- Page 1 SDKRDBS & A s s e m b l y I n s t r u c t i o n s O W N E R ’ S M A N U A L v. SDKRDBS-102315...
- Page 2 W a r n i n g , S a f e t y & M a i n t e n a n c e Be sure that all users carefully read and understand all warning, safety and maintenance labels on the machine before each use.
- Page 3 T a b l e o f C o n t e n t s • SAFETY INSTRUCTIONS......PAGE 4 • PREPARATION..........PAGE 5 • HARDWARE & PART LISTS......PAGE 6 • HARDWARE ILLUSTRATION......PAGE 7 • ASSEMBLY INSTRUCTIONS......PAGE 8 • CONTACT PAGE...........
- Page 4 Before beginning assembly, please take the time that we can assist you better. to read the instructions thoroughly. 1. Model Number m Read each step in the assembly instructions and 2. Place of Purchase follow the steps in sequence. Do not skip ahead. 3. Serial Number (S/N) If you skip ahead, you may learn later that you 4. Part # and Description have to disassemble components and that you may have damaged the equipment. m Assemble and operate the SDKRDBS on a solid, level surface. Locate the unit a few feet from the walls or furniture to provide easy access.
- Page 5 P r e p a r a t i o n Thank you for purchasing the SDKRDBS. This bench is part of the Body-Solid line of quality strength training machines, which lets you target specific muscle groups to achieve better muscle tone and overall body conditioning. To maximize your use of the equipment please study this Owner’s Manual thoroughly. Required Tools Assembly Tips The basic tools that you must obtain before assembling Read all “Notes” on each page before beginning each the SDKRDBS include but are not limited to: step. While you may be able to assemble the SDKRDBS using m Metric Allen Key Set the illustrations only, important safety notes and other tips are included in the text.
- Page 6 S D K R D B S H a r d w a r e & P a r t L i s t Part# Size Description Quantity M10x30mm HEX HEAD BOLT 4 PCS. LOCK WASHER 4 PCS. FLAT WASHER 4 PCS.
- Page 7 S D K R D B S H a r d w a r e I l l u s t r a t i o n Part #1 HEX HEAD BOLT M10x30mm QTY. 4...
- Page 8 O P T. Be careful to assemble all components in the sequence they are presented. NOTE: Finger tighten all hardware initially. Wrench tighten ALL hardware at the end of this STEP. 1A. Attach Small Dumbbell Shelf (A) to the top tier of the two Uprights (B, Sold Seperately) using: 4 - (#1) M10x30mm Hex Head Bolt 4 - (#2) M10 Lock Washer 4 - (#3) M10 Flat Washer NOTE:...
- Page 9 O P T. Above shows option #1 assembled and completed.
- Page 10 O P T. Be careful to assemble all components in the sequence they are presented. NOTE: Finger tighten all hardware initially. Wrench tighten ALL hardware at the end of this STEP. 2A. Attach Small Dumbbell Shelf (A) to the second tier of the two Uprights (B, Sold Seperately) using: 4 - (#1) M10x30mm Hex Head Bolt 4 - (#2) M10 Lock Washer 4 - (#3) M10 Flat Washer NOTE:...
- Page 11 O P T. Above shows option #2 assembled and completed.
- Page 12 O P T. Be careful to assemble all components in the sequence they are presented. NOTE: Finger tighten all hardware initially. Wrench tighten ALL hardware at the end of this STEP. 2A. Attach Small Dumbbell Shelf (A) to the bottom tier of the two Uprights (B, Sold Seperately) using: 4 - (#1) M10x30mm Hex Head Bolt 4 - (#2) M10 Lock Washer 4 - (#3) M10 Flat Washer NOTE:...
- Page 13 O P T. Above shows Option #3 assembled and completed.
- Page 14 SDKRDBS PLEASE WRITE YOUR SERIAL NUMBER IN THE BOXES BELOW 010239-��-��-����-���� S/N # 1900 S. Des Plaines Ave. Forest Park, Il 60130 Phone:(708)427-3555 Fax:(708)427-3556 Hours: M-F 8:30 - 5:00 CST www.bodysolid.com Copyright 2009. Body-Solid. All rights reserved. Body-Solid reserves the right to change design and specifications when we feel it will improve the product.
