English INDEX 1. FUNCTION DESCRIPTION..................3 2. OPENER PACKAGE CONTENTS ................5 3. IMPORTANT INSTALLATION INSTRUCTION ..............6 4. INSTALLATION STEPS....................7 4-1. MEASURE DOOR’S HIGHEST TRAVEL POINT............7 4-2. INSTALL H EADER B RACKET................7 4-3. INSTALL D OOR B RACKET T O D OOR...............8 4-4.
English 1. Functional description The B 100 Plus 600N and B 100 Plus 1000N operators may be used for sectional doors. B 100 PLUS B 100 PLUS TECHNICAL DATA 600N 1000N 230V/50Hz Supply voltage: Power(W): Door (travel) speed(mm/s): Maximum duty cycle(min):...
Page 4
English Internal release mechanism: The models have an internal release mechanism with which you can open the garage door by hand in emergencies or in the event of a power cut. The internal release mechanism is attached to the profile slide with a rope and a knob. By pulling the rope you uncouple the garage door from the opener and then you can open the door by hand.
English 2. Opener package contents The following items are included with the Garage Door Opener. The opener and rail are packaged with their respective carton. (A) OPENER (B) ACCESSOIRES a. Wall B racket (1x) b. D . oor B raket & Plate (1x) U Bracket (3x ) e.
English 3. Important installation instructions WARNING 1. READ AND FOLLOW ALL INSTALLATION INSTRUCTIONS 2. Check with the door manufacturer to determine if additional reinforcement is required to support the door prior to installation of the garage door opener. 3. Install garage door opener only on a properly balanced garage door .An improperly balanced door could cause seriously injury.
English 4. INSTALLATION STEPS Identify a sound structural support on header wall above garage door for header bracket mounting. Fasten it securely using lag screws (not provided) to structural supports of garage. 4-1. Measure door’s highest travel point: • Open door to its highest travel point and measure from the garage floor to the top of door. •...
English 4-3. Install d oor b racket t o d oor Mark the position of the holes and fix the anchor bracket to the upper end of the door with screws (not supplied). 4-4. Attach rail to opener head !WARNING! When fastening the rail to the opener, use only the screws provided.
English 4-5. Attach rail to header bracket • Support opener head slightly off the floor. • Lift the opposite end of the rail up to the header bracket. • Position rail end-stop within the openings in the header bracket. Insert clevis (e), and then attach cotter pin (g) to end of pin.
English 4-7. Connect arm to door and trolley • Make sure door is fully closed. • Pull the manual release cord on the trolley to disconnect trolley from chain or belt connector. Slide trolley to position it about 100mm-200mm away from the door. •...
English 4-9. Tension adjust The tension, can the adjusting screw clockwise until brush and the rail has the right position. 4-10. Rail installation Lock nut 2 Rail end, 3 Party neck bolt, 4 Rail, 5 Slider, 6 B lock Self-tapping screws, spring, 9 chain, 10 Pulley block,...
English 5. Control unit BATTERY POWER LIGHT RECEPTOR DISPLAY +24V PB GND PBSW + Allarm - A-SW CN1 = Input/output connector CNE = Encoder connector CNR = External receiver connector SD = Door contact MR = Right motor ML = Left motor POWER = Power supply connector BATTERY = Battery connector LIGHT = Courtesy light connector...
English 5-1. Control and safety devices connection wiring method: Function logic : OPEN - STOP - CLOSE - STOP - OPEN. Note: +24V accessoires power supply GND accessoires negative PB photocells contact PBSW START contact WALL SWITCH 5-2. Control unit programming Powering the unit you may see scrolling the numbers from 9 to 1 on the display.
English 5-4. Run learning Press “+” (OPEN) When the door reaches to the desired Press “SETTING” over 4 seconds position, leave “+” press “SETTING” to until the door is not in until the LED displays the letter “1”. t h e d e s i r e d o p e n confirm the opening position.
English 5-6. Use photoelectric switches The photocell input can be disabled through the display. Press “-” (CLOSE) over 4 seconds until the LED displays “-”, you can set the he status of the photocells. If you want the photocell active, press "+" (OPEN) until the LED displays "H".
English 6. Trouble shooting Fault Cause Solution Disconnection between Check the electrical No response for the outlet and /or the door opener and power operator, LED is off powder supply fuse supply The journey adjustment No response for the Re-adjust the journey operator is wrong - Check the balance...
3. This product was designed and built strictly for the use indicated in this documentation. Any other use, not expressly indicated here, could compromise the good condition/operation of the product and/or be a source of danger. BLEU by SEA declines all liability caused by improper use or different use in respect to the intended one.
Page 18
Tel. +39 0861 588341 r.a. Fax +39 0861 588344 http://www.seateam.com La SEA S.p.A. dichiara che i prodotti sopra citati sono conformi ai requisiti essenziali di sicurezza relativi ai prodotti entro il campo di applicabilità delle seguenti Direttive Comunitarie: SEA S.p.A. declares that the above mentioned products are conforming to the essential safety...
