USER MANUAL
VERSION 1.0 May 2012
TEOS WIDE

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the TEOS WIDE and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for AURES TEOS WIDE

Summary of Contents for AURES TEOS WIDE

  • Page 1 USER MANUAL VERSION 1.0 May 2012 TEOS WIDE...

  • Page 2: Important Safety Instructions

    Copyright 2012 All Rights Reserved Manual Version 1.0 The information contained in this document is subject to change without notice. We make no warranty of any kind with regard to this material, including, but not limited to, the implied warranties of merchantability and fitness for a particular purpose. We shall not be liable for errors contained herein or for incidental or consequential damages in connection with the furnishing, performance, or use of this material.
  • Page 3 CE MARK This device complies with the requirements of the EEC directive 2004/108/EC with regard to “Electromagnetic compatibility” and 2006/95/EC “Low Voltage Directive”. This device complies with part 15 of the FCC rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference.

  • Page 4: Legislation And Weee Symbol

    LEGISLATION AND WEEE SYMBOL 2011/65/EU Waste Electrical and Electronic Equipment Directive on the treatment, collection, recycling and disposal of electric and electronic devices and their components. The crossed dust bin symbol on the device means that it should not be disposed of with other household wastes at the end of its working life.

  • Page 5: Revision History

    Revision History Changes to the original user manual are listed below: Revision Description Date • Initial release May 2012...

  • Page 6: Table Of Contents

    Table of Contents 1. Packing List ........1 1-1. Standard Items ..............1 1-2. Optional Items ..............2 2. System View ........3 2-1. Front & Side View ............3 2-2. Rear View .................3 2-3. I/O view ................4 2-4. Dimensions ..............5 2-4-1. 15.6" System ..............5 2-4-2.
  • Page 7 6. Configuration ....... 15 6-1. C68 Motherboard Layout ..........15 6-2. Connectors & Functions ..........16 6-3. Jumper Setting ...............17 Appendix: Drivers Installation ..22...
  • Page 8 The page is intentionally left blank. viii...

  • Page 9: Packing List

    Packing List 1-1. Standard Items System Power adapter Power cord RJ45-DB9 cable (x2) Note: Power cord will be supplied differently according to various region or country.

  • Page 10: Optional Items

    1-2. Optional Items...

  • Page 11: System View

    System View 2-1. Front & Side View Touch Screen Ventilation Built-in Web Cam MSR Cable Hole 2-2. Rear View 5. VESA Mounting Holes 6. Safety Label 7. Cable Cover...

  • Page 12: I/O View

    2-3. I/O view Item No. Descrivption MIC IN DC IN LAN (x2) Cash Drawer Line Out COM Port 1, 2, 3, 4 (from left to right) USB(x4) Printer Power Button HDD slot...

  • Page 13: Dimensions

    2-4. Dimensions 2-4-1. 15.6" System 396mm 48mm 2-4-2. 18.5" System 464mm 48mm 2-4-3. 21.5" System 536mm 48mm...

  • Page 14: System Assembly

    System Assembly 3-1. Open the Chassis Cover The motherboard and RAM module can be replaced by opening the chassis cover, which is located on the back side of the system. Please follow the steps below to open the chassis cover. 1.

  • Page 15: Ram Module Replacement

    3-2. RAM Module Replacement To remove and replace the RAM module, please open the chassis cover firstly as steps dscribed in chapter 3-1. Removing a RAM module 1. Find the memory slot at the right side of the motherboard. 2. Flip the ejector clips outwards to remove the memory module from the memory slot.

  • Page 16: Hdd Replacement

    3-3. HDD Replacement To remove and replace the HDD, please open the cable cover firstly as stpes dscribed in chapter 3-1-1. 15.6” / 18.5” LED LCD The HDD is secured by a clip, please push the clip aside as the picture shown.
  • Page 17 3. Attach the HDD to the HDD tray and slide it into the slot until it snaps in place. Please note the top of the HDD should be on the upper side.

  • Page 18: Peripheral Installation

    Peripheral Installation 4-1. MSR Installation To install MSR, please open the cable cover firstly as steps described in chapter 3-1-1. 1. Insert MSR module in place and fasten the screws (x2) on the back to secure the module. 2. Connect MSR cable to the connector on system side.

  • Page 19: Cash Drawer Installation

    4-2. Cash Drawer Installation You can install a cash drawer through the cash drawer port. Please verify the pin as- signment before installation. Cash Drawer Pin Assignment Signal DOUT bit0 DIN bit0 12V / 19V DOUT bit1 Cash Drawer Controller Register The Cash Drawer Controller use one I/O addresses to control the Cash Drawer.
  • Page 20 Bit 7: Reserved Bit 6: Cash Drawer “DIN bit0” pin input status. = 1: the Cash Drawer closed or no Cash Drawer = 0: the Cash Drawer opened Bit 5: Reserved Bit 4: Reserved Bit 3: Cash Drawer “DOUT bit1” pin output control. = 1: Opening the Cash Drawer = 0: Allow close the Cash Drawer Bit 2: Cash Drawer “DOUT bit0”...

  • Page 21: Specification

    Specification Model Name TEOS WIDE Mainboard Intel Sandy Bridge CPU, LGA 1155-pin, 32nm i3-2120 3.3G, L2 3M, 65W Celeron G540 2.5G, L2 2M, 65W Intel Q67 PCH Chipset (Processor Controller Hub, AMT supported_highend) System Memory 1 x Long DIMM socket up to 8GB DDR3 1066/1333 Mhz, standard 2GB...
  • Page 22 Environment EMC & Safety FCC Class A, CE, LVD Operating Temperature 0°C ~ 35°C (32°F ~ +95°F) Storage Temperature -20°C ~ 60°C (-4°F ~ 140°F) Humidity 20% - 85% RH non-condensing Dust & Water Proof IP 54 (front panel) Dimensions 536 x 48 x 328 mm 396 x 245 x 48 mm 464 x 284 x 48 mm...

  • Page 23: Configuration

    Configuration 6-1. C68 Motherboard Layout PWR1 CN18 PWR3 MINI_PCIE1 RJ45_1 CN19 RJ11_1 CN15 JP14 CN21 CN16 JP10 JP13 DDR3_A1 SATA2 RJ45_2 FAN_CPU1 CN10 CN11 SATA1 SKT1 JP11 JP12 USB1 CN14 USB2 CN12 CN13 CN17 PRN1 CN20 FAN_SYS1 JP15 Version: C68 v1.0...

  • Page 24: Connectors & Functions

    6-2. Connectors & Functions Connector Function CN1/2 SATA power Connector LVDS Connector LVDS INVERTER Connector SATA HDD LED Connector DVI Connector BATTERY Connector CN10/11 USB Port(Internal) CN12 Card Reader Connector(COM6) CN13 RF Connector CN14 COM5 for Touch CN15 SPEAKER & MIC Connector (Internal) CN16 PS2 Keyboard Connector CN17...

  • Page 25: Jumper Setting

    6-3. Jumper Setting Power Mode Setting Function ▲ATX Power AT Power Cash Drawer Power Setting Function JP14 ▲+19V +12V Inverter Selection Function ▲ CCFL Hardware Reset Function ▲System Normal System Reset J umper open Jumper short ▲ = Manufacturer Default Setting...
  • Page 26 USB Touch Power Setting for CN11 Connector Function JP11 ▲+5VSB LCD ID Setting LVDS Resolution Bits Channel 1366 x 768 Single 1920 x 1020 Dual CMOS Operation Mode CMOS Reset To clear the CMOS, 1. Remove the power cable from the system. 2.
  • Page 27 COM2 RS232/485/422 Setting Function JP10 JP13 1 3 5 7 9 5 7 9 11 ▲RS232 6 8 10 6 8 10 12 5 7 9 5 7 9 RS485 8 10 8 10 5 7 9 5 7 9 11 RS422 8 10 COM3 &...
  • Page 28 COM3/COM4 Jumper setup Function JP12 ▲+5V COM3 +12V COM4 ▲+12V...
  • Page 29 Intel Graphics Driver Setting Right click Desktop. Find "Graphics Properties" and enter the manu. 2. Make sure the Display Device is same as follows. Intel Graphics Driver Output Interface Connector & Jumper Device Name LCD Panel Notebook VGA Port JP4/5 Monitor...

  • Page 30: Appendix: Drivers Installation

    Appendix: Drivers Installation To downoad the most recent drivers and utilities, and obtain advice regarding the installation of your equipment, please visit the AURES Technical Support Website: www.aures-support.fr (French) www.aures-support.fr/UK (English) www.aures-support.fr/GE (German)
