International Three-Phase Power Specifications - HP Integrity NonStop X NS7 Planning Manual

Table 6 International Three-Phase Power Specifications
International
Output Load
Input Voltage
Input Connector
Output Voltage
Output Connectors
Notes
Enclosure AC Input for NS7 Systems
Enclosures (IP CLIM, SAS disk enclosure, and so forth) require:
Specification
Nominal input voltage
Voltage range
Nominal line frequency
Frequency ranges
Number of phases
Single-phase c7000 enclosures require:
Specification
Voltage range
Nominal line frequency
Frequency ranges
Number of phases
R12000 3-phase UPS
12 kW
380-415V 3P Wye
IEC309 532P6
400V 3P Wye
2 x IEC309 309 516C6
UPS outputs are connected to the compatible PDU inputs.
Value
200/208/220/230/240 V AC RMS
180-264 V AC
50 or 60 Hz
47-53 Hz or 57-63 Hz
1
Value
200-240 VAC
50 or 60 Hz
47-53 Hz or 57-63 Hz
1
iPDU 3-phase
16 A/phase
380-415V 3P Wye
IEC309 516P6
N/A
6 x C19
(20 x C13)
AC Input Power for NS7 Racks
Modular PDU 3-phase
16 A/phase
380-415V 3P Wye
IEC309 516P6
N/A
6 x C19 (20 A)
(42 x C13)
47
