Rack Stability for NS7 Systems

Rack stabilizers are required when you have less than four racks bayed together.
NOTE: Rack stability is of special concern when equipment is routinely installed, removed, or
accessed within the rack. Stability is addressed through the use of leveling feet, baying kits, fixed
stabilizers, and/or ballast. Use baying kits to bay racks to racks of the same height. In all cases,
a rack cannot be bayed with another rack of a different height.
NOTE: For instructions on best practices for the Enterprise series rack (formerly known as the
Intelligent rack) or for using the HPE Rack Ground Bonding Kit (BW891A), ask your service
provider to see the instructions in the:
HP Rack Options Installation Guide
http://www.hpe.com/support/Intelligent_Series_Rack_Manuals.

Environmental Specifications for NS7 AC Systems

NS7 Heat Dissipation Specifications and Worksheet
Enclosure Type
c7000 enclosure
(single-phase)
BL460c Gen8 server
blade, 64GB
BL460c Gen9 server
blade, 64GB
BL460c Gen9 server
blade, 128GB
BL460c Gen9 server
blade, 192GB
IB FDR ADI Switch
IB FDR I/O Expansion
Switch
IB FDR cluster switch
(NonStop X Cluster
Solution)
Gen8 Storage CLIM
Gen8 10GbE
Networking CLIM
4C/1C
Gen8 10GbE
Networking CLIM
4F/1C
Gen9 Storage CLIM
Gen9 10GbE
Networking CLIM
4C/1C
Number Installed Unit Heat
(BTU/hour, Typical
Heat Dissipation)
2764
785
1024
1075
1126
706
706
706
444
427
409
1024
461
Unit Heat (BTU/hour, Total (BTU/hour)
Maximum Heat
Dissipation)
3856
785
1024
1075
1126
798
798
798
546
529
511
1024
631
Rack Stability for NS7 Systems 55
