Appendix C
Status Messages
The Power Control Processor displays messages on the LCD to advise status of the system or
the components in the panel itself.
.
Status Message
System OK
No other messages active
Emergency Active
Emergency look is active
Breakers Tripped
No voltage detected at one or more relays
Relay Mismatch
One or more relays in the rack are mismatched Yes
Relay Removed
One or more relays in the rack are not found
One or more breakers don't match the
Breaker Mismatch
configuration
Breaker Removed
One or more breakers in the rack are missing
Timed Event Hold
User has applied a timed event hold.
Holiday Shut-off
User has activated Holiday Shut-off
Unable to communicate to the breaker drive
Drive 1/2 Error
board
Breaker Error
Breaker is detected as an impossible type
Dim Overtemp
Dimmer is in an overtemp state
Emergency Active
Emergency contact closures are commonly used with auxiliary systems, such as fire alarms.
For information on wiring and configuring the emergency input on your specific panel,
reference the applicable Installation Manual found on the ETC website,
www.etcconnect.com.
An "Emergency Active" status message on the display indicates that the emergency ("Panic")
contact input has been triggered and the configured emergency look is active in the panel.
An "Emergency Active" status message is the highest priority message; no other status
message display while this status is active. In addition, this status cannot be cleared until the
condition is cleared. For example, resetting the fire alarm signal would clear the condition.
Status Messages
Output Status
Cause
Echo-
ERP-UL
ERP-FT
DIN
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
No
Yes
Yes
Yes
Yes
No
No
No
No
No
No
Yes
Yes
Yes
Yes
Yes
Yes
No
No
No
No
No
No
Yes
Yes
Yes
Sensor
IQ
Yes
Yes
Yes
No
No
Yes
Yes
Yes
Yes
Yes
Yes
No
54
