETY TATEMENTS La prise secteur doit se trouver à proximité de l’appareil et son accès doit ◆ être facile. Vous ne pouvez mettre l’appareil hors circuit qu’en débranchant son cordon électrique au niveau de cette prise. L’appareil fonctionne à une tension extrêmement basse de sécurité qui est ◆...
  • Page 11 OMPLIANCES AND AFETY TATEMENTS Bitte unbedingt vor dem Einbauen des Switches die folgenden Sicherheitsanweisungen durchlesen: Die Installation und der Ausbau des Geräts darf nur durch WARNUNG: Fachpersonal erfolgen. Das Gerät sollte nicht an eine ungeerdete Wechselstromsteckdose ◆ angeschlossen werden. Das Gerät muß an eine geerdete Steckdose angeschlossen werden, welche ◆...
  • Page 12 OMPLIANCES AND AFETY TATEMENTS ARNINGS AND AUTIONARY ESSAGES This product does not contain any serviceable user parts. ARNING Installation and removal of the unit must be carried out by ARNING qualified personnel only. When connecting this device to a power outlet, connect the ARNING field ground lead on the tri-pole power plug to a valid earth ground line to prevent electrical hazards.

  • Page 13: C Ompliances And S Afety S Tatements

    OMPLIANCES AND AFETY TATEMENTS ND OF RODUCT This product is manufactured in such a way as to allow for the recovery and disposal of all included electrical components once the product has reached the end of its life. ANUFACTURING ATERIALS There are no hazardous nor ozone-depleting materials in this product.
  • Page 14 OMPLIANCES AND AFETY TATEMENTS – 14 –...

  • Page 15: About This Guide

    BOUT UIDE URPOSE This guide details the hardware features of the switch, including the physical and performance-related characteristics, and how to install the switch. UDIENCE The guide is intended for use by network administrators who are responsible for installing and setting up network equipment; consequently, it assumes a basic working knowledge of LANs (Local Area Networks).
  • Page 16 BOUT UIDE EVISION ISTORY This section summarizes the changes in each revision of this guide. 2010 R EVISION This is the first revision of this guide. – 16 –...

  • Page 17: Table Of Contents

    ONTENTS OMPLIANCES AND AFETY TATEMENTS BOUT UIDE ONTENTS ABLES IGURES NTRODUCTION Overview Description of Hardware ETWORK LANNING Fiber-To-The-Home (FTTH) Application Examples Application Notes NSTALLING THE WITCH Selecting a Site Ethernet Cabling Equipment Checklist Mounting Installing an Optional SFP Transceiver Connecting to a Power Source Connecting to the Console Port AKING ETWORK...
  • Page 18 ONTENTS Connectivity Rules Cable Labeling and Connection Records ROUBLESHOOTING Diagnosing Switch Indicators Power and Cooling Problems Installation In-Band Access ABLES Twisted-Pair Cable and Pin Assignments Fiber Standards PECIFICATIONS Physical Characteristics Switch Features Management Features Standards Compliances LOSSARY NDEX – 18 –...

  • Page 19: Tables

    ABLES Table 1: 100 Mbps SC Port Status LEDs (1~24) Table 2: 1000 Mbps Combination RJ-45/SFP Ports Status LEDs (25~28) 27 Table 3: System Status LEDs Table 4: Serial Converter Wiring Table 5: Maximum 1000BASE-T Gigabit Ethernet Cable Length Table 6: Maximum 1000BASE-SX Gigabit Ethernet Cable Lengths Table 7: Maximum 1000BASE-LX Gigabit Ethernet Cable Length...
  • Page 20 ABLES – 20 –...

  • Page 21: Figures

    IGURES Figure 1: Front Panel Figure 2: Rear Panel Figure 3: Port LEDs Figure 4: Power Supply Sockets Figure 5: Downlink Fiber Connections Figure 6: Uplink SFP Connections Figure 7: RJ-45 Connections Figure 8: Attaching the Brackets Figure 9: Installing the Switch in a Rack Figure 10: Attaching the Adhesive Feet Figure 11:...
  • Page 22 IGURES – 22 –...

  • Page 23: Introduction

    NTRODUCTION VERVIEW The ECS3510-28F is an intelligent Layer 2 switch designed for delivering Fiber- To-The-Home (FTTH) for high-speed Internet access. Deployed at the service provider’s central office (CO), the switch supports up to 24 subscribers through 100BASE-FX single-fiber downlink connections to remote CPEs (customer premises equipment).

  • Page 24: Description Of Hardware

    | Introduction HAPTER Description of Hardware WITCH RCHITECTURE The switch employs a wire-speed, non-blocking switching fabric. This permits simultaneous wire-speed transport of multiple packets at low latency on all ports. The switch also features full-duplex capability on all ports, which effectively doubles the bandwidth of each connection.
  • Page 25 | Introduction HAPTER Description of Hardware auto-negotiation of flow control, so the switch can automatically prevent port buffers from becoming saturated. RJ-45 P ORTS The switch contains four combination RJ-45 ports that operate at 10 Mbps or 100 Mbps, half or full duplex, or at 1000 Mbps, full duplex. They are shared with SFP ports 25~28.

  • Page 26: Figure 3: Port Leds

    | Introduction HAPTER Description of Hardware SFP 1000BX20D ◆ SFP 1000BX10 ◆ SFP 1000BX10D ◆ For information on the recommended standards for fiber optic cabling, see “1000 Mbps Gigabit Ethernet Collision Domain” on page ONSOLE An RJ-45 serial console port is provided on the switch front panel for a connection to a console device through a straight-through UTP or STP Ethernet cable and an RJ-45-to-DB-9 converter.

  • Page 27: Table 1: 100 Mbps Sc Port Status Leds (1~24)

    | Introduction HAPTER Description of Hardware Table 1: 100 Mbps SC Port Status LEDs (1~24) Condition Status Link/Act On/Flashing Green Port has established a valid 100 Mbps network connection. Flashing indicates activity. There is no valid link on the port. Table 2: 1000 Mbps Combination RJ-45/SFP Ports Status LEDs (25~28) Condition Status...

  • Page 28: Figure 4: Power Supply Sockets

    | Introduction HAPTER Description of Hardware OWER UPPLY OCKETS There are two power sockets located on the rear panel of the switch. The standard power socket is for the AC power cord. The socket labeled “RPU” is for the optional Redundant Power Unit (RPU). Figure 4: Power Supply Sockets –...

  • Page 29: Network Planning

    The ECS3510-28F and CPE provide an ideal FTTH system, allowing a service provider to extend an Ethernet connection over optical fiber directly to a subscriber.

  • Page 30: Application Examples

    Application Examples PPLICATION XAMPLES The ECS3510-28F switch is designed to offer a cost-effective solution for FTTH, providing downlink fiber connections to subscribers and high-bandwidth twisted- pair uplink connections to core switches and routers at the CO. Some basic connection configurations are described in the following pages.

  • Page 31: Figure 6: Uplink Sfp Connections

    The figure below illustrates the ECS3510-28F connecting to a core switch with UTP cable. Figure 6: Uplink SFP Connections...

  • Page 32: Application Notes

    | Network Planning HAPTER Application Notes PPLICATION OTES Full-duplex operation only applies to point-to-point access (such as when a switch is attached to a workstation, server or another switch). When the switch is connected to a hub, both devices must operate in half-duplex mode.

  • Page 33: Installing The Switch

    NSTALLING THE WITCH ELECTING A Switch units can be mounted in a standard 19-inch equipment rack or on a flat surface. Be sure to follow the guidelines below when choosing a location. The site should: ◆ be at the center of all the devices you want to link and near a power ■...

  • Page 34: Ethernet Cabling

    | Installing the Switch HAPTER Ethernet Cabling THERNET ABLING To ensure proper operation when installing the switch into a network, make sure that the current cables are suitable for 10BASE-T, 100BASE-TX or 1000BASE-T operation. Check the following criteria against the current installation of your network: Cable type: Unshielded twisted pair (UTP) or shielded twisted pair (STP) ◆...

  • Page 35: Equipment Checklist

    After unpacking this switch, check the contents to be sure you have received all the components. Then, before beginning the installation, be sure you have all other necessary installation equipment. ACKAGE ONTENTS Fast Ethernet Fiber Access Switch (ECS3510-28F) ◆ Power Cord—either US, Continental Europe or UK ◆ Four adhesive foot pads ◆...

  • Page 36: Mounting

    | Installing the Switch HAPTER Mounting OUNTING This switch can be mounted in a standard 19-inch equipment rack or on a desktop or shelf. Mounting instructions for each type of site follow. OUNTING Before rack mounting the switch, pay particular attention to the following factors: Temperature: Since the temperature within a rack assembly may be higher ◆...

  • Page 37: Figure 8: Attaching The Brackets

    | Installing the Switch HAPTER Mounting Figure 8: Attaching the Brackets Mount the device in the rack, using the four 12-24 rack-mounting screws in the Rack-Mounting Kit. Be sure to secure the lower rack-mounting screws first to prevent the brackets being bent by the weight of the switch. Figure 9: Installing the Switch in a Rack If installing a single switch only, turn to “Connecting to a Power Source”...

  • Page 38: Figure 10: Attaching The Adhesive Feet

    | Installing the Switch HAPTER Mounting If also installing an RPU, mount it in the rack below the other devices. ESKTOP OR HELF OUNTING The switch includes four pre-installed rubber feet for desktop or shelf mounting. To mount devices on a horizontal surface, follow these steps: Attach the four adhesive feet to the bottom of the first switch.

  • Page 39: Installing An Optional Sfp Transceiver

    | Installing the Switch HAPTER Installing an Optional SFP Transceiver SFP T NSTALLING AN PTIONAL RANSCEIVER The SFP slots support the following optional SFP transceivers: 1000BASE-SX ◆ 1000BASE-LX ◆ 1000BASE-LH ◆ 1000BASE-LHX ◆ 1000BASE-ZX ◆ 1000BASE-BX20 ◆ 1000BASE-BX10 ◆ Figure 11: Inserting an SFP Transceiver into a Slot To install an SFP transceiver, follow these steps: Consider network and cabling requirements to select an appropriate SFP transceiver type.

  • Page 40: Connecting To A Power Source

    | Installing the Switch HAPTER Connecting to a Power Source Slide the SFP transceiver into the slot until it clicks into place. SFP transceivers are hot-swappable. The switch does not need to be powered off before installing or removing a transceiver. However, always first disconnect the network cable before removing a transceiver.

  • Page 41: Connecting To The Console Port

    | Installing the Switch HAPTER Connecting to the Console Port ONNECTING TO THE ONSOLE This port is used to connect a console device to the switch through a straight- through UTP cable and an RJ-45-to-DB-9 serial converter. The console device can be a PC or workstation running a VT-100 terminal emulator, or a VT-100 terminal.
  • Page 42 | Installing the Switch HAPTER Connecting to the Console Port The serial port’s configuration requirements are as follows: Default Baud rate—115,200 bps ◆ Character Size—8 Characters ◆ Parity—None ◆ Stop bit—One ◆ Data bits—8 ◆ Flow control—none ◆ – 42 –...

  • Page 43: Making Network Connections

    AKING ETWORK ONNECTIONS The ECS3510-28F switch is designed to provide high-speed Internet access to individual subscribers through its 100BASE-FX single-fiber downlink connections. Four combination 1000BASE-T/SFP ports provide the uplink connection from the switch to other switches or routers at the central office.

  • Page 44: Figure 14: Making Twisted-Pair Connections

    | Making Network Connections HAPTER Twisted-Pair Devices ONNECTING TO WITCHES Attach one end of a twisted-pair cable segment to the device’s RJ-45 connector. Figure 14: Making Twisted-Pair Connections Attach the other end to an available port on the switch. Make sure each twisted pair cable does not exceed 100 meters (328 ft) in length.

  • Page 45: Fiber Optic Devices

    | Making Network Connections HAPTER Fiber Optic Devices IBER PTIC EVICES Each single-fiber SC connector on the switch’s front panel connects directly to a CPE at the subscriber’s premises. The switch’s single-fiber ports require one strand of 9/125 micron single-mode fiber optic cable with an SC connector at the switch end.

  • Page 46: Figure 15: Making Sc Port Fiber Connections

    | Making Network Connections HAPTER Fiber Optic Devices Connect fiber devices to the switch. For connections to the CPE, connect one end of the cable to the SC port on the switch and the other end to the CPE at the subscriber’s premises.

  • Page 47: Connectivity Rules

    | Making Network Connections HAPTER Connectivity Rules As a connection is made, check the Link LED on the switch corresponding to the port to be sure that the connection is valid. The 100BASE-FX fiber optic ports operate at 100 Mbps, full duplex. You can run each single-mode fiber link up to a maximum of 15 kilometers from the central office.

  • Page 48: Table 6: Maximum 1000Base-Sx Gigabit Ethernet Cable Lengths

    | Making Network Connections HAPTER Connectivity Rules Table 6: Maximum 1000BASE-SX Gigabit Ethernet Cable Lengths Fiber Size Fiber Bandwidth Maximum Cable Length Connector 62.5/125 micron 160 MHz/km 2-220 m (7-722 ft) multimode fiber 200 MHz/km 2-275 m (7-902 ft) 50/125 micron 400 MHz/km 2-500 m (7-1641 ft) multimode fiber...

  • Page 49: Table 11: Maximum 1000Base-Bx20 Gigabit Ethernet Cable Length

    | Making Network Connections HAPTER Connectivity Rules Table 11: Maximum 1000BASE-BX20 Gigabit Ethernet Cable Length Fiber Size Fiber Bandwidth Maximum Cable Length Connector 9/125 micron single- 2 m - 20 km mode fiber (7 ft - 12.4 miles) Table 12: Maximum 1000BASE-BX10 Gigabit Ethernet Cable Length Fiber Size Fiber Bandwidth Maximum Cable Length...

  • Page 50: Cable Labeling And Connection Records

    | Making Network Connections HAPTER Cable Labeling and Connection Records ABLE ABELING AND ONNECTION ECORDS When planning a network installation, it is essential to label the opposing ends of cables and to record where each cable is connected. Doing so will enable you to easily locate inter-connected devices, isolate faults and change your topology without need for unnecessary time consumption.

  • Page 51: Diagnosing Switch Indicators

    ROUBLESHOOTING IAGNOSING WITCH NDICATORS Table 15: Troubleshooting Chart Symptom Action Power LED is Off ◆ Check connections between the switch, the power cord and the wall outlet. ◆ Contact your dealer for assistance. Power LED is on ◆ Power cycle the switch to try and clear the condition. Amber ◆...

  • Page 52: Troubleshooting

    | Troubleshooting PPENDIX Power and Cooling Problems OWER AND OOLING ROBLEMS If the power indicator does not turn on when the power cord is plugged in, you may have a problem with the power outlet, power cord, or internal power supply.

  • Page 53: Cables

    ABLES WISTED ABLE AND SSIGNMENTS For 10/100BASE-TX connections, the twisted-pair cable must have two pairs of wires. For 1000BASE-T connections the twisted-pair cable must have four pairs of wires. Each wire pair is identified by two different colors. For example, one wire might be green and the other, green with white stripes.

  • Page 54: Table 16: 10/100Base-Tx Mdi And Mdi-X Port Pinouts

    | Cables PPENDIX Twisted-Pair Cable and Pin Assignments 10BASE-T/100BASE-TX P SSIGNMENTS Use unshielded twisted-pair (UTP) or shielded twisted-pair (STP) cable for RJ-45 connections: 100-ohm Category 3 or better cable for 10 Mbps connections, or 100-ohm Category 5 or better cable for 100 Mbps connections. Also be sure that the length of any twisted-pair connection does not exceed 100 meters (328 feet).

  • Page 55: Figure 18: Straight-Through Wiring

    | Cables PPENDIX Twisted-Pair Cable and Pin Assignments Figure 18: Straight-through Wiring EIA/TIA 568B RJ-45 Wiring Standard 10/100BASE-TX Straight-through Cable White/Orange Stripe Orange White/Green Stripe End A End B Blue White/Blue Stripe Green White/Brown Stripe Brown ROSSOVER IRING If the twisted-pair cable is to join two ports and either both ports are labeled with an “X”...

  • Page 56: Table 17: 1000Base-T Mdi And Mdi-X Port Pinouts

    | Cables PPENDIX Twisted-Pair Cable and Pin Assignments 1000BASE-T P SSIGNMENTS All 1000BASE-T ports support automatic MDI/MDI-X operation, so you can use straight-through cables for all network connections to PCs or servers, or to other switches or hubs. The table below shows the 1000BASE-T MDI and MDI-X port pinouts. These ports require that all four pairs of wires be connected.

  • Page 57: Fiber Standards

    | Cables PPENDIX Fiber Standards 1000BASE-T DJUSTING XISTING ATEGORY ABLING TO If your existing Category 5 installation does not meet one of the test parameters for 1000BASE-T, there are basically three measures that can be applied to try and correct the problem: Replace any Category 5 patch cables with high-performance Category 5e or Category 6 cables.
  • Page 58 | Cables PPENDIX Fiber Standards Table 18: Fiber Standards (Continued) ITU-T Description Application Standard G.654 1550-nm Loss-Minimized Fiber Extended long-haul applications. Optimized for high-power Single-mode, 9/125-micron core transmission in the 1500 to 1600-nm region, with low loss in the 1550-nm band.

  • Page 59: Specifications

    PECIFICATIONS HYSICAL HARACTERISTICS ORTS 24 100BASE-FX, single-fiber single-mode 4 10/100/1000BASE-T, shared with four SFP transceiver slots ETWORK NTERFACE Ports 1~24: single fiber SC connector 100BASE-FX: 9/125 micron single-mode fiber cable Shared Ports 25~28: RJ-45 connector, auto MDI/X 10BASE-T: RJ-45 (100-ohm, UTP cable; Category 3 or better) 100BASE-TX: RJ-45 (100-ohm, UTP cable;...
  • Page 60 | Specifications PPENDIX Physical Characteristics EIGHT 4.2 kg (9.26 lbs) (W x D x H): 440 x 324 x 43 mm (17.32 x 12.76 x 1.69 inches) EMPERATURE Operating: 0°C to 50°C (32°F to 122°F) Storage: -40°C to 70°C (-40°F to 158°F) UMIDITY Operating: 5% to 95% (non-condensing) AC I...

  • Page 61: Switch Features

    | Specifications PPENDIX Switch Features WITCH EATURES ORWARDING Store-and-forward HROUGHPUT Wire speed ONTROL Full Duplex: IEEE 802.3x Half Duplex: Back pressure ANAGEMENT EATURES ANAGEMENT SSH, Telnet, SNMP, or HTTP ANAGEMENT RS-232 RJ-45 console port OFTWARE OADING HTTP, TFTP in-band – 61 –...

  • Page 62: Standards

    | Specifications PPENDIX Standards TANDARDS IEEE 802.3-2005 Ethernet, Fast Ethernet, Gigabit Ethernet Full-duplex flow control Link Aggregation Control Protocol IEEE 802.1D -2004 Spanning Tree Protocol Rapid Spanning Tree Protocol Multiple Spanning Tree Protocol ISO/IEC 8802-3 OMPLIANCES MISSIONS EN55022 (CISPR 22) Class A EN 61000-3-2/3 FCC Class A CE Mark...

  • Page 63: Glossary

    LOSSARY 10BASE-T IEEE 802.3 specification for 10 Mbps Ethernet over two pairs of Category 3, 4, or 5 UTP cable. 100BASE-TX IEEE 802.3u specification for 100 Mbps Ethernet over two pairs of Category 5 UTP cable. 1000BASE-LH Specification for long-haul Gigabit Ethernet over two strands of 9/125 micron core fiber cable.
  • Page 64 LOSSARY ANDWIDTH The difference between the highest and lowest frequencies available for network signals. Also synonymous with wire speed, the actual speed of the data transmission along the cable. OLLISION OMAIN Single CSMA/CD LAN segment. CSMA/CD CSMA/CD (Carrier Sense Multiple Access/Collision Detect) is the communication method employed by Ethernet, Fast Ethernet, and Gigabit Ethernet.
  • Page 65 LOSSARY IEEE Institute of Electrical and Electronic Engineers. IEEE 802.3 Defines carrier sense multiple access with collision detection (CSMA/CD) access method and physical layer specifications. IEEE 802.3 Defines CSMA/CD access method and physical layer specifications for 1000BASE-T Gigabit Ethernet. (Now incorporated in IEEE 802.3-2005.) IEEE 802.3 Defines CSMA/CD access method and physical layer specifications for 100BASE- TX Fast Ethernet.
  • Page 66 LOSSARY (MAC) EDIA CCESS ONTROL A portion of the networking protocol that governs access to the transmission medium, facilitating the exchange of data between network nodes. An acronym for Management Information Base. It is a set of database objects that contains information about the device. ODAL ANDWIDTH Bandwidth for multimode fiber is referred to as modal bandwidth because it...
  • Page 67 LOSSARY (UDP) ATAGRAM ROTOCOL provides a datagram mode for packet-switched communications. It uses IP as the underlying transport mechanism to provide access to IP-like services. UDP packets are delivered just like IP packets – connection-less datagrams that may be discarded before reaching their targets. UDP is useful when TCP would be too complex, too slow, or just unnecessary.
  • Page 68 LOSSARY – 68 –...

  • Page 69: Index

    NDEX UMERICS 10 Mbps connectivity rules electrical interference, avoiding 100 Mbps connectivity rules equipment checklist 1000 Mbps connectivity rules Ethernet connectivity rules 1000BASE-LH fiber cable Lengths examples, connections 1000BASE-LX fiber cable Lengths 1000BASE-SX fiber cable Lengths 1000BASE-T pin assignments Fast Ethernet connectivity rules ports features 100BASE-TX, cable lengths...
  • Page 70 NDEX mounting the switch in a rack Telnet on a desktop or shelf troubleshooting multimode fiber optic cables in-band access power and cooling problems twisted-pair connections network connections examples web-based management out-of-band management package contents pin assignments 1000BASE-T 10BASE-T/100BASE-TX console port ports, connecting to power, connecting to rack mounting...
  • Page 72 ECS3510-28F E062010-CS-R01 150200000112A...
