- Page 1 User Guide YDM 3168 LEASE READ INSTRUCTIONS BEFORE USE. he functions and design of this product can be changed without prior notice for performance and quality improvement. ISL-1578-00...
-
Page 2: Table Of Contents
This user manual enables you to operate the product safely and to Components Overview its full potential. Specifications Identification Be sure to read this completely before using the Yale Digital Lock product. Quick Menu ( Normal mode) Unlock your life! Quick Menu (... -
Page 3: Safety Precautions
7⃞ Fake PIN Code To prevent the PIN Code being exposed. Yale Digital door lock allows you to enter decoy numbers before or after entering your PIN Code 8⃞ Auto Locking The handle automatically disengages on the outside once you have entered your home, preventing anyone from following you. -
Page 4: Components Overview
Components Overview Specifications Basic Contents Specifications The contents of this product may be subject to change without notice for performance or quality improvement. 》 Basic Contents Parts Specifications Remarks 64mm(W) x 311.7mm(H) x 26mm(D) Front (Front Body) Aluminum Operating temperature : -15~55℃... -
Page 5: Identification
Identification Identification Front body Main body (Front Body, Installation on the outside of the door) (Main Body, Installation on the inside of the door) Pull down Emergency Cover Lock case ❻ 9V Emergency ❶ ❼ battery ❽ (Sold separately) ❶ ❷... -
Page 6: Quick Menu ( Normal Mode)
Quick Menu Quick Menu Normal mode Normal mode Quick Menu (Normal mode) Quick Menu (Normal mode) User PIN Code Registration(4~12) Complete Touch the screen with palm of hand or fingers to begin and end actions. User Card Key Registration Complete Click the indicated number. -
Page 7: Quick Menu ( Advanced Mode)
Quick Menu Quick Menu Advanced mode Advanced mode Quick Menu (Advanced mode) Quick Menu (Advanced mode) Language Setting English Complete Register 01 ~ 40 Continue Registration Individual credential mode Turkish Complete Complete Russian Complete Continue 41 ~ 70 4 ~ 12 Change the Master Code 4 ~ 12 4 ~ 12... - Page 8 How to Use How to Use Normal mode Normal mode Advanced mode User PIN Code Registration (4~12 digits) Unlocking Door with PIN Code User PIN Code Registration(4~12) Complete ➞ ➞ ➞ ➞ Touch the keypad of Enter the registered Touch the keypad of Enter the button.
-
Page 9: Locking The Door
How to Use How to Use Normal mode Advanced mode Normal mode Advanced mode Locking the door Unlocking the door from the inside ※ Please check Automatic / Manual Lock Mode Safe Handle Setting is not fixed as a default . 》... -
Page 10: Safe Handle Setting
How to Use How to Use Normal mode Advanced mode Normal mode Safe Handle Setting Language Setting The technology to prevent a forced attempt to drill a hole in the door and unlock the doorlock has been applied. Language Setting English Complete 》... - Page 11 How to Use How to Use Normal mode Normal mode Register Onetime PIN Code Register Remote control Press buttons Register Onetime PIN Code Register 4 ~ 12 Register Complete Complete on Remote Remote control Menu mode Menu mode Delete Onetime PIN Code Delete all remote control Complete After...
- Page 12 How to Use How to Use Normal mode Advanced mode Normal mode Advanced mode External Forced Lock Automatic / Manual Lock When External Forced Lock mode is activated the Alarm will go off if someone press the Default Automatic lock handle to exit the property.
-
Page 13: Emergency Mechanical Key Override
How to Use How to Use Normal mode Advanced mode Normal mode Advanced mode Break-in Alarm Emergency mechanical key override Break-in Alarm : When the front handle is seperated from Operate the lock with the mechanical key the door the damage alarm will sound. when there is a problem with the lock. -
Page 14: Emergency Power
Emergency Power Emergency power supply for discharged batteries In case the batteries are dead, you can open the door by using 9V battery as shown. 》 To supply emergency power ➞ ➞ ➞ Place the 9V battery Touch the keypad with Enter the registered PIN Touch the keypad with onto the emergency... - Page 18 ❻ ❶ ❼ ❽ ❶ ❷ ❹ ❽ ❸ ❾ ❷ ❸ ❾ ❺ ❿ ❹ ❶ ❷ ❸ ❺ ❹ ❻ ❺ ❶ ❻ ❼ ❷ ❼ ❸ ❹ ❽ ❺ ❾ ❻ ❿ ❼ ❽ ❾...
- Page 21 ➞ ➞ ➞ ➞ ➞ ➞ ➞ ➞...
- Page 22 ➞ ➞ ➞ ➞...
- Page 23 ➞ ➞ ➞ ➞ ➞ ➞ ➞ ➞...
- Page 24 ➞ ➞ ➞ ➞ ➞ ➞ ➞ ➞ ➞...
- Page 25 ➞ ➞...
- Page 27 ➞ ➞ ➞...
- Page 31 ❻ ❶ ❼ ❽ ❶ ❷ ❹ ❽ ❸ ❾ ❷ ❸ ❾ ❺ ❿ ❹ ❶ ❷ ❺ ❸ ❻ ❹ ❶ ❺ ❼ ❷ ❻ ❸ ❼ ❹ ❽ ❺ ❾ ❻ ❿ ❼ ❽ ❾...
- Page 34 ➞ ➞ ➞ ➞ ➞ ➞ ➞ ➞...
- Page 35 ➞ ➞ ➞ ➞...
- Page 36 ➞ ➞ ➞ ➞ ➞ ➞ ➞ ➞...
- Page 37 ➞ ➞ ➞ ➞ ➞ ➞ ➞ ➞ ➞...
- Page 38 ➞ ➞...
- Page 40 MEMO ➞ ➞ ➞...
