4-BTV, 5-BTV, 6-BTV
Multiband HF
Vertical Antennas
New Assembly and
High Performance
Installation
Instructions
DXE-BTV-INST-INS - Rev 4
Cost: $7.95
To be certain to get optimum performance from this
vertical design, please assemble and install your new
antenna according to these DX Engineering Assembly
and High Performance Installation Instructions.
These instructions are intended to replace those
originally supplied by the manufacturer.
© DX Engineering 2016
1200 Southeast Ave. - Tallmadge, OH 344278 USA
Phone: (800) 777-0703 ∙ Tech Support and International: (330) 572-3200
Fax: (330) 572-3279 ∙ E-mail: DXEngineering@DXEngineering.com
- 1 -
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for DX Engineering 4-BTV
Summary of Contents for DX Engineering 4-BTV
- Page 1 Cost: $7.95 To be certain to get optimum performance from this vertical design, please assemble and install your new antenna according to these DX Engineering Assembly and High Performance Installation Instructions. These instructions are intended to replace those originally supplied by the manufacturer.
-
Page 2: Table Of Contents
4 BTV - Package Contents & Assembly ® Hustler 5 BTV - Package Contents & Assembly Six Blade Spider for the 4-BTV and 5-BTV only Three Blade Spider for the 5-BTV only 80 Meter Resonator and Whip Installation for the 5-BTV and 6-BTV ®... - Page 3 - or no - tuning and wide bandwidth but mediocre performance. DX Engineering decided to take this popular product and show how its performance could be greatly increased by proper installation, including the addition of an adequate radial ground system.
-
Page 4: Chapter 1 - Introduction Congratulations
BTV Series HF Base Vertical is mechanically and electrically superior to other brands, and will ® offer years of top performance. If the system is installed with the DX Engineering Hustler antenna options according to the recommendations and instructions in this manual, the full capabilities of this antenna are realized ®... -
Page 5: Hustler ® Btv Antennas
75/80 meter band by adding the RM-80S resonator and the 4457-1 three blade spider assembly on top of the 4-BTV. If the 75/80 meter resonator is attached to the 4-BTV, it may be desirable to guy the antenna above the 20 meter trap with small diameter polypropylene rope. -
Page 6: You Gotta Be Kidding Me
Do you need the high performance options now? No, you can get started with the basic system and add enhancements over time. Many hams that have added DX Engineering BTV antenna options have exclaimed the resulting higher performance was like getting a new antenna! -
Page 7: Chapter 2 - General Information
Chapter 2 - General Information Warning Overhead Power Line Safety Basic Tools Required Assembly Notes WARNING! INSTALLATION OF ANY ANTENNA NEAR POWER LINES IS DANGEROUS Warning: Do not locate the antenna near overhead power lines or other electric light or power circuits, or where it can come into contact with such circuits. -
Page 8: Chapter 3 - Common Starting Information
4. Install the Radial Plate and Radial System 10. Tuning 5. Install the Tilt Base Assembly 11. Add optional DX Engineering Add-On Kits 6. Mount the BTV base to the Tilt Base for 12, 17 and 60 meters and make adjustments... -
Page 9: Site Selection
The height of the mounting pipe above ground level of 20-23 inches will allow you to do either a basic installation, or an enhanced installation by adding the DX Engineering optional items described in this detailed manual. In some cases ham... -
Page 10: Concrete Or No Concrete - That Is The Question
Also, a driven or pounded pipe may be used on any ground-mounted vertical antenna installation, regardless of the number of radials used. DX Engineering recommends using a concrete base, as shown on page 9, when a high performance installation with many radials is planned. The reasons that a concrete base is recommended: 1. -
Page 11: Coaxial Cable To Mounting Pipe
Get the Best Performance From Your New Quarter-Wave Vertical Antenna To be certain to get optimum performance from this vertical design, please assemble and install your new antenna according to these DX Engineering Assembly and High Performance Installation Instructions. These instructions are intended to replace those originally supplied by ®... -
Page 12: Some Brief Words On Ground Mounting, Elevated Mounting, And Radial Wires
Height is not a requirement for HF Verticals. Unlike horizontally oriented antennas, ground mounted vertical antennas used for HF sky wave communications only require a radial system for performance. If an HF quarter-wave vertical antenna is elevated, then it requires resonant, quarter wavelength, tuned radials to be efficient and functional. -
Page 13: How To Put Radial Wires Down Without Digging
Next, connect the radials to the Radial Plate with wire terminal ends (which you can get at DX Engineering along with the radial wire) and stretch them out while arraying them evenly around the antenna. -
Page 14: Radial System Considerations
Install 30 to 60 radials for higher performance using one or more DX Engineering radial wire kits. The relaxed black PVC insulated 14 gauge stranded copper wire in our Radial Wire Kits is easy to handle and will last far longer than bare wire or wire mesh. - Page 15 Performance of the antenna is directly proportional to the number and length of radials. Many short radials are better than a few long radials. The stainless steel DX Engineering DXE-RADP-3 Radial Plate makes it easy to attach long-lasting radial wire connections.
- Page 16 Examples of properly installed radials using the optional DX Engineering DXE-RADP-3 Radial Plate K7CIE N8DOD N5RMM W0ZSP - 16 -...
-
Page 17: Chapter 5 - Basic Btv Assembly Assembling Vertical Aluminum Antenna Sections & Element Clamps
4 BTV - Package Contents & Assembly ® Hustler 5 BTV - Package Contents & Assembly Six Blade Spider for the 4-BTV and 5-BTV only Three Blade Spider for the 5-BTV only 80 Meter Resonator and Whip Installation for the 5-BTV and 6-BTV ®... - Page 18 Assembly is easier if the tubing sections are pre-marked. A dark color felt-tip marker works well. Locate the hardware pack containing the element clamps. Refer to the following 4-BTV, 5-BTV or 6-BTV assembly instructions, depending on your antenna, for element clamps, tubing and trap placement.
- Page 19 4-BTV Antenna Contents Part Description Number 4098-1 Bracket Assembly - Assembled 4190 Top Tube Section - 56" 4087-1 Lower Tube Section - 72" 4087-2 Intermediate Tube Section - 20" 4090-1 Ten Meter Trap - Orange 4090-2 Fifteen Meter Trap - Red...
- Page 20 Assembly of the 4-BTV Antenna Vertical Sections Assemble the 4-BTV as shown in these pictures. The dimensions between the aluminum sections and the traps are shown in the chart below. The six bladed spider is mounted just above the 20 Meter trap.
-
Page 21: Hustler
5-BTV Antenna Contents Part Description Number 4098-1 Bracket Assembly - Assembled 4190 Top Tube Section - 56" 4087-1 Lower Tube Section - 72" 4087-2 Intermediate Tube Section - 20" 4090-1 Ten Meter Trap - Orange 4090-2 Fifteen Meter Trap - Red 4090-3 Twenty Meter Trap - Green 5481... - Page 22 Assembly of the 5-BTV Antenna Vertical Sections Assemble the 5-BTV as shown in these two pictures. The dimensions between the aluminum sections and the traps are shown in the chart below. The six bladed spider is mounted just above the 20 Meter trap. The three blade spider is mounted just below the 80 Meter resonator.
-
Page 23: 80 Meter Resonator And Whip Installation For The 5-Btv And 6-Btv
Six Blade Spider for the 4-BTV and 5-BTV only Assemble the 6 bladed spider using the parts shown. This spider is used on both the 4-BTV and 5- BTV antennas. The spider mounts on the antenna just above the 20 meter trap. -
Page 24: Btv - Package Contents & Assembly
6-BTV Antenna Contents Part Description Number 4087-1 Lower Tube Section - 72" 4087-11 Intermediate Tube Section - 24" 4087-2 Intermediate Tube Section - 20" 4090-1 Ten Meter Trap - Orange 4090-2 Fifteen Meter Trap - Red 4090-3 Twenty Meter Trap - Green 4090-4 Thirty Meter Trap - Blue 4098-1... - Page 25 Assembly of the 6-BTV Antenna Vertical Sections Assemble the 6-BTV as shown in these two pictures. The dimensions between the aluminum sections and the traps are shown in the chart below. - 25 -...
-
Page 26: Hustler Base Assembly
® Hustler Base Assembly ® The Hustler Base Assembly (HSR-4098-1) is pre-assembled from the factory. The following diagram shows all the parts, including the parts that are used for basic mounting on a 1 inch to 1-3/4 inch OD mounting pipe using the included U-Bolts from New-Tronics. - 26 -... -
Page 27: Optional Reinforced Lower Tube Assembly
Any Hustler BTV antenna may have some slight bend in the lower first 6 foot section of the antenna. The tight tolerances between DX Engineering sizes of aluminum tubing are such, that even a slight bend in one of the tubes may be enough to prevent close tolerance tubes to be sleeved over each other. -
Page 28: Mating The Vertical Sections To The Base Section
6-BTV Approximate Starting Dimensions Type of Installation On a roof with 4 ft. pipe and radials 2-1/8" Ground Mounted - No Radials 0" Ground Mounted with Radials 0" (BTV base shown mounted to the optional DX Engineering Tilt Base) - 28 -... -
Page 29: Installing Radials & Feedline On The Hustler Base
® Hustler base using the supplied lugs for coax connections. For radial wires, the better alternative is to use an optional DXE-RADP-3 DX Engineering Radial Plate. Additionally, the feedline can be connected using other methods using DX Engineering custom made feedline options as shown in Chapter 6. -
Page 30: Coax Rf Choke
The following diagram shows the coax cable choke system which offers modest performance on some bands. The better alternative is the optional DX Engineering DXE-VFCC-H05-A Vertical Feedline Current Choke which is specifically engineered and manufactured to help eliminate RF feedback from a resonant vertical antenna. -
Page 31: Chapter 6 - Dx Engineering Enhanced Antenna Systems Special Hustler
BTV Packages Available from DX Engineering ® Hustler 4-BTV Package - High Performance HF Vertical System - DXE-HSR-4BTV-P1 ® For a high performance HF ground mounted vertical system, the DX Engineering Hustler 4-BTV Package provides 40/20/15/10 meter band coverage. ® Hustler 5-BTV Package - High Performance HF Vertical System - DXE-HSR-5BTV-P1 ®... - Page 32 Connectors at each end – Call to order your length (1) Antenna Analyzer for precise antenna tuning - DX Engineering carries a variety of analyzers for your antenna needs - check the web site or call for assistance ...
-
Page 33: Radial Plate To Mounting Pipe
BTV base, with optional Tilt Base, Radial Plate and VFCC shown below). DXE-RADP-3 Radial Plate Installation ® The picture to the right shows the Hustler BTV base, DXE-TB-3P Tilt Base DXE-RADP-3 Radial Plate DXE-VFCC-H05-A Vertical Feedline Choke DX Engineering Radial Wires - 33 -... -
Page 34: Attaching Ground Radial Wires To The Radial Plate
There are optional DX Engineering Radial Wire Kits available. DXE-RADW-500K/BD contains a 500 foot spool of 14 gauge copper stranded wire with black PVC insulation, 20 Terminal Lugs and 100 Steel or Biodegradable Lawn Staples. -
Page 35: Dxe-Tb-3P Tilt Base Mounting Plate To The Ground Mounting Pipe
Tilt Base Mounting Plate to Mounting Pipe DXE-TB-3P Install the Tilt Base to the 2" mounting pipe using two DXE-SSVC-2P Stainless Steel V-Clamps allowing approximately 7" clearance between the bottom of the tilt base plate, to the top surface of the DXE-RADP-3 Radial Plate as shown to the right. -
Page 36: Testing The Dxe-Tb-3P Tilt Base
Testing the DXE-TB-3P Tilt Base Test the tilt function to ensure proper clearances. Standing in front of the Tilt Base, lift the antenna base section, slide it to the right, and let it down slightly until the lower outside bolt is resting in the pivot point. -
Page 37: Dxe-Omnitilt-1P Omni-Tilt™ Tilt Base
All of the hardware used in the OMNI-TILT™ Base is Stainless Steel to ensure long and dependable service. The DX Engineering OMNI-TILT™ is safe to use and is available with a wide range of optional mounting hardware to maximize the use of this tilt base with all types of vertical antennas. -
Page 38: Mounting The Omni-Tilt™ Tilt Base To The Ground Mounting Pipe
Mounting the OMNI-TILT™ to the Ground Mounted Pipe Two DXE-OTMC-250P Mounting Clamp Kits are used to mount the OMNI-TILT™ Tilt Base to the ground mounted mounting pipe. DXE-OTMC-250P (Qty 2 are required) Mounting Clamps 2 - DXE-OTMC-250P Mounting Clamps with Hardware Kits For mounting to a 1-1/4”... -
Page 39: Mounting The Hustler Btv Base To The Omni-Tilt™ Tilt Base
Mounting a Hustler BTV Vertical Antenna to the OMNI-TILT™ Tilt Base Mounting the Hustler BTV Series antenna to the OMNI-TILT™ Tilt Base requires installation of four hex head bolts, Flat, Split Lock washers and Hex Nuts. DXE-TVA-HWK Parts List DXE-TVA-HWK Mounting Hardware Kit For Trap Verticals (Hustler BTV series, Hy-Gain AVQ series) 1/4”-20 x 1”... -
Page 40: Alternate Feedpoint Connections
Alternate Optional Feedpoint Connections The DXE-AOK-DCF Direct Coax Feed assembly by DX Engineering for the Hustler® BTV series antennas allows direct connection from a coaxial cable with a PL-259 connector. Features Laser Cut Stainless Steel Bracket and Stainless Steel Hardware ... -
Page 41: The Dxe-Vfcc-H05-A Vertical Feedline Current Choke
A second method that may be used is the connection of a pigtail from the feedline connection on ® the Hustler BTV base section to the Radial Plate using a DXE-8X19-RT 19" Pigtail for the ® Hustler BTV Base to PL-259 along with a DXE-UHF-FDFB-KIT SecureMount™... - Page 42 Using the two tinned copper braids supplied with the optional DXE-VFCC-H05-A Vertical Feedline Choke, connect them as shown in the VFCC manual as well as being shown below to the Radial Plate and the antenna feedpoint. Make sure the proper braid is connected to the feedpoint (refer to the VFCC manual for details).
-
Page 43: Chapter 7 - Tuning
Trap calibration adjustment will NOT void the warranty of a Hustler antenna purchased from DX Engineering. The antenna traps will not be harmed by performing this tuning procedure. Note: For the purposes of these instructions the term “resonance” or “resonant frequency” is defined as the point of lowest SWR and may be used interchangeably. -
Page 44: Hustler Traps
are not realistic. The frequency where the lowest SWR occurs will likely result in analyzer readings that are not perfect.] If you only have an SWR or power meter use it at the antenna. Use your transceiver or analyzer and plot a chart of SWR measurements at several frequencies across the range below and above your target frequency, repeating after every antenna adjustment. - Page 45 It is not necessary to remove each trap from the larger tubing below it, or measure it, in order to make the trap sleeve adjustment to tune the antenna. The lettered dimensions charted below are only starting points and will normally be changed for fine tuning. 4-BTV 5-BTV 6-BTV...
-
Page 46: Hustler Trap Calibration - Resonance Adjustment Procedure
® Hustler Trap Calibration - Resonance Adjustment Procedure ® Tune all Hustler BTVs starting with the 10 meter trap, because any adjustment done there affects the rest of the antenna, regardless of the number of bands it has. 1. Slightly loosen the band clamp at the bottom of the trap sleeve, NOT the clamp on the larger tube below. -
Page 47: Tuning The 80 Meter Resonator Whip For The 5-Btv And 6-Btv
One whip cut for the lower frequency in the CW area of the band, and another whip cut for the higher end in the SSB area of the band. (Part Number HSR-49-04-80S from DX Engineering) Changing the whip is made easier when using the DX Engineering Tilt Base. -
Page 48: Chapter 8 - Guying The Hustler
The remaining guys help stabilize the vertical in three directions when being raised. The DX Engineering Vertical Guying Kits have been designed to be... -
Page 49: Chapter 9 - Reference Information
If you must elevate your antenna, Pre-Cut Radial Wire Sets are also available from DX Engineering. An antenna analyzer such as the MFJ-259B or an SWR meter is used to make resonant, elevated ®... -
Page 50: The Quarter-Wave Vertical On A Metal Roof
The Quarter-Wave Vertical on a Metal Roof Over the years, many Amateur Radio operators have successfully used a metal roof as the ground plane or radial system for their quarter-wave HF vertical antenna. This is possible with a metal roof on a home, barn, garage, carport, RV, porch and metal sheds or awnings, and even on commercial buildings. - Page 51 DXing benefits of quarter-wave vertical! Consider the DX Engineering Vertical Feedline Current Choke kit model DXE-VFCC-H05-A, to make up for deficiencies in the metal "ground plane" or radial system. This choke and its properly mounted insulated shelf kit isolates the feedline, balances currents on the system for maximum signals, and offers the additional advantages of reduced noise and RFI/TVI.
-
Page 52: What Trap Do I Have
What Trap Do I Have? In some cases the trap you have may not be easily identified. During manufacturing, New-Tronics applies a colored label to the trap sleeve, just below the trap cover. 10M = Orange, 15M = Red, 20M = Green and 30M is Blue. If your trap label is missing, you will have to open up the trap and count the turns of wire on the internal coil. -
Page 53: Hustler Btv Replacement Parts Diagram
® Hustler BTV Replacement Parts Diagram - 53 -... -
Page 54: Weatherproofing Coaxial Cable Connections
Use the TES-06132 as an overwrap to give the assembly UV protection. Cover the TES-2155 splicing tape completely. Lightning Protection - For Any Installation Proper lightning protection and grounding is a prudent investment for any Amateur Radio antenna installation. DX Engineering offers general grounding information, specific examples with available ® components, PolyPhaser and Alpha Delta protectors for safe and worry-free antenna installations. -
Page 55: Hustler ® Btv Specifications
Antenna Specifications Copyright © New-Tronics Antenna Corporation - 225 Van Story St. - Mineral Wells, Texas 76067 Re-printed with permission - 55 -... - Page 56 Copyright © New-Tronics Antenna Corporation - 225 Van Story St. - Mineral Wells, Texas 76067 Re-printed with permission - 56 -...
-
Page 57: Chapter 10 - Additional Operating Bands
DXE-AOK-12M Add-On-Kit 12M for the Hustler BTV Series Verticals The patent pending DX Engineering DXE-AOK-12M kit adds 12 meter coverage to the Hustler® BTV series of vertical antennas without giving up any existing band coverage. This kit will operate across the entire 12M band with an SWR of 1.5:1 or less. No disassembly of the existing antenna is required, simply bolt this kit on your BTV, make some minimal tuning adjustments and you're on the air with an additional band. -
Page 58: Chapter 11 - Recommended Accessory Items
BTV Antennas With a patented DX Engineering Tilt Base, operators can raise or lower their BTV vertical in seconds while leaving the base plate securely attached to the mounting pipe or post. One person can service the antenna - no more climbing ladders or removing brackets. -
Page 59: For Quick Tilt Action
Tilt Base a 'must have' for all types of vertical antennas. The OMNI-TILT™ is patterned on the same proven safe technology as the patented DX Engineering SAF-T-TILT™ and the patented DXE-TB- 3P Tilt Bases, which are designed to prevent the antenna from falling when the fasteners are loosened. The user simply lifts the OMNI-TILT™... -
Page 60: For Tuning
The DXE-RLT - Reinforced Lower Tube Assembly for the Hustler 4-BTV, 5-BTV or 6-BTV Vertical Antenna is a custom made aluminum, sleeved, double wall, tube assembly that replaces the first six foot aluminum section of the Hustler BTV Series antenna. -
Page 61: Additional Accessories For Your Hustler ® Btv
DXE-RADP-3 - Radial Plate, Stainless Steel w/20 sets Radial Attach Hardware, up to 3" pipe Unique enough to be covered by two US Patents, the DX Engineering Radial Plate is meant for those of you that have or are building a quarter wave vertical antenna and who want an easy, neat and effective way to connect those essential radial wires and the coax to your vertical antenna for the lowest takeoff angle and strongest signals. - Page 62 DXE Radial Wire Kits for #14 Radial and Antenna Wire. DXE-RADP-1HWK - Radial Plate Wire Attachment Hardware Kit - Stainless Steel 20 Sets of ALL Stainless Steel Radial Hardware for use with the DX Engineering Stainless Steel Radial Plate. ...
- Page 63 DXE-T001 - DX Engineering SO-239 Connector Installation Tool Kit This DX Engineering SO-239 connector installation tool kit offers an easier installation of chassis or bulkhead mount SO-239 coaxial connectors. Having the right tools can make all of the difference in your shack, and this handy DXE tool provides you with a special dual-use stainless steel wrench, plus a multipurpose 6-in-1 screwdriver/nut driver tool.
-
Page 64: Technical Support And Warranty
DX Engineering Warranty All products manufactured by DX Engineering are warranted to be free from defects in material and workmanship for a period of one (1) year from date of shipment. DX Engineering’s sole obligation under these warranties shall be to issue credit, repair or replace any item or part thereof which is proved to be other than as warranted;...
