- Page 1 DED 076/095 Indoor Units Outdoor Units AWSI-DED076-N11 AWAU-YED076-H13 AWSI-DED095-N11 AWAU-YED095-H13 REFRIGERANT R410A HEAT PUMP SM DED 1-A.1 GB FEB-2017 Version:1...
- Page 2 LIST OF EFFECTIVE PAGES LIST OF EFFECTIVE PAGES Note: Changes in the pages are indicated by a “Revision#” in the footer of each effected page (when none indicates no changes in the relevant page). All pages in the following list represent effected/ non effected pages divided by chapters.
-
Page 3: Table Of Contents
TABLE ODEDONTENTS Table of Contents INTRODUCTION ..........................1-1 PRODUCT DATA SHEET ....................... 2-1 RATING CONDITIONS ........................3-1 OUTLINE DIMENSION ........................4-1 PERFORMANCE DATA ......................... 5-1 AIRFLOW CURVES ........................6-1 SOUND LEVEL CHARACTERISTICS ................... 7-1 ELECTRICAL DATA ........................8-1 WIRING DIAGRAM ......................... 9-1 REFRIGERATION DIAGRAMS ...................... -
Page 4: Introduction
INTRODUCTION INTRODUCTION General DED series is a monosplit DCI inverter air conditioner. The indoor is high static pressure ducted type which is very suitable for larger space air conditioning. The outdoor is front discharge ourdoor designed for easy installation and saving installation space. -
Page 5: Indoor Unit
INTRODUCTION Indoor Unit The indoor unit is high static ducted type indoor, and can be easily fitted to many types of commercial buildings. It includes: Variable speeds DC fan Integrated condesate water pump High efficiency filtration to ensure a best Air Quality Control Wired control RCW17 as standard control including functions (ON/OFF, mode, temperature, fan, swing, sleep mode,fresh air settings, turbo mode, error display) - Page 6 INTRODUCTION Matching Table INDOOR UNITS OUTDOOR UNITS AWSI-DED076-N11 AWSI-DED095-N11 AWAU-YED076-H13 AWAU-YED095-H13 SM DED 1-A.1 GB...
-
Page 7: Product Data Sheet
PRODUCT DATA SHEET PRODUCT DATA SHEET AWSI-DED076-N11 / AWAU-YED076-H13 Model Indoor Unit AWSI-DED076-N11 Model Outdoor Unit AWAU-YED076-H13 Installation Method of Pipe Soldering Characteristics Units Cooling Heating Capacity 22.4 25.0 Power input 6.54 SEER /SCOP 3.34 3.82 Energy efficiency class Power supply... - Page 8 PRODUCT DATA SHEET AWSI-DED095-N11 / AWAU-YED095-H13 Model Indoor Unit AWSI-DED095-N11 Model Outdoor Unit AWAU-YED095-H13 Installation Method of Pipe Soldering Characteristics Units Cooling Heating Capacity 28.0 30.0 Power input 8.15 SEER /SCOP 3.37 3.68 Energy efficiency class Power supply V/Ph/Hz 380-415V/3N~/50Hz Circuit breaker rating Fan type &...
-
Page 9: Rating Conditions
RATING CONDTIONS RATING CONDITIONS Rating conditions in accordance with ISO 5151 and ISO 13253 (for ducted units). Cooling: Indoor: C DB 19 C WB Outdoor: 35 C DB Heating: Indoor: C DB Outdoor: 7 C DB 6 C WB Operating Limits R410A Indoor Outdoor... -
Page 10: Outline Dimension
OUTLINE DIMENSION OUTLINE DIMENSION Indoor: DED076 / 095 Model DED076 1353 1150 DED095 1563 1350 SM DED 1-A.1 GB... - Page 11 OUTLINE DIMENSION Outdoor: YED076/YED095 SM DED 1-A.1 GB...
-
Page 12: Performance Data
PERFORMANCE DATA PERFORMANCE DATA Model: AWSI-DED076-N11 / AWAU-YED076-H11 1) Cooling running Capacity Indoor temperature (℃ WB/℃ DB) Outdoor 14℃WB 16℃WB 19℃WB 22℃WB 24℃WB temperature 20℃DB 23℃DB 27℃DB 30℃DB 32℃DB (℃DB) 15.2 11.6 16.4 12.8 22.4 16.8 27.6 17.9 30.0 19.5 15.2... - Page 13 PERFORMANE DATA Model: AWSI-DED096-N11 / AWAU-YED096-H11 1) Cooling running Capacity Indoor temperature (℃ WB/℃ DB) Outdoor 14℃WB 16℃WB 19℃WB 22℃WB 24℃WB temperatur 20℃DB 23℃DB 27℃DB 30℃DB 32℃DB e (℃DB) 14.5 20.4 15.9 34.4 22.4 37.5 24.4 14.5 20.4 15.9 34.4 22.4 37.5 24.4...
-
Page 14: Airflow Curves
AIRFLOW CURVES AIRFLOW CURVES Model: AWSI-DED076-N11 Model: AWSI-DED095-N11 SM DED 1-A.1 GB... -
Page 15: Sound Level Characteristics
SOUND LEVEL CHARACTERISTICS SOUND LEVEL CHARACTERISTICS Sound Pressure Level Notes: 1. The noise level is measured in the semi-anechoic room. It will be slightly higher due to change of the environment during actual operation. 2. The noise level is measured under the standard test condition. 3. - Page 16 SOUND LEVEL CHARACTERISTICS Soud Pressure Level Spectrum (Measured as Figure 1) Model: AWSI-DED076-N11 Model: AWSI-DED095-N11...
-
Page 17: Electrical Data
ELECTRICAL DATA ELECTRICAL DATA AWSI-DED076-N11 AWSI-DED095-N11 MODEL AWAU-YED076-H13 AWAU-YED095-H13 Indoor & Outdoor Power Supply Indoor: 1PH-220-240V-50Hz Outdoor: 3PH-380-415V-50Hz Max Power (Indoor) 900W 900W Max power (Outdoor) 8400W 12100W Circuit Breaker,A (indoor / Outdoor) Power Supply (Indoor) Wiring No. X Cross 3x1.5 mm... -
Page 18: Wiring Diagram
WIRING DIAGRAMS WIRING DIAGRAM Abbrivation Symbol Symbol Color Symbol Symbol Color Symbol Name White Green Jumper cap Yellow Brown COMP Compressor Blue Grounding wire YEGN Yellow/Green Black Violet Orange Indoor AWSI-DED076-N11, AWSI-DED095-N11 SM DED 1-A.1 GB... - Page 19 WIRING DIAGRAM Outdoor AWAU-YED076-H13, AWAU-YED095-H13 SM DED 1-A.1 GB...
-
Page 20: Refrigeration Diagrams
REFRIGERATION DIAGRAMS REFRIGERATION DIAGRAMS SM DED 1-A.1 GB 10-1... - Page 21 REFRIGERATION DIAGRAMS Function description for each component: Name Main Function Name Main Function Compressor Adjusts its own rotational speed Liquid outlet Detects tube temperature. based on the actual requirement of the temperature system to implement capacity control. sensor of sub cooler Compressor Maintains a proper oil temperature in...
-
Page 22: Tubing Connections
TUBING CONNECTIONS TUBING CONNECTIONS 11.1 Flaring Connection The refrigerant pipes and IDUs are connected by using the flare opening. Therefore, the quality of flaring connection must be ensured. The flaring depth of the bell mouth cannot be smaller than the caliber. The flaring direction must face towards the direction of medium flow. - Page 23 TUBING CONNECTIONS When the outdoor unit is installed above the indoor unit an oil trap is required every 5m along the suction line at the lowest point of the riser. In case the indoor unit is installed above the outdoor, no trap is required. 11-2 SM DED 1-A.1 GB...
-
Page 24: Control System(To Be Finished)
CONTROL SYSTEM CONTROL SYSTEM(TO BE FINISHED) SM DED 1-A.1 GB 12-1... -
Page 25: Troubleshooting
TROUBLESHOOTING TROUBLESHOOTING SM DED 1-A.1 GB 13-1... -
Page 26: Characteristics Of Sensor
CHARACTERISTICS OF SENSOR CHARACTERISTICS OF SENSOR 14.1.1 RAT/OAT RAT/OAT R-T chart Temperature(C) 14.1.2 ICT/OCT ICT/OCT R-T Chart Temperature(C) SM DED 1-A.1 GB 14-1... - Page 27 CHARACTERISTICS OF SENSOR 14.1.3 CTT R-T Chart Temperature(C) 14-2 SM DED 1-A.1 GB...
-
Page 28: Exploded View & Spare Part List
EXPLODED VIEW & SPARE PART LIST EXPLODED VIEW & SPARE PART LIST 15.1 Exploded view of indoor unit: DED076 SM DED 1-A.1 GB 15-1... - Page 29 EXPLODED VIEW & SPARE PART LIST 15.2 Spare part list of indoor Unit: DED076 Part Code Part Description 01265359 Top Cover Board Assy 01024100120 Evaporator Assy 30296000040_L51037 Display Board 02112466 Hook 01284620 Water Tray Assy 01265357 Bottom Cover Plate Assy 15404100051 Centrifugal fan assy 15704100009...
- Page 30 EXPLODED VIEW & SPARE PART LIST 15.4 Exploded view of indoor unit: DED095 SM DED 1-A.1 GB 15-3...
- Page 31 EXPLODED VIEW & SPARE PART LIST 15.5 Spare part list of indoor Unit: DED095 Part Code Part Description 01314314 Front Side Plate Sub-Assy 15404100061 Centrifugal fan assy 15704100009 Brushless DC Motor 15704118 Motor 1570411801 Motor 01264213 Lower Cover Plate Sub-Assy 01314100088 Right Side Plate Assy 01314312...
- Page 32 EXPLODED VIEW & SPARE PART LIST 15.6 Exploded view of outdoor unit: YED076 SM DED 1-A.1 GB 15-5...
- Page 33 EXPLODED VIEW & SPARE PART LIST 15.7 Spare part list of outdoor Unit: YED076 Part Code Part Description 01574106 Front Grill 10335010 Axial Flow Fan 15704100006 Brushless DC Motor 01514100003P Cabinet 26904100016 Handle 01344100009P Front Connection Board 01194100047P Chassis Sub-assy 07212001 Strainer 00204100005...
- Page 34 EXPLODED VIEW & SPARE PART LIST Part Code Part Description 01394100257 Electric Box Assy 01264100014P Coping 01244100008 Clapboard 01804100280 Motor Support Assy 01314100024P Left Side Plate 46010608 Rectifier 49018000046 Radiator 30224100002 Filter Board 49010109 Magnetic Ring 71010005 Wire Clamp 70410006 Insulation Gasket 42011043 Terminal Board...
- Page 35 EXPLODED VIEW & SPARE PART LIST 15.8 Exploded view of outdoor unit: YED095 15-8 SM DED 1-A.1 GB...
- Page 36 EXPLODED VIEW & SPARE PART LIST 15.9 Spare part list of outdoor Unit: YED095 Part Code Part Description 322101002 Sensing Device 322101032 Sensor (High Pressure) 01124100107 Condenser Assy 00204100003 Compressor 04574100051 Inhalation Tube Sub-assy 04044100020 4-Way Valve Assy 04224100203 Oil balance pipe Sub-Assy 04224100204 Oil balance pipe Sub-Assy 01324100017...
- Page 37 EXPLODED VIEW & SPARE PART LIST Part Code Part Description 01804100153 Supporter 01894100024 Supporting Board(Condenser) 01804100274 Supporter 01804100275 Supporter 01804100276 Supporter 01894100025 Supporting Board 26905202 Sensor Support 15-10 SM DED 1-A.1 GB...
- Page 38 APPENDIX SM DED 1-A.1 GB 15-1...
