Intel
®
Server Board S2600KP Product Family
Intel
®
Compute Module HNS2600KP Product Family
Intel
®
Server Chassis H2000G Product Family
Spares/Accessories List and Configuration Guide
A reference guide to assist with ordering parts and accessories available to configure an Intel sever system based on the Intel
Server Board S2600KP Product Family.
Revision 2.0
December 2015
Intel® Server Boards and Systems
®

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the S2600KP and is the answer not in the manual?

Questions and answers

Related Manuals for Intel S2600KP

Summary of Contents for Intel S2600KP

  • Page 1 ® Server Chassis H2000G Product Family Spares/Accessories List and Configuration Guide A reference guide to assist with ordering parts and accessories available to configure an Intel sever system based on the Intel ® Server Board S2600KP Product Family. Revision 2.0 December 2015 Intel®...
  • Page 2 Intel® Server S2600KP Product Family Configuration Guide and Spares/Accessories List Document Revision History Date-Published Revision Revision-Change-Description May 13 Rev. 0.1 Initial release for Alpha Nov. 13 Rev. 0.61 Update product code name Dec. 13 Rev. 0.62 Update some description Jan. 14 Rev.
  • Page 3 Current characterized errata are available on request. Intel, Intel Xeon, Pentium, and the Intel logo are trademarks or registered trademarks of Intel Corporation or its subsidiaries in the United States and other countries.

  • Page 4: Table Of Contents

    Intel® Server S2600KP Product Family Configuration Guide and Spares/Accessories List Table of Contents INTEL® SERVER FAMILY OVERVIEW ........................................... 1 ..........................................4 RODUCT AMILY UMMARY HART SERVER BUILDING BLOCK CONFIGURATION ......................................1 ® S S2600KP P ..................................2 NTEL ERVER OARD...
  • Page 5 Table 3. Compute Module Product Family Summary ................................4 Table 4. Server Chassis & Server System Product Family Summary ..........................4 Table 5. Intel® Server Board S2600KP Product Family SKUs ............................. 2 Table 6. Intel® Server Compute Module HNS2600KP Product Family SKUs ....................... 3 Table 7.
  • Page 6 Intel® Server S2600KP Product Family Configuration Guide and Spares/Accessories List Intel® Server Family Overview This document is provided to assist Intel customers with identifying the right Intel® server system and available accessories, enabling them to create a unique server platform that meets their unique server requirements.

  • Page 7: Table 1. Product Family Reference Collaterals

    Intel ® Server System H2000G Product Family Technical Product Specification  Intel® Remote Management Module 4 (Intel® RMM4) and Integrated BMC User Guide  Intel® Remote Management Module 4 Technical Product Specification For in-depth technical information about this product ...
  • Page 8 Intel® Server S2600KP Product Family Configuration Guide and Spares/Accessories List Figure 1. Intel® Compute Module HNS2600KP Feature Set Identification...

  • Page 9: Table 2. Server Board Product Family Summary

    Figure 2. Intel® Server Chassis H2000G Feature Set Identification Product Family Summary Chart The Intel® S2600KP product family is built around either of two Intel® Server Board S2600KP options: BBS2600KP and BBS2600KPF. The feature set of each server board option is identical except for the integrated InfiniBand*.
  • Page 10 Yes – Option included KDK – Knock Down Kit – Intel PCSD term for chassis only product BIK – Server Board in KDK – Intel PCSD term for integrated (L6) system product L6 – Integrated system with no processors, memory, or storage devices...

  • Page 11: Intel® Server Family Overview

    Server Building Block Configuration Server building blocks are offered to give Intel customers the option to configure and assemble a unique server system from the bare chassis up. Each building block component and optional accessory is purchased seperately. At a minimum, building up a functional server system using building blocks will require the following: ...

  • Page 12: Intel® Server Board S2600Kp Product Family Skus

    ® SAS module option Un-packaged Net Weight Box includes: one server board 12.8 Kgs, 28.2 Lbs NOTE: All necessary mounting hardware, cabling, and shielding will ship with the Intel chassis and optional accessory kits. Intel ® Server Board BBS2600KPF iPC – BBS2600KPF ...

  • Page 13: Intel® Compute Module Hns2000Kp Product Family Skus

    Intel® Server S2600KP Product Family Configuration Guide and Spares/Accessories List Intel® Compute Module HNS2000KP Product Family SKUs Table 6. Intel® Server Compute Module HNS2600KP Product Family SKUs Intel Product Code Order Information Product Description Product Type (iPC) Intel ® Compute Module HNS2600KP...

  • Page 14: Product Family Summary Chart

    In an effort to provide the complete product bill of materials, the ship along components list in each product table will include items identified by description and by iPN (Intel Part Number). The iPN information is provided for reference only. These components are not orderable as a spare or accessory.

  • Page 15: Ipc - H2216Xxkr2

    Intel® Server S2600KP Product Family Configuration Guide and Spares/Accessories List NOTE: The rail kit only supports specific rack type with 3/8” square and 7.1mm round holes (1) – Power Supply Bay blank insert (8) – DIMM slot blanks – iPN H43597-00x (2) –...

  • Page 16: Server System Configuration Options

    Intel® Server S2600KP Product Family Configuration Guide and Spares/Accessories List Server System Configuration Options Locking Front Bezel Accessory Kit The Front Bezel is made of back molede plastic and uses a snap-on design. When installed, its design allows for maximum airflow to maintain system cooling requirments.

  • Page 17: Intel® I/O Expansion Modules

    Figure 4. Installing the Snap-on to the Front Bezel Intel® I/O Expansion Modules The Intel® S2600KP product family includes supports for a number of optional Intel® I/O Module that install proprietary connectors on the server board leaving available PCIe* add-in cards slot available for other add-in cards options.
  • Page 18 Intel® Server S2600KP Product Family Configuration Guide and Spares/Accessories List Intel Product Code Order Information Product Description Product Type Intel® I/O Modules AXXKPTPIOM iPC –AXXKPTPIOM PCI Express x16 (200 pin) rIOM riser and rIOM carrier board kit for supporting Intel ®...
  • Page 19 Intel® Server S2600KP Product Family Configuration Guide and Spares/Accessories List Intel Product Code Order Information Product Description Product Type Dual Port Intel® 82599EB 10GbE I/O Module iPC - AXX10GBNIAIOM MM# - 917905 Dual SFP+ port 10GbE IO module based on Intel ®...
  • Page 20 Intel® Server S2600KP Product Family Configuration Guide and Spares/Accessories List Intel Product Code Order Information Product Description Product Type iPC - AXX4P1GBPWLIOM Quad Port Intel® I350-AE4 GbE I/O Module Quad-port 1GbE IO Module based on Intel ® Ethernet Controller I350...

  • Page 21: Intel® Sas Bridge Board Options

    The Intel® S2600KP product family include support for the latest generation of 12Gb/s SAS Intel® RAID add-in cards, modules, expanders, and accessories. Previous 6Gb/s Intel RAID cards can also be supported. See the published Tested Hardware and OS List for a full list of validated Intel RAID cards.

  • Page 22: Intel® Raid Controller Add-In Cards - Sas 3.0 (12Gb/S)

    Intel® Server S2600KP Product Family Configuration Guide and Spares/Accessories List 3.4.1 Intel® RAID Controller Add-in Cards – SAS 3.0 (12Gb/s) Table 11. List of Intel® RAID Controller Add-in Cards – SAS 3.0 (12Gb/s) Intel Product Code Order Information Product Description Product Type Intel®...

  • Page 23: 3.4.2 Intel® Raid Accessoried Options

    EAN - 5032037033640 MOQ - 5 iPC - AXXRPFKSSD2 Intel® RAID SSD Cache with Fast Path *I/O Upgrade Key to enable SSD Cache with Fast path I/O for Intel’s MM# - 915316 RAID RS25 family of ROC products. UPC - 735858221467 ...

  • Page 24: Rack Mount Kits

    Rack Mount kits The Intel® S2600KP provides the upgrade option to the rack mount kits. CAUTION: Exeeding the rail kit’s specified maximum weight limit or misalignment of the server in the rack may result in failure of the rack rails, resulting in damage to the systems or personal injury.

  • Page 25: Miscellaneous Accessory Options

    Intel® Server S2600KP Product Family Configuration Guide and Spares/Accessories List Miscellaneous Accessory Options Table 14. List of Miscellaneous Accessory Options Intel Product Code Order Information Product Description Product Type iPC - AXXRMM4LITE MM# - 911660 UPC - 735858219297  Activation key for advanced management features...

  • Page 26: Spare And Replacement Parts (Frus)

    Intel® Server S2600KP Product Family Configuration Guide and Spares/Accessories List Spare and Replacement Parts (FRUs) Table 15. List of Spare and Replacement Parts Intel Product Code Order Information Product Description Product Type MM# – 935565 PCI Express Riser FHW1U16RISER2 (Slot 1) iPC –FHW1U16RISER2...
  • Page 27 Intel® Server S2600KP Product Family Configuration Guide and Spares/Accessories List Intel Product Code Order Information Product Description Product Type iPC - FXX1600PCRPS 1600W Common Redundant Power Supply FXX1600PCRPS (Platinum-Efficiency) MM# - 915606 1600W AC Common Redundant Power Supply UPC - 735858243650 FXX1600PCRPS 80Plus Platinum-Efficiency ...
  • Page 28 Intel® Server S2600KP Product Family Configuration Guide and Spares/Accessories List Intel Product Code Order Information Product Description Product Type iPC - FXX4056DRFAN2 MM# - 935566 UPC - 735858288439 40x56mm Dual Rotor Fan spare  Spare FRU EAN - 5032037067751 MOQ - 1...
  • Page 29 Intel® Server S2600KP Product Family Configuration Guide and Spares/Accessories List Intel Product Code Order Information Product Description Product Type iPC - FXX25HSCAR2 MM# - 937542 UPC - 735858289405 Spare 2.5” HDD hot swap carriers  Spare FRU EAN - 5032037068383...

  • Page 30: Extended Warranty

    Image Oder Infromation Description iPC - SVCEWHWSY MM# - 923113 Extended Warranty for complete system (1x Intel® Server Chassis H2000G + 4x Intel® Compute Module HNS2600KP), Single MOQ - 1 iPC - SVCEWHWB MM# - 914905 Extended Warranty for single node (1x Intel® Compute Module HNS2600KP), Single...

  • Page 31: Table 17. A List Of Acronyms And Terms Used Throughout This Document

    Intel® Server S2600KP Product Family Configuration Guide and Spares/Accessories List Glossary of Terms Table 17. A list of Acronyms and Terms used throughout this document Acronym or Term Definition Acronym or Term Definition Baseboard In Knock-Down-Kit – Integrated QSFP Quad Small Form factor Pluggable...
