Adjustment Using the
Menus

Items

The screen menu of this monitor consists of the
following items.
STATUS menu (the items indicate the
current settings.)
For SDI input or OPTION input

FORMAT

RGB RANGE

COLOR TEMP

BRIGHTNESS

CONTRAST

CHROMA

COLOR SPACE/GAMMA

BACKLIGHT

SDI PAYLOAD ID
INPUT: Input
PAYLOAD ID
VIDEO STANDARD
SAMPLING STRUCTURE
BIT DEPTH
PICTURE RATE
SCANNING METHOD
LINK NUMBER
MODEL NAME
SERIAL NO.
SOFTWARE VERSION
OPTION MODEL NAME
1)
SERIAL NO.
SOFTWARE VERSION
For HDMI input
FORMAT
RGB RANGE
COLOR TEMP
BRIGHTNESS
CONTRAST
CHROMA
COLOR SPACE/GAMMA
BACKLIGHT
HDMI
INPUT
PIXEL ENCODING
COLOR DEPTH
MATRIX
RGB RANGE
MODEL NAME
SERIAL NO.
1)
1)
SOFTWARE VERSION
OPTION MODEL NAME
1)
SERIAL NO.
SOFTWARE VERSION
1) This item appears only when the optional BKM-XP1 4K SxS
Player (OPTION) is mounted.
COLOR TEMP/COLOR SPACE/
GAMMA menu
COLOR TEMP
MANUAL ADJUSTMENT
ADJUST GAIN/BIAS
COPY FROM
COLOR SPACE
GAMMA
USER CONTROL menu
APERTURE
BACKLIGHT CONTROL
BACKLIGHT
USER CONFIG menu
4K/QFHD INPUT SETTING
INTERFACE FORMAT
IMAGE DIVISION (SDI input only)
SIGNAL FORMAT
INPUT
RGB RANGE
HDMI AUTO (HDMI input only)
2K/HD INPUT SETTING
INTERFACE FORMAT
SIGNAL FORMAT
INPUT
1080I/PSF (SDI input only)
24PSF
25PSF/50I
30PSF/60I
RGB RANGE
HDMI AUTO (HDMI input only)
FUNCTION BUTTON SETTING
F1 BUTTON
F2 BUTTON
F3 BUTTON
F4 BUTTON
F5 BUTTON
F6 BUTTON
F7 BUTTON
MARKER SETTING
MARKER
ASPECT MARKER
CENTER MARKER
AREA MARKER
BRIGHTNESS
ASPECT MAT
1)
1)

Adjustment Using the Menus

13
