Airwell DAF009 Service Manual

Yif series
Hide thumbs
Table of Contents

Advertisement

Quick Links

DAF009
DAF012
DAF018
DAF024
DAF030
DAF036
DAF042
DAF060
REFRIGERANT
SM YIFSER 2-A.1 GB
Version:2
YIF series
Indoor Units
FAF012
FAF018
FAF024
FAF030
FAF036
FAF042
R410A
CAF012
CAF018
CAF024
CAF030
CAF036
CAF042
JAN - 2012
Outdoor Units
YIF009
YIF012
YIF018
YIF024
YIF030
YIF036
YIF036T
YIF042T
YIF060T
HEAT PUMP

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the DAF009 and is the answer not in the manual?

Questions and answers

Related Manuals for Airwell DAF009

Summary of Contents for Airwell DAF009

  • Page 1 YIF series Indoor Units Outdoor Units DAF009 YIF009 DAF012 FAF012 CAF012 YIF012 DAF018 FAF018 CAF018 YIF018 DAF024 FAF024 CAF024 YIF024 DAF030 FAF030 CAF030 YIF030 YIF036 DAF036 FAF036 CAF036 YIF036T DAF042 FAF042 CAF042 YIF042T DAF060 YIF060T REFRIGERANT R410A HEAT PUMP JAN - 2012 SM YIFSER 2-A.1 GB...
  • Page 2 LIST OF EFFECTIVE PAGES LIST OF EFFECTIVE PAGES Note: Changes in the pages are indicated by a “Revision#” in the footer of each effected page (when none indicates no changes in the relevant page). All pages in the following list represent effected/ non effected pages divided by chapters.

  • Page 3: Table Of Contents

    TABLE OF CONTENTS Table of Contents INTRODUCTION ..........................1-1 PRODUCT DATA SHEET....................... 2-1 RATING CONDITIONS ........................3-1 OUTLINE DIMENSION ........................4-1 PERFORMANCE DATA ......................... 5-1 AIRFLOW CURVES........................6-1 SOUND LEVEL CHARACTERISTICS ................... 7-1 ELECTRICAL DATA........................8-1 WIRING DIAGRAM......................... 9-1 REFRIGERATION DIAGRAMS ...................... 10-1 TUBING CONNECTIONS .......................

  • Page 5: Introduction

    9kBtu/h to 60kBtu/h which matching following indoors, as follows: IDU: Ducted(8 Models): DAF009 DAF012 DAF018 DAF024 DAF030 DAF036 DAF042 DAF060 Floor/Ceiling(4 Models): FAF012 FAF018 FAF024 FAF030 FAF036 FAF042 Cassette(6 Models): CAF012 CAF018 CAF024 CAF030 CAF036 CAF042...
  • Page 6 INTRODUCTION Indoor Unit The indoor unit is calling mounted, and can be easily fitted to many types of residential and commercials applications. It is major designed for light commercial air-conditioning needs. It includes: • Coil with hydrophilic aluminum fins. • Advanced electronic control box assembly •...
  • Page 7 INTRODUCTION Accessories RCW Wall Mounted Remote Control The RCW remote control is mounted on the wall, and controls the unit either as an infrared remote control or as a wired controller. The wired remote control with larger LCD display provides the following functions •...
  • Page 8 INTRODUCTION 1.10 Matching Table INDOOR UNITS OUTDOOR DAF009 DAF012 DAF018 DAF024 DAF030 DAF036 DAF042 DAF060 UNITS CAF012 CAF018 CAF024 CAF030 CAF036 CAF042 FAF012 FAF018 FAF024 FAF030 FAF036 FAF042 √ YIF009 √ YIF012 √ YIF018 √ YIF024 √ YIF030 √ YIF036 √...

  • Page 9: Product Data Sheet

    PRODUCT DATASHEET PRODUCT DATA SHEET DAF009 / YIF009 R410A PRELIMINARY PRODUCT DATA SHEET Model Indoor Unit DAF009 Model Outdoor Unit YIF009 Installation Method of Pipe ducted Characteristics Units Cooling Heating Btu/hr 8870 9720 Capacity (4) 2.85 Power input (4) 1.00 0.97...
  • Page 10 PRODUCT DATASHEET DAF012 / YIF012 R410A PRELIMINARY PRODUCT DATA SHEET Model Indoor Unit DAF012 Model Outdoor Unit YIF012 Installation Method of Pipe ducted Characteristics Units Cooling Heating Btu/hr 11940 12280 Capacity (4) Power input (4) EER (Cooling) or COP(Heating) (4) 2.91 3.27 Energy efficiency class...
  • Page 11 PRODUCT DATASHEET DAF018 / YIF018 R410A PRELIMINARY PRODUCT DATA SHEET Model Indoor Unit DAF018 Model Outdoor Unit YIF018 Installation Method of Pipe ducted Characteristics Units Cooling Heating Btu/hr 17060 19450 Capacity (4) Power input (4) EER (Cooling) or COP(Heating) (4) 2.38 3.16 Energy efficiency class...
  • Page 12 PRODUCT DATASHEET DAF024 / YIF024 R410A PRELIMINARY PRODUCT DATA SHEET Model Indoor Unit DAF024 Model Outdoor Unit YIF024 Installation Method of Pipe ducted Characteristics Units Cooling Heating Btu/hr 23880 27300 Capacity (4) Power input (4) 2.66 2.51 EER (Cooling) or COP(Heating) (4) 2.63 3.18 Energy efficiency class...
  • Page 13 PRODUCT DATASHEET DAF030 / YIF030 R410A PRELIMINARY PRODUCT DATA SHEET Model Indoor Unit DAF030 Model Outdoor Unit YIF030 Installation Method of Pipe ducted Characteristics Units Cooling Heating Btu/hr 28320 31050 Capacity (4) Power input (4) 3.00 3..00 EER (Cooling) or COP(Heating) (4) 2.76 3.03 Energy efficiency class...
  • Page 14 PRODUCT DATASHEET DAF036 / YIF036 R410A PRELIMINARY PRODUCT DATA SHEET Model Indoor Unit DAF036 Model Outdoor Unit YIF036 Installation Method of Pipe ducted Characteristics Units Cooling Heating Btu/hr 34120 37530 Capacity (4) 10.0 11.0 Power input (4) 4.00 3.50 EER (Cooling) or COP(Heating) (4) 2.50 3.14 Energy efficiency class...
  • Page 15 PRODUCT DATASHEET DAF036 / YIF036T R410A PRELIMINARY PRODUCT DATA SHEET Model Indoor Unit DAF036 Model Outdoor Unit YIF036T Installation Method of Pipe ducted Characteristics Units Cooling Heating Btu/hr 34120 37530 Capacity (4) 10.0 11.0 Power input (4) 4.00 3.50 EER (Cooling) or COP(Heating) (4) 2.50 3.14 Energy efficiency class...
  • Page 16 PRODUCT DATASHEET DAF042 / YIF042 R410A PRELIMINARY PRODUCT DATA SHEET Model Indoor Unit DAF042 Model Outdoor Unit YIF042T Installation Method of Pipe ducted Characteristics Units Cooling Heating Btu/hr 40940 47770 Capacity (4) 12.0 14.0 Power input (4) EER (Cooling) or COP(Heating) (4) 2.26 2.85 Energy efficiency class...
  • Page 17 PRODUCT DATASHEET DAF060 / YIF060 R410A PRELIMINARY PRODUCT DATA SHEET Model Indoor Unit DAF060 Model Outdoor Unit YIF060T Installation Method of Pipe ducted Characteristics Units Cooling Heating Btu/hr 54590 63120 Capacity (4) 16.0 18.5 Power input (4) EER (Cooling) or COP(Heating) (4) 2.46 3.36 Energy efficiency class...
  • Page 18 PRODUCT DATASHEET 2.10 FAF012 / YIF012 R410A PRELIMINARY PRODUCT DATA SHEET Model Indoor Unit FAF012 Model Outdoor Unit YIF012 Installation Method of Pipe Floor / Ceiling Characteristics Units Cooling Heating Btu/hr 11940 12280 Capacity (4) Power input (4) 1.17 1.10 EER (Cooling) or COP(Heating) (4) 2.99 3.27...
  • Page 19 PRODUCT DATASHEET 2.11 FAF018 / YIF018 R410A PRELIMINARY PRODUCT DATA SHEET Model Indoor Unit FAF018 Model Outdoor Unit YIF018 Installation Method of Pipe Floor / Ceiling Characteristics Units Cooling Heating Btu/hr 17060 19450 Capacity (4) Power input (4) 2.03 2.07 EER (Cooling) or COP(Heating) (4) Energy efficiency class 1.10...
  • Page 20 PRODUCT DATASHEET 2.12 FAF024 / YIF024 R410A PRELIMINARY PRODUCT DATA SHEET Model Indoor Unit FAF024 Model Outdoor Unit YIF024 Installation Method of Pipe Floor / Ceiling Characteristics Units Cooling Heating Btu/hr 23880 27300 Capacity (4) Power input (4) 2.61 2.59 EER (Cooling) or COP(Heating) (4) 2.68 3.08...
  • Page 21 PRODUCT DATASHEET 2.13 FAF030 / YIF030 R410A PRELIMINARY PRODUCT DATA SHEET Model Indoor Unit FAF030 Model Outdoor Unit YIF030 Installation Method of Pipe Floor / Ceiling Characteristics Units Cooling Heating Btu/hr 30030 33440 Capacity (4) Power input (4) 3.00 2.85 EER (Cooling) or COP(Heating) (4) 2.93 3.43...
  • Page 22 PRODUCT DATASHEET 2.14 FAF036 / YIF036 R410A PRELIMINARY PRODUCT DATA SHEET Model Indoor Unit FAF036 Model Outdoor Unit YIF036 Installation Method of Pipe Floor / Ceiling Characteristics Units Cooling Heating Btu/hr 34120 37530 Capacity (4) 10.0 11.0 Power input (4) 3.60 3.30 EER (Cooling) or COP(Heating) (4)
  • Page 23 PRODUCT DATASHEET 2.15 FAF036 / YIF036T R410A PRELIMINARY PRODUCT DATA SHEET Model Indoor Unit FAF036 Model Outdoor Unit YIF036T Installation Method of Pipe Floor / Ceiling Characteristics Units Cooling Heating Btu/hr 34120 36780 Capacity (4) 10.0 10.78 Power input (4) 3.60 3.30 EER (Cooling) or COP(Heating) (4)
  • Page 24 PRODUCT DATASHEET 2.16 FAF042 / YIF042 R410A PRELIMINARY PRODUCT DATA SHEET Model Indoor Unit FAF042 Model Outdoor Unit YIF042T Installation Method of Pipe Floor / Ceiling Characteristics Units Cooling Heating Btu/hr 40940 47770 Capacity (4) 12.0 14.0 Power input (4) EER (Cooling) or COP(Heating) (4) 2.50 2.97...
  • Page 25 PRODUCT DATASHEET 2.17 CAF012 / YIF012 R410A PRELIMINARY PRODUCT DATA SHEET Model Indoor Unit CAF012 Model Outdoor Unit YIF012 Installation Method of Pipe Flared Characteristics Units Cooling Heating Btu/hr 11940 12280 Capacity (4) Power input (4) 1.17 EER (Cooling) or COP(Heating) (4) 2.99 3.27 Energy efficiency class...
  • Page 26 PRODUCT DATASHEET 2.18 CAF018 / YIF018 R410A PRELIMINARY PRODUCT DATA SHEET Model Indoor Unit CAF018 Model Outdoor Unit YIF018 Installation Method of Pipe Flared Characteristics Units Cooling Heating Btu/hr 17060 19450 Capacity (4) Power input (4) 2.00 1.90 EER (Cooling) or COP(Heating) (4) 2.38 3.16 Energy efficiency class...
  • Page 27 PRODUCT DATASHEET 2.19 CAF024 / YIF024 R410A PRELIMINARY PRODUCT DATA SHEET Model Indoor Unit CAF024 Model Outdoor Unit YIF024 Installation Method of Pipe Flared Characteristics Units Cooling Heating Btu/hr 23200 25590 Capacity (4) Power input (4) 2.62 2.50 EER (Cooling) or COP(Heating) (4) 2.63 3.18 Energy efficiency class...
  • Page 28 PRODUCT DATASHEET 2.20 CAF030 / YIF030 R410A PRELIMINARY PRODUCT DATA SHEET Model Indoor Unit CAF030 Model Outdoor Unit YIF030 Installation Method of Pipe Flared Characteristics Units Cooling Heating Btu/hr 28320 30030 Capacity (4) Power input (4) 2.90 3..15 EER (Cooling) or COP(Heating) (4) 2.86 2.79 Energy efficiency class...
  • Page 29 PRODUCT DATASHEET 2.21 CAF036 / YIF036 R410A PRELIMINARY PRODUCT DATA SHEET Model Indoor Unit CAF036 Model Outdoor Unit YIF036 Installation Method of Pipe Flared Characteristics Units Cooling Heating Btu/hr 34120 37530 Capacity (4) 10.0 11.0 Power input (4) 3.60 3.30 EER (Cooling) or COP(Heating) (4) 2.77 3.33...
  • Page 30 PRODUCT DATASHEET 2.22 CAF036 / YIF036T R410A PRELIMINARY PRODUCT DATA SHEET Model Indoor Unit CAF036 Model Outdoor Unit YIF036T Installation Method of Pipe Flared Characteristics Units Cooling Heating Btu/hr 34120 37530 Capacity (4) 10.0 11.0 Power input (4) 3.60 3.10 EER (Cooling) or COP(Heating) (4) 2.77 3.54...
  • Page 31 PRODUCT DATASHEET 2.23 CAF042 / YIF042 R410A PRELIMINARY PRODUCT DATA SHEET Model Indoor Unit CAF042 Model Outdoor Unit YIF042T Installation Method of Pipe Flared Characteristics Units Cooling Heating Btu/hr 40940 47770 Capacity (4) 12.0 14.0 Power input (4) EER (Cooling) or COP(Heating) (4) 2.50 2.80 Energy efficiency class...

  • Page 33: Rating Conditions

    RATING CONDITIONS RATING CONDITIONS TING CONDITIONS Rating conditions in accordance with ISO 5151 and ISO 13253 (for ducted units). Rating conditions in accordance with ISO 5151 and ISO 13253 (for ducted units). Cooling: Cooling: Indoor: Indoor: C DB 19 C DB 19 C WB C WB Outdoor: 35...

  • Page 35: Outline Dimension

    OUTLINE DIMENSION OUTLINE DIMENSION Indoor Units: DAF009, DAF012, DAF018, DAF024, DAF036, DAF042, DAF060 Unit：mm Model DAF009 DAF012 DAF018 1012 DAF024 1101 1159 1270 1002 DAF030 DAF036 1011 1115 1251 DAF042 DAF060 1015 1115 1251 SM YIF 2-A.1 GB...
  • Page 36 OUTLINE DIMENSION Indoor Units: FAF012, FAF018, FAF024, FAF036, FAF042 Unit: mm Model FAF012/018 1300 1202 FAF024/030 1590 1491 FAF036/042 SM YIF 2-A.1 GB...
  • Page 37 OUTLINE DIMENSION Indoor Units: CAF012, CAF018, CAF024, CAF036, CAF042 Unit: mm Model CAF012 CAF018 CAF024 CAF030 CAF036 CAF042 SM YIF 2-A.1 GB...
  • Page 38 OUTLINE DIMENSION Outdoor Units: YIF009/012/018/024/030/036 SM YIF 2-A.1 GB...
  • Page 39 OUTLINE DIMENSION YIF042/060 Unit：mm Model YIF009 YIF012 YIF018 YIF024 1018 YIF030 YIF036 1018 YIF036T YIF042T 1032 1250 YIF060T SM YIF 2-A.1 GB...

  • Page 41: Performance Data

    PERFORMANCE DATA & PRESSURE CURVES PERFORMANCE DATA YIF009 5.1.1 Cooling Capacity (kW) Entering Air DB Data Entering Air WB/DB ID Coil( OD Coil( 15/21 17/24 19/27 21/29 23/32 2.65 2.81 2.94 3.07 3.17 1.71 1.81 1.91 1.87 1.90 0.71 0.71 0.71 0.72 0.72...
  • Page 42 PERFORMANCE DATA & PRESSURE CURVES ENTERING AIR DB ID COIL( ENTERING WB OD COIL( 1.50 0.78 1.44 0.83 1.38 0.87 1.61 0.80 1.55 0.84 1.50 0.88 1.71 0.81 1.65 0.85 1.60 0.90 2.08 0.84 2.00 0.90 1.91 0.95 2.94 0.91 2.75 1.03 2.85...
  • Page 43 PERFORMANCE DATA & PRESSURE CURVES Discharge Pressure VS.Outdoor Temp 40.0 30.0 20.0 25 C DB 20 C DB 15 C DB 10.0 Outdoor Temp.( C WB) YIF012 5.2.1 Cooling Capacity (kW) Entering Air DB Data Entering Air WB/DB ID Coil( OD Coil( 15/21 17/24...
  • Page 44 PERFORMANCE DATA & PRESSURE CURVES LEGEND – Total Cooling Capacity, kW – Sensible Capacity, kW – Power Input, kW WB – Wet Bulb Temp., ( – Dry Bulb Temp., ( – Indoor – Outdoor 5.2.2 Heating Capacity (kW) ENTERING AIR DB ID COIL( ENTERING WB OD COIL( 1.89...
  • Page 45 PERFORMANCE DATA & PRESSURE CURVES Suction Pressure VS.Outdoor Temp 11.0 15/21(WB/DB) 17/24(WB/DB) 19/27(WB/DB) 21/29(WB/DB) 23/32(WB/DB) Outdoor Temp.( C DB) Heating Discharge Pressure VS.Outdoor Temp 40.0 30.0 20.0 25 C DB 20 C DB 15 C DB 10.0 Outdoor Temp.( C WB) SM YIF 2-A.1 GB...
  • Page 46 PERFORMANCE DATA & PRESSURE CURVES YIF018 5.3.1 Cooling Capacity (kW) Entering Air DB Data Entering Air WB/DB ID Coil( OD Coil( 15/21 17/24 19/27 21/29 23/32 5.10 5.40 5.65 5.90 6.10 3.30 3.50 3.68 3.60 3.66 1.49 1.49 1.50 1.50 1.51 5.05 5.35...
  • Page 47 PERFORMANCE DATA & PRESSURE CURVES 5.1.3 Heating Capacity (kW) ENTERING AIR DB ID COIL( ENTERING WB OD COIL( 2.99 1.44 2.88 1.53 2.76 1.61 3.22 1.48 3.11 1.56 2.99 1.64 3.42 1.49 3.31 1.58 3.19 1.67 4.16 1.57 3.99 1.67 3.82 1.76 5.87...
  • Page 48 PERFORMANCE DATA & PRESSURE CURVES Discharge Pressure VS.Outdoor Temp 40.0 30.0 20.0 25 C DB 20 C DB 15 C DB 10.0 Outdoor Temp.( C WB) YIF024 5.4.1 Cooling Capacity (kW) Entering Air DB Data Entering Air WB/DB ID Coil( OD Coil( 15/21 17/24...
  • Page 49 PERFORMANCE DATA & PRESSURE CURVES LEGEND – Total Cooling Capacity, kW – Sensible Capacity, kW – Power Input, kW WB – Wet Bulb Temp., ( – Dry Bulb Temp., ( – Indoor – Outdoor 5.4.2 Heating Capacity (kW) ENTERING AIR DB ID COIL( ENTERING WB OD COIL( 4.20...
  • Page 50 PERFORMANCE DATA & PRESSURE CURVES Suction Pressure VS.Outdoor Temp 11.0 15/21(WB/DB) 17/24(WB/DB) 19/27(WB/DB) 21/29(WB/DB) 23/32(WB/DB) C DB ) Outdoor Temp.( Heating Discharge Pressure VS.Outdoor Temp 40.0 30.0 20.0 25 C DB 20 C DB 15 C DB 10.0 Outdoor Temp.( C WB) YIF030 5.5.1...
  • Page 51 PERFORMANCE DATA & PRESSURE CURVES Entering Air DB Data Entering Air WB/DB ID Coil( OD Coil( 15/21 17/24 19/27 21/29 23/32 8.47 8.96 9.38 9.79 10.13 5.46 5.79 6.10 5.96 6.06 2.13 2.13 2.14 2.15 2.15 8.38 8.88 9.30 9.71 10.04 5.98 6.35...
  • Page 52 PERFORMANCE DATA & PRESSURE CURVES ENTERING AIR DB ID COIL( ENTERING WB OD COIL( 4.25 2.40 4.09 2.56 3.93 2.69 4.58 2.46 4.41 2.60 4.25 2.74 4.86 2.49 4.70 2.64 4.54 2.79 5.91 2.61 5.67 2.78 5.43 2.94 8.34 2.81 7.82 3.19 8.10...
  • Page 53 PERFORMANCE DATA & PRESSURE CURVES Discharge Pressure VS.Outdoor Temp 40.0 30.0 20.0 25 C DB 20 C DB 15 C DB 10.0 Outdoor Temp.( C WB) YIF036 5.6.1 Cooling Capacity (kW) Entering Air DB Data Entering Air WB/DB ID Coil( OD Coil( 15/21 17/24...
  • Page 54 PERFORMANCE DATA & PRESSURE CURVES LEGEND – Total Cooling Capacity, kW – Sensible Capacity, kW – Power Input, kW WB – Wet Bulb Temp., ( – Dry Bulb Temp., ( – Indoor – Outdoor 5.6.2 Heating Capacity (kW) ENTERING AIR DB ID COIL( ENTERING WB OD COIL( 5.78...
  • Page 55 PERFORMANCE DATA & PRESSURE CURVES Suction Pressure VS.Outdoor Temp 11.0 15/21(WB/DB) 17/24(WB/DB) 19/27(WB/DB) 21/29(WB/DB) 23/32(WB/DB) Outdoor Temp.( C DB) Heating Discharge Pressure VS.Outdoor Temp 40.0 30.0 20.0 25 C DB 20 C DB 15 C DB 10.0 Outdoor Temp.( C WB) YIF042 5.7.1 Cooling Capacity (kW)
  • Page 56 PERFORMANCE DATA & PRESSURE CURVES Entering Air DB Data Entering Air WB/DB ID Coil( OD Coil( 15/21 17/24 19/27 21/29 23/32 12.24 12.96 13.56 14.16 14.64 7.90 8.38 8.83 8.62 8.77 3.76 3.77 3.77 3.79 3.81 12.12 12.84 13.44 14.04 14.52 8.64 9.18...
  • Page 57 PERFORMANCE DATA & PRESSURE CURVES ENTERING AIR DB ID COIL( ENTERING WB OD COIL( 7.35 3.92 7.07 4.17 6.79 4.39 7.91 4.02 7.63 4.24 7.35 4.47 8.40 4.07 8.12 4.31 7.84 4.56 10.22 4.26 9.80 4.53 9.38 4.80 14.42 4.58 13.51 5.20 14.00...
  • Page 58 PERFORMANCE DATA & PRESSURE CURVES Discharge Pressure VS.Outdoor Temp 40.0 30.0 20.0 25 C DB 20 C DB 15 C DB 10.0 Outdoor Temp.( C WB) YIF060 5.8.1 Cooling Capacity (kW) Entering Air DB Data Entering Air WB/DB ID Coil( OD Coil( 15/21 17/24...
  • Page 59 PERFORMANCE DATA & PRESSURE CURVES LEGEND – Total Cooling Capacity, kW – Sensible Capacity, kW – Power Input, kW WB – Wet Bulb Temp., ( – Dry Bulb Temp., ( – Indoor – Outdoor 5.8.2 Heating Capacity (kW) ENTERING AIR DB ID COIL( ENTERING WB OD COIL( 9.71...
  • Page 60 PERFORMANCE DATA & PRESSURE CURVES Suction Pressure VS.Outdoor Temp 11.0 15/21(WB/DB) 17/24(WB/DB) 19/27(WB/DB) 21/29(WB/DB) 23/32(WB/DB) Outdoor Temp.( C DB) Heating Discharge Pressure VS.Outdoor Temp 40.0 30.0 20.0 25 C DB 20 C DB 15 C DB 10.0 Outdoor Temp.( C WB) 5-20 SM YIF 2-A.1 GB...

  • Page 61: Airflow Curves

    AIRFLOW CURVES AIRFLOW CURVES DAF009 Nominal System Curve Max System Curve Airflow Vs. External Static Pressure High speed Medium Speed Performance test Low Speed point at 25 Pa Operating Range Airflow Rate,(m ³/ hr) Model: DAF012 Nominal System Curve Max System Curve Airflow Vs.
  • Page 62 AIRFLOW CURVES Model: DAF018 Nominal System Curve Max System Curve Airflow Vs. External Static Pressure High speed Medium Speed Performance test Low Speed point at 25 Pa Operating Range 1000 1100 Airflow Rate,(m ³/ hr) Model: DAF024 Nominal System Curve Max System Curve Airflow Vs.
  • Page 63 AIRFLOW CURVES Model: DAF030 Nominal System Curve Max System Curve Airflow Vs. External Static Pressure High speed Medium Speed Low Speed Operating Range Performance test point at 37 Pa 1000 1200 1400 1600 Airflow Rate,(m ³/ hr) Model: DAF036 Nominal System Curve Max System Curve Airflow Vs.
  • Page 64 AIRFLOW CURVES Model: DAF042 Nominal System Curve Max System Curve Airflow Vs. External Static Pressure High speed Medium Speed Low Speed Operating Range Performance test point at 37Pa 1000 1200 1400 1600 1800 2000 2200 2400 Airflow Rate,(m ³/ hr) Model: DAF060 Nominal System Curve Max System Curve...

  • Page 65: Sound Level Characteristics

    SOUND LEVEL CHARACTERISTICS SOUND LEVEL CHARACTERISTICS Sound Pressure Level SM YIF 2-A.1 GB...
  • Page 66 SOUND LEVEL CHARACTERISTICS Ducted IDU Sound Pressure Level ( measured as figure 3) DAF 009 Cooling DAF 009 Heating Noise spectrum & NC Curves Noise spectrum & NC Curves NC65 NC65 NC60 NC60 NC55 NC55 NC50 NC50 NC45 NC45 NC40 NC40 NC35 NC35...
  • Page 67 SOUND LEVEL CHARACTERISTICS DAF 018 Cooling DAF 018 Heating Noise spectrum & NC Curves Noise spectrum & NC Curves NC65 NC65 NC60 NC60 NC55 NC55 NC50 NC50 NC45 NC45 NC40 NC40 NC35 NC35 NC30 NC30 NC25 NC25 NC20 NC20 NC15 NC15 1000 2000 4000 8000 1000 2000 4000 8000...
  • Page 68 SOUND LEVEL CHARACTERISTICS DAF 030 Cooling DAF 030 Heating Noise spectrum & NC Curves Noise spectrum & NC Curves NC65 NC65 NC60 NC60 NC55 NC55 NC50 NC50 NC45 NC45 NC40 NC40 NC35 NC35 NC30 NC30 NC25 NC25 NC20 NC20 NC15 NC15 1000 2000...
  • Page 69 SOUND LEVEL CHARACTERISTICS DAF 042 Cooling DAF 042 Heating Noise spectrum & NC Curves Noise spectrum & NC Curves NC65 NC65 NC60 NC60 NC55 NC55 NC50 NC50 NC45 NC45 NC40 NC40 NC35 NC35 NC30 NC30 NC25 NC25 NC20 NC20 NC15 NC15 1000 2000...
  • Page 70 SOUND LEVEL CHARACTERISTICS Cassette IDU Sound Pressure Level ( measured as figure 4) CAF012 Cooling CAF012 Heating Noise spectrum & NC Curves Noise spectrum & NC Curves NC65 NC65 NC60 NC60 NC55 NC55 NC50 NC50 NC45 NC45 NC40 NC40 NC35 NC35 NC30 NC30...
  • Page 71 SOUND LEVEL CHARACTERISTICS CAF024 Cooling CAF024 Heating Noise spectrum & NC Curves Noise spectrum & NC Curves NC65 NC65 NC60 NC60 NC55 NC55 NC50 NC50 NC45 NC45 NC40 NC40 NC35 NC35 NC30 NC30 NC25 NC25 NC20 NC20 NC15 NC15 1000 2000 4000 8000...
  • Page 72 SOUND LEVEL CHARACTERISTICS CAF036 Cooling CAF036Heating Noise spectrum & NC Curves Noise spectrum & NC Curves NC65 NC65 NC60 NC60 NC55 NC55 NC50 NC50 NC45 NC45 NC40 NC40 NC35 NC35 NC30 NC30 NC25 NC25 NC20 NC20 NC15 NC15 1000 2000 4000 8000 1000...
  • Page 73 SOUND LEVEL CHARACTERISTICS Floor Ceiling IDU Sound Pressure Level ( measured as figure 2) FAF012 Cooling FAF012 Heating Noise spectrum & NC Curves Noise spectrum & NC Curves NC65 NC65 NC60 NC60 NC55 NC55 NC50 NC50 NC45 NC45 NC40 NC40 NC35 NC35 NC30...
  • Page 74 SOUND LEVEL CHARACTERISTICS FAF018 Cooling FAF018 Heating Noise spectrum & NC Curves Noise spectrum & NC Curves NC65 NC65 NC60 NC60 NC55 NC55 NC50 NC50 NC45 NC45 NC40 NC40 NC35 NC35 NC30 NC30 NC25 NC25 NC20 NC20 NC15 NC15 1000 2000 4000 8000 1000 2000 4000 8000 Octave Band Center Frequencies [Hz] Octave Band Center Frequencies [Hz]...
  • Page 75 SOUND LEVEL CHARACTERISTICS FAF030 Cooling FAF030 Heating Noise spectrum & NC Curves Noise spectrum & NC Curves NC65 NC65 NC60 NC60 NC55 NC55 NC50 NC50 NC45 NC45 NC40 NC40 NC35 NC35 NC30 NC30 NC25 NC25 NC20 NC20 NC15 NC15 1000 2000 4000 8000...
  • Page 76 SOUND LEVEL CHARACTERISTICS FAF042 Cooling FAF042 Heating Noise spectrum & NC Curves Noise spectrum & NC Curves NC65 NC65 NC60 NC60 NC55 NC55 NC50 NC50 NC45 NC45 NC40 NC40 NC35 NC35 NC30 NC30 NC25 NC25 NC20 NC20 NC15 NC15 1000 2000 4000 8000...
  • Page 77 SOUND LEVEL CHARACTERISTICS Sound Pressure Level Spectrum (Measured as Figure 5) YIF009 Cooling YIF009 Heating Noise spectrum & NC Curves Noise spectrum & NC Curves NC65 NC65 NC60 NC60 NC55 NC55 NC50 NC50 NC45 NC45 NC40 NC40 NC35 NC35 NC30 NC30 NC25 NC25...
  • Page 78 SOUND LEVEL CHARACTERISTICS YIF018 Cooling YIF018 Heating Noise spectrum & NC Curves Noise spectrum & NC Curves NC65 NC65 NC60 NC60 NC55 NC55 NC50 NC50 NC45 NC45 NC40 NC40 NC35 NC35 NC30 NC30 NC25 NC25 NC20 NC20 NC15 NC15 1000 2000 4000 8000 1000 2000 4000 8000 Octave Band Center Frequencies [Hz]...
  • Page 79 SOUND LEVEL CHARACTERISTICS YIF030 Cooling YIF030 Heating Noise spectrum & NC Curves Noise spectrum & NC Curves NC65 NC65 NC60 NC60 NC55 NC55 NC50 NC50 NC45 NC45 NC40 NC40 NC35 NC35 NC30 NC30 NC25 NC25 NC20 NC20 NC15 NC15 1000 2000 4000 8000 1000 2000 4000...
  • Page 80 SOUND LEVEL CHARACTERISTICS YIF036T Cooling YIF036T Heating Noise spectrum & NC Curves Noise spectrum & NC Curves NC65 NC65 NC60 NC60 NC55 NC55 NC50 NC50 NC45 NC45 NC40 NC40 NC35 NC35 NC30 NC30 NC25 NC25 NC20 NC20 NC15 NC15 1000 2000 4000 8000...
  • Page 81 SOUND LEVEL CHARACTERISTICS YIF060 Cooling YIF060 Heating Noise spectrum & NC Curves Noise spectrum & NC Curves NC65 NC65 NC60 NC60 NC55 NC55 NC50 NC50 NC45 NC45 NC40 NC40 NC35 NC35 NC30 NC30 NC25 NC25 NC20 NC20 NC15 NC15 1000 2000 4000 8000...

  • Page 83: Electrical Data

    Indoor units Ducted Power Supply Power Supply Power Supply Circuit Breaker Circuit Breaker Wiring No. X Wiring No. X Model （V，Ph，Hz） Cross Section Cross Section DAF009 220-240，1，50 3 X1.5 DAF012 220-240，1，50 3 X1.5 DAF018 220-240，1，50 3 X1.5 DAF024 220-240，1，50 3 X1.5 DAF030 220-240，1，50...
  • Page 84 ELECTRICAL DATA Outdoor units Power Supply Interconnecting Cable Power Supply Circuit Breaker Wiring No. X Model Model No. X Cross Section （V，Ph，Hz） Cross Section YIF009 220-240，1，50 3 X2.5 2 X0.75 YIF012 220-240，1，50 3 X2.5 2 X0.75 YIF018 220-240，1，50 3 X2.5 2 X0.75 YIF024 220-240，1，50...

  • Page 85: Wiring Diagram

    WIRING DIAGRAM WIRING DIAGRAM Indoor unit 9.1.1 Ducted type: for all models SM YIF 2-A.1 GB...
  • Page 86 WIRING DIAGRAM 9.1.2 Floor ceiling type: for all models SM YIF 2-A.1 GB...
  • Page 87 WIRING DIAGRAM 9.1.3 Cassette type: for CAF012 018 024 9.1.4 Cassette type: for CAF 030 036 042 SM YIF 2-A.1 GB...
  • Page 88 WIRING DIAGRAM Outdoor unit 9.2.1 YIF009 SM YIF 2-A.1 GB...
  • Page 89 WIRING DIAGRAM 9.2.2 YIF012 SM YIF 2-A.1 GB...
  • Page 90 WIRING DIAGRAM 9.2.3 YIF018 SM YIF 2-A.1 GB...
  • Page 91 WIRING DIAGRAM 9.2.4 YIF024 SM YIF 2-A.1 GB...
  • Page 92 WIRING DIAGRAM 9.2.5 YIF030 SM YIF 2-A.1 GB...
  • Page 93 WIRING DIAGRAM 9.2.6 YIF036 SM YIF 2-A.1 GB...
  • Page 94 WIRING DIAGRAM 9.2.7 YIF036T 9-10 SM YIF 2-A.1 GB...
  • Page 95 WIRING DIAGRAM 9.2.8 YIF042 SM YIF 2-A.1 GB 9-11...
  • Page 96 WIRING DIAGRAM 9.2.9 YIF060 9-12 SM YIF 2-A.1 GB...

  • Page 97: Refrigeration Diagrams

    REFRIGERATION DIAGRAMS REFRIGERATION DIAGRAMS 10.1 Cooling and Dry Mode 10.2 Heating Mode SM YIF 2-A.1 GB 10-1...

  • Page 99: Tubing Connections

    TUBING CONNECTIONS TUBING CONNECTIONS When the outdoor unit is installed above the indoor unit, an oil trap is required every 5m along the suction line at the lowest point of the riser. In case the indoor unit is installed above the outdoor, no trap is required.

  • Page 101: Control System

    CONTROL SYSTEM CONTROL SYSTEM 12.1 OPERATION FLOWCHART Cooling/Dry Operation Power Unit start and running at cool or dry mode Indoor fan run Satisfying open Comp. condition Comp. and outdoor fan run Temp of indoor ≤ Set temp Comp. and outdoor fan stop Comp.
  • Page 102 CONTROL SYSTEM Heating Operation 12.2 MAIN LOGIC 12-2 SM YIF 2-A.1 GB...
  • Page 103 CONTROL SYSTEM 12.2.1 Cooling Mode When RAT≥SPT +1℃, the unit begins cooling operation, the compressor and the outdoor fan are running, the indoor fan is running at a set speed. When RAT ≤SPT -1℃, the unit is in the cooling idl e state, the compressor and the outdoor fan stop running, the indoor fan is running at a set speed.
  • Page 104 CONTROL SYSTEM When RAT≤SPT-2℃, the unit is in the cooling shutdown state, the compressor and the outdoor fan stop running. When SPT-2℃＜RAT＜SPT+2℃, the unit is in the six-minute stop and four-minute operation state, at is, the compressor runs for 6 minutes and then stops for 4 minutes, in such cycle repeatedly; and the indoor fan operates at a l ow speed.
  • Page 105 CONTROL SYSTEM 12.3 Protections 12.3.1 Indoor Coil Defrost Protection When the unit has been running for refrigeration or dehumidification for a period and the ICT< -2 , the unit will repo rt a fault and stops the compressor and the ℃...
  • Page 106 CONTROL SYSTEM After the compressor is started, if the overload switch of the compressor is detected to shut off, the fault is reported. All loads (except for the four way valve) are shut off, the fault is displayed, and the compressor will stop for 3 minutes.

  • Page 107: Troubleshooting

    TROUBLESHOOTING TROUBLESHOOTING 13.1 TROUBLE TABLE Trouble Origin of Trouble Name Control Description Code Trouble Signal If water full protection continues for 2 hours and fails to restore, it is Pump Failure Pump believed that the water pump is at fault and all loads are shut off and fail to restore automatically.
  • Page 108 TROUBLESHOOTING Trouble Origin of Trouble Name Control Description Code Trouble Signal will restore. Otherwise, the fault is displayed. When outdoor unit is energized and fails to receive data of indoor unit within 30 seconds, an indoor unit communication fault is reported.

  • Page 109: Flow Chart Of Troubleshooting

    TROUBLESHOOTING Trouble Origin of Trouble Name Control Description Code Trouble Signal mode, only the fault is displayed and the indoor unit is running normally. The fault display disappears when the fault is removed. When OCT failure is detected for continuous 5 seconds, in cool and dry mode, the system will be shut off.
  • Page 110 TROUBLESHOOTING Service personnel shall collect the malfunction information as much as possible and research them thoroughly, list these electrical parts which may cause malfunction, service personnel shall be able to determine the specific reason and solve the faulted parts. Observe the status of the complete device and do not observe the partial It is advised to start from the simple operation during analyzing ,judging and confirming malfunction reason, then conduct the complicated operations such removal of device, part replacement and refrigerant filling.
  • Page 111 TROUBLESHOOTING Malfunction display: E1 Compressor High Pressure Protection SM YIF 2-A.1 GB 13-5...
  • Page 112 TROUBLESHOOTING Malfunction display: E3 Compressor Low Pressure Protection 13-6 SM YIF 2-A.1 GB...
  • Page 113 TROUBLESHOOTING Malfunction display: E4 Compressor Exhaust High Temperature(CTT) Protection Compressor Exhaust High Temperature Protection Check if the air exhaust temperature has Check if the resistance value of the replace the corresponding reached 130℃？ sensor is correct? discharge temperature sensor check if the liquid bypass plug is connected Replace the main board of the when the air exhaust temperature of the outdoor unit...
  • Page 114 TROUBLESHOOTING Malfunction display: E5 Compressor Overload Compressor Overheat if the compressor cable is properly adjust the compressor cable connected connection if the current value is higher than the set replace over-current protector value of the protector if the high pressure of the refer to “E1”...
  • Page 115 TROUBLESHOOTING Malfunction display: E6 Communications Failure Communications Failure Check if the communication cable of the indoor check the directions of the plug unit is ok and the socket check if the communication cable is through replace communication cable check the connection of the communication check the directions of the plug cable for the indoor and outdoor units and the socket...
  • Page 116 TROUBLESHOOTING Malfunction display: E9 Water Full Protection Full Water Protection check if the voltage of liquid level replace the main board of the check if water overflows? switch end is ok? indoor unit check the liquid level switch replace the main board of the indoor unit check if the voltage for the water check the cables of water...
  • Page 117 TROUBLESHOOTING Malfunction display: F0 Failure of RAT Failure of Indoor Room Sensor at Air Intake check if the plug of the temperature sensor check the directions of the is correctly connected with socket on the plug and socket main board? Remove the sensor to check if the replace temperature sensor resistance value is ok?
  • Page 118 TROUBLESHOOTING Malfunction display: F3 Failure of OAT Failure of Outdoor Ambient Sensor Check if the plug of the temperature sensor check the directions of the is correctly connected with socket on the plug and the socket main board? Remove the temperature sensor to check if replace the temperature the resistance value is ok？...
  • Page 119 TROUBLESHOOTING Malfunction display: F5 Failure of RAT at RCW Failure of Indoor Room Sensor at Wire Controller Check if the plug of the temperature sensor check the directions of the is correctly connected with socket on the plug and the socket main board？...

  • Page 121: Exploded View & Spare Part List

    EXPLODED VIEW & SPARE PART LIST EXPLODED VIEW & SPARE PART LIST 14.1 Exploded view of Indoor unit: for DAF all models SM YIF 2-A.1 GB 14-1...
  • Page 122 EXPLODED VIEW & SPARE PART LIST 14.2 Spare part list of Indoor Unit DAF009 Part Code Part Description 11725201 Filter Sub-Assy 01499051 Seal of Left Side Plate 01259051 Top Cover Plate 3900012123G Temperature Sensor 390001921G Tube Sensor 01395768 Electric Box Assy...
  • Page 123 EXPLODED VIEW & SPARE PART LIST 14.3 Spare part list of Indoor Unit DAF012 Part Code Part Description 11725201 Filter Sub-Assy 01499051 Seal of Left Side Plate 01259051 Top Cover Plate 3900012123G Temperature Sensor 390001921G Tube Sensor 01395767 Electric Box Assy 30228205 Main PCB2 Z8235 43110239...
  • Page 124 EXPLODED VIEW & SPARE PART LIST 14.4 Spare part list of Indoor Unit DAF018 Part Code Part Description 11725202 Filter sub-assy 01315295 Left Side Plate Assy 01259064 Upper Cover Plate Assy 3900012123G Temperature Sensor 390001921G Tube Sensor 01395766 Electric Box Assy 30228205 Main PCB2 Z8235 43110239...
  • Page 125 EXPLODED VIEW & SPARE PART LIST 14.5 Spare part list of Indoor Unit DAF024 Part Code Part Description 11125303 Filter Sub-assy 01315343 Left Side Plate Sub-Assy 01265301 Top Cover 3900012123G Temperature Sensor 3900012121G Temperature Sensor 01395765 Electric Box Assy 30228205 Main PCB2 Z8235 43110239 Transformer...
  • Page 126 EXPLODED VIEW & SPARE PART LIST 14.6 Spare part list of Indoor Unit DAF030 Part Code Part Description 11125303 Filter Sub-assy 01315343 Left Side Plate Sub-Assy 01265301 Top Cover 3900012123G Temperature Sensor 3900012121G Temperature Sensor 01395765 Electric Box Assy 30228205 Main PCB2 Z8235 43110239 Transformer...
  • Page 127 EXPLODED VIEW & SPARE PART LIST 14.7 Spare part list of Indoor Unit DAF036 Part Code Part Description 111253031 air filter 01315306 Left Side Plate 01265306 Top Cover 3900012123G Temperature Sensor 390001921G Tube Sensor 01395764 Electric Box Assy 30228205 Main PCB2 Z8235 43110239 Transformer 33010734...
  • Page 128 EXPLODED VIEW & SPARE PART LIST 14.8 Spare part list of Indoor Unit DAF042 Part Code Part Description 111253031 air filter 01315306 Left Side Plate 01265306 Top Cover 3900012123G Temperature Sensor 390001921G Tube Sensor 01395764 Electric Box Assy 30228205 Main PCB2 Z8235 43110239 Transformer 33010734...
  • Page 129 EXPLODED VIEW & SPARE PART LIST 14.9 Spare part list of Indoor Unit DAF060 Part Code Part Description 111253032 Filter Sub-assy 01309108 Left Side Plate 01259111 Top Cover 3900012123G Temperature Sensor 3900012121G Temperature Sensor 01395764 Electric Box Assy 30228205 Main PCB2 Z8235 43110239 Transformer 33010734...
  • Page 130 EXPLODED VIEW & SPARE PART LIST 14.10 Exploded view of Indoor unit: FAF012, FAF018 14-10 SM YIF 2-A.1 GB...
  • Page 131 EXPLODED VIEW & SPARE PART LIST 14.11 Spare part list of Indoor Unit FAF012 Part Code Part Description 01302013 Rear Side Plate 26232001 Handle 261124152 Decorate Plate 0130201501 Rear side plate assy 1051953202 Guide Louver 261124162 Decorate Plate 10512026 Shaft of Guide Louver II 24212019 Guide Louver Support 10512025...
  • Page 132 EXPLODED VIEW & SPARE PART LIST 39000194 Outdoor Tube Sensor 42020063 Sensor Insert 01362001 Water Lead Panel 01072409 Cover Of Evaporator 01708763 Fixed Mount 10312401 Centrifugal Fan 22202032 Propeller Housing 22202031 Front Volute Casing Axes Connector 70819522 Bar Clasp 70819521 Hoop 15707302 Fan Motor...
  • Page 133 EXPLODED VIEW & SPARE PART LIST 14.12 Spare part list of Indoor Unit FAF018 Part Code Part Description 01302013 Rear Side Plate 26232001 Handle 261124152 Decorate Plate 0130201501 Rear side plate assy 1051953202 Guide Louver 261124162 Decorate Plate 10512026 Shaft of Guide Louver II 24212019 Guide Louver Support 10512025...
  • Page 134 EXPLODED VIEW & SPARE PART LIST 48.1 03222520 Liquid-intake Pipe Components 48.2 03533428 Air Collecting Pipe Components 39000194 Outdoor Tube Sensor 42020063 Sensor Insert 01362001 Water Lead Panel 01072409 Cover Of Evaporator 01708763 Fixed Mount 10312401 Centrifugal Fan 22202032 Propeller Housing 22202031 Front Volute Casing Axes Connector...
  • Page 135 EXPLODED VIEW & SPARE PART LIST 14.13 Exploded view of Indoor unit: FAF024 SM YIF 2-A.1 GB 14-15...
  • Page 136 EXPLODED VIEW & SPARE PART LIST 14.14 Spare part list of Indoor Unit FAF024 Part Code Part Description 261124172 Decorative Board 10512025 Shaft of Louver 0133242202 Mounting Plate Sub-Assy of Swing Vane 24212020 Louver Support 24222016 Louver Fixer 1051241001 Air Guider Assy 10512026 Shaft of Louver 261124212...
  • Page 137 EXPLODED VIEW & SPARE PART LIST 39000186 Temperature Sensor(15K black) 390001215G Temperature Sensor 01072417 Evaporator Cover 26112032 Left Decoration Panel 01332405 Mounting Plate 12312406 Left side board foam sub-assy 01332428 Bearing Mounting Plate Sub-Assy 01302418 Rear Side Plate assy of Air Outlet 10582008 Swing Lever 10582009...
  • Page 138 EXPLODED VIEW & SPARE PART LIST 14.15 Exploded view of Indoor unit: FAF030 14-18 SM YIF 2-A.1 GB...
  • Page 139 EXPLODED VIEW & SPARE PART LIST 14.16 Spare part list of Indoor Unit FAF030 Part Code Part Description 10512025 Shaft of Louver 0133242202 Mounting Plate Sub-Assy of Swing Vane 1051241001 Air Guider Assy 26152407 Left mounting plate(Louver Motor ) 015324104 Front Panel Assy 30545654 Display Board...
  • Page 140 EXPLODED VIEW & SPARE PART LIST 42020063 Sensor Insert 01792409 Fixer of Motor Support 76512404 O-Gasket of Bearing 01702405 Motor Press Plate 24222016 Louver Fixer 22412011 Grille 11122012 Filter 39000186 Temperature Sensor(15K black) 10582009 Swing Link Lever 14-20 SM YIF 2-A.1 GB...
  • Page 141 EXPLODED VIEW & SPARE PART LIST 14.17 Exploded view of Indoor unit: FAF036/042 SM YIF 2-A.1 GB 14-21...
  • Page 142 EXPLODED VIEW & SPARE PART LIST 14.18 Spare part list of Indoor Unit FAF036 Part Code Part Description 261124152 Left Decoration Plate 10512025 Shaft of Louver 0133241802 Swing Louver Fixer sub-assy 24212019 Guide Louver Holder 24212018 Louver Fixer 1051240602 Guide Louver 10512026 Shaft of Louver 261124162...
  • Page 143 EXPLODED VIEW & SPARE PART LIST 26252002 Front Grill Clip Temp Sensor （20K） 39000194G 39000186 Temperature Sensor(15K black) 01072409 Cover Of Evaporator 26112028 Decorative Board 01332405 Mounting Plate 12312403 Left Side Foam 01332417 Bearing Mounting Plate Assy 01302417 Rear Side Plate Sub-Assy 10582008 Swing Lever 10582009...
  • Page 144 EXPLODED VIEW & SPARE PART LIST 14.19 Spare part list of Indoor Unit FAF042 Part Code Part Description 261124152 Left Decoration Plate 10512025 Shaft of Louver 0133241802 Swing Louver Fixer sub-assy 24212019 Guide Louver Holder 24212018 Louver Fixer 1051240602 Guide Louver 10512026 Shaft of Louver 261124162...
  • Page 145 EXPLODED VIEW & SPARE PART LIST 26252003 Front Grill Clip 01029612 Evaporator Assy 26252002 Front Grill Clip Temp Sensor （20K） 39000194G 39000186 Temperature Sensor(15K black) 01072409 Cover Of Evaporator 26112028 Decorative Board 01332405 Mounting Plate 12312403 Left Side Foam 01332417 Bearing Mounting Plate Assy 01302417 Rear Side Plate Sub-Assy...
  • Page 146 EXPLODED VIEW & SPARE PART LIST 14.20 Exploded view of Indoor unit: CAF012/018 14-26 SM YIF 2-A.1 GB...
  • Page 147 EXPLODED VIEW & SPARE PART LIST 14.21 Spare part list of Indoor Unit CAF012 Part Code Part Description 30297301 Display Board Z7A351 10312702 Centrifugal Fan 15012707 Fan Motor 01029608 Evaporator Assy 01702702 Motor Mounting Rack 01382719 Tube Exit Plate Assy 01399418 Electric Box Assy 42010258...
  • Page 148 EXPLODED VIEW & SPARE PART LIST 14.22 Spare part list of Indoor Unit CAF018 Part Code Part Description 30297301 Display Board Z7A351 10312702 Centrifugal Fan 15012707 Fan Motor 01029408 Evaporator Assy 01702702 Motor Mounting Rack 01382719 Tube Exit Plate Assy 01399408 Electric Box Assy 42010258...
  • Page 149 EXPLODED VIEW & SPARE PART LIST 14.23 Exploded view of Indoor unit:CAF024/036/042 SM YIF 2-A.1 GB 14-29...
  • Page 150 EXPLODED VIEW & SPARE PART LIST 14.24 Spare part list of Indoor Unit CAF024 Part Code Part Description 01382715 Tube Exit Plate Assy 01332701 Major Mounting Plate 01302718 Front Side Plate 01302715 Left Side Plate Assy 01222701 Base Plate Assy 01302714 Rear Side Plate 01702701...
  • Page 151 EXPLODED VIEW & SPARE PART LIST 14.25 Spare part list of Indoor Unit CAF036 Part Code Part Description 01382715 Tube Exit Plate Assy 01332701 Major Mounting Plate 01302713 Front Side Plate 01302711 Left Side Plate Assy 01222701 Base Plate Assy 01302709 Rear Side Plate 01702701...
  • Page 152 EXPLODED VIEW & SPARE PART LIST 14.26 Spare part list of Indoor Unit CAF042 Part Code Part Description 01382715 Tube Exit Plate Assy 01332701 Major Mounting Plate 01302713 Front Side Plate 01302711 Left Side Plate Assy 01222701 Base Plate Assy 01302709 Rear Side Plate 01702701...
  • Page 153 EXPLODED VIEW & SPARE PART LIST 14.27 Exploded view of Indoor unit: CAF030 SM YIF 2-A.1 GB 14-33...
  • Page 154 EXPLODED VIEW & SPARE PART LIST 14.28 Spare part list of Indoor Unit CAF030 Part Code Part Description 01382715 Tube Exit Plate Assy 01332701 Major Mounting Plate 01302718 Front Side Plate 01302715 Left Side Plate Assy 01222701 Base Plate Assy 01302714 Rear Side Plate 01702701...
  • Page 155 EXPLODED VIEW & SPARE PART LIST 14.29 Exploded view of Outdoor unit: YIF009/012 SM YIF 2-A.1 GB 14-35...
  • Page 156 EXPLODED VIEW & SPARE PART LIST 14.30 Spare part list of Outdoor Unit YIF009 Part Code Part Description 22413007 Grille 200020153 Front Panel Sub-Assy 10333413 Axial-flow Fan 15013067 Fan Motor 01703068 Motor Support 01125241 Condenser Assy 01253443 Top Cover Plate 01473014 Rear Grill 33010743...
  • Page 157 EXPLODED VIEW & SPARE PART LIST 14.31 Spare part list of Outdoor Unit YIF012 Part Code Part Description 22413433 Front grill 200020153 Front Panel Sub-Assy 10333004 Axial Flow Fan 15013071 Motor FW48G 01703086 motor support 01125244 Condenser Assy 01253443 Top Cover Plate 01473014 Rear Grill 33010743...
  • Page 158 EXPLODED VIEW & SPARE PART LIST 14.32 Spare part list of Outdoor Unit YIF018 Part Code Part Description 22413007 Grille 01533012 Front Panel 10333413 Axial-flow Fan 15013071 Motor FW48G 01703391 Motor Support 01125252 Condenser Assy 01253443 Top Cover Plate 01473014 Rear Grill 33000039 Capacitor...
  • Page 159 EXPLODED VIEW & SPARE PART LIST 14.33 Exploded view of Outdoor unit: YIF024 SM YIF 2-A.1 GB 14-39...
  • Page 160 EXPLODED VIEW & SPARE PART LIST 14.34 Spare part list of Outdoor Unit YIF024 Part Code Part Description 22414102 Panel Grille 26235401 Small Handle 01433017P Front Plate 01303251P Front Side Plate 26235253 Handle 10335253 Axial-flow Fan 150154512 Motor LW92H 01705103 Motor Support 01255013P Top Cover...
  • Page 161 EXPLODED VIEW & SPARE PART LIST 14.35 Exploded view of Outdoor unit: YIF030 SM YIF 2-A.1 GB 14-41...
  • Page 162 EXPLODED VIEW & SPARE PART LIST 14.36 Spare part list of Outdoor Unit YIF030 Part Code Part Description 01305043P Left Side Plate 01475008 Rear Grill 10335005 Axial Flow Fan 01125339 Condenser Assy 01705016 Motor Support Sub-Assy 01255007 Top Cover Sub-Assy 01235061 Clapboard 04145321...
  • Page 163 EXPLODED VIEW & SPARE PART LIST 14.37 Exploded view of Outdoor unit: YIF036 SM YIF 2-A.1 GB 14-43...
  • Page 164 EXPLODED VIEW & SPARE PART LIST 14.38 Spare part list of Outdoor Unit YIF036 Part Code Part Description 22265401 Front Grill 01435103P Housing 01475401 Rear Grill 01255012P Top Cover 01305402 Rear Side Plate Sub-Assy 26235253 Handle 01715402 Valve Support Sub-Assy 01205402 Underpan Sub-Assy 01305406...
  • Page 165 EXPLODED VIEW & SPARE PART LIST 14.39 Spare part list of Outdoor Unit YIF036T Part Code Part Description 22265401 Front Grill 01435103P Housing 01475401 Rear Grill 01255012P Top Cover 01305402 Rear Side Plate Sub-Assy 26235253 Handle 01715402 Valve Support Sub-Assy 01205403 Underpan Assy 01305403...
  • Page 166 EXPLODED VIEW & SPARE PART LIST 14.40 Exploded view of Outdoor unit: YIF042 14-46 SM YIF 2-A.1 GB...
  • Page 167 EXPLODED VIEW & SPARE PART LIST 14.41 Spare part list of Outdoor Unit YIF042 Part Code Part Description 22414102 Panel Grille 01435436 Front Plate 01475432 Rear Grill 01255013P Top Cover 01303712 Rear Side Plate Sub-Assy 26235253 Handle 01715001 Valve Support Sub-Assy 01205433 Underpan Sub-Assy 01305430...
  • Page 168 EXPLODED VIEW & SPARE PART LIST 14.42 Exploded view of Outdoor unit: YIF060 14-48 SM YIF 2-A.1 GB...
  • Page 169 EXPLODED VIEW & SPARE PART LIST 14.43 Spare part list of Outdoor Unit YIF060 Part Code Part Description 22414102 Panel Grille 01435436 Front Plate 01475432 Rear Grill 01255472 Top Cover 01303712 Rear Side Plate Sub-Assy 26235253 Handle 01715001 Valve Support Sub-Assy 01205472 Underpan Sub-Assy 01305431...

  • Page 171: Appeddix

    APPENDIX APPEDDIX APPENDIX SM YIF 2-A.1 GB 15-1...

This manual is also suitable for:

Yif009Faf012Caf012Yif012Daf018Faf018 ... Show all

Table of Contents
