Sensor IQ Panel Overview
The Sensor IQ Intelligent Breaker System provides professional quality switching and dimming
of loads controlled by DMX512, Ethernet, or ETC's Echo line of stations.
Breakers
Power Control
Processor
(User interface)
*Door removed
for visual clarity
Overview of Panels
Optional Main
Circuit Breaker
installs here
Main lug
Circuit breaker for
user interface
The Ride-Thru
option (SQ-RTO)
installs behind the
UI
Remove front panel
for access to option
cards:
IQ-NET, IQ-CI,
IQ-LVD,IQ-DALI
Low voltage
trough
