NS7 Enclosure Power Loads

The total power and current load for a rack depends on the number and type of enclosures
installed in it. Therefore, the total load is the sum of the loads for all installed enclosures.
In normal operation, the AC power is split equally between the power feeds on the two sides (left
and right) of the rack. However, if AC power fails on one side of the rack, the power feed(s) on
the remaining side must carry the power for all enclosures in that rack.
NOTE: For NS7 CG X2 system specifications, see
CG Systems" (page
Power and current specifications for each type of enclosure are:
Enclosure Type
Products used by NS7 X1
AC systems
BL460c Gen8 CPU
(64 GB RAM)
BL460c Gen8 CPU
(128 GB RAM)
BL460c Gen8 CPU
(192 GB RAM)
Products used by NS7 X2
AC systems
BL460c Gen9 CPU
(64 GB RAM)
BL460c Gen9 CPU
(128 GB RAM)
BL460c Gen9 CPU
(192 GB RAM)
Common products used by
NS7 X1 and NS7 X2 AC
systems:
c7000 enclosure
FDR IB ADI switch (for
NSADI)
FDR IB switches expansion
FDR IB cluster switch (for
NonStop X Cluster Solution)
Gen8 Storage CLIM
Gen8 Networking CLIM,
4C/1C (IP or Telco)
Gen8 Networking CLIM,
3C/2F (IP or Telco)
Gen9 Storage CLIM
48 NS7 System Installation Specifications
70).
AC Power Lines per
Enclosure
-
-
-
-
-
-
6
2
2
2
2
2
2
2
"System Installation Specifications for NS7
Typical Power
1
Consumption (VA)
230
260
290
300
315
330
810
207
207
207
130
126
128
140
Maximum Power
2
Consumption (VA)
230
260
290
300
315
330
1250
234
234
234
160
156
158
190
