System Concepts and Definitions
Station Control
The Power Control Processor supports Echo Inspire Stations, and five and ten button Preset
stations on the EchoConnect bus. The power supply of one connected panel can support up
to six hosts and six stations on the bus. An additional wall mounted or rack mounted power
supply can be added to a system to support up to sixteen hosts and sixteen stations.
With an
external
power
supply
9
EchoConnect - Belden 8471 + (1) 14 AWG ESD Ground Wire
=
ERP UL shown. Typical of systems
using EchoDIN, ERP FT, and Sensor IQ
panels.
EchoConnect - Belden 8471 + (1) 14 AWG
Power Control Processor Configuration Manual v2.1
