CONCRETE SAW

PARTS LIST

OPERATOR'S
MANUAL
MODEL
C14
(FEB-2015)

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the C14 and is the answer not in the manual?

Questions and answers

Related Manuals for Diamond Products C14

Summary of Contents for Diamond Products C14

  • Page 1: Concrete Saw

    CONCRETE SAW PARTS LIST OPERATOR’S MANUAL MODEL (FEB-2015)
  • Page 2 ORIGINAL INSTRUCTIONS For your personal safety, READ and UNDERSTAND before using. SAVE THESE INSTRUCTIONS FOR FUTURE REFERENCE. Warning: On tools equipped with over load protection, when motor has been cut off due to over load, always switch on machine with no load for at least 3 minutes to reduce temperature before returning to operation to avoid burn out of the motor.
  • Page 3 SPECIFICATIONS Model Power Input North America: 15 A, Other Regions: 110-120V:1700W, 220-240V: 2800W Voltage North America: 115V~60Hz, Other Regions: See Machine Nameplate Rated speed/ min n=4500 min Blade Diameter 355mm (14") Arbor 20mm or 25.4 (1 in.) Max. Cutting Depth 125mm (5") Weight 7.9kg (17 Lbs) (8.3kg (18 Lbs) with guide rollers)

  • Page 4: General Power Tool Safety Warnings

    GENERAL POWER TOOL SAFETY WARNINGS WARNING! Read all safety warnings and all instructions. Failure to follow the warnings and instructions may result in electric shock, fire and/or serious injury. Save all warnings and instructions for future reference. The term “power tool” in the warnings refers to your mains operated (corded) power tool or battery-operated (cordless) power tool.
  • Page 5 Remove any adjusting key or wrench before turning the power tool on. A wrench or a key left attached to a rotating part of the power tool may result in personal injury. Do not overreach. Keep proper footing and balance at all times. This enables better control of the power tool in unexpected situations.
  • Page 6 ………..Rated speed …..revolutions or reciprocation per minute ..Protective earth ..Warning of general danger ..read these instructions ..Always wear eye protection ..Always wear a dust mask..Always wear hearing protection ..Wear safety-approved hard hat ..DANGER! Keep hands away from cutting area and the blade. do not dispose of electric tools, accessories and packaging together with household waste material SAFETY INSTRUCTIONS FOR CUTTING-OFF OPERATIONS Cut-off machine safety warnings...
  • Page 7 power tool or wheel is dropped, inspect for damage or install an undamaged wheel. After inspecting and installing the wheel, position yourself and bystanders away from the plane of the rotating wheel and run the power tool at maximum no load speed for one minute. Damaged wheels will normally break apart during this test time.
  • Page 8 Never place your hand near the rotating accessory. Accessory may kickback over your hand. Do not position your body in line with the rotating wheel. Kickback will propel the tool in direction opposite to the wheel’s movement at the point of snagging. Use special care when working corners, sharp edges etc.

  • Page 9: Grounding Instructions

    GROUNDING INSTRUCTIONS All grounded, cord-connected tools: In the event of a malfunction or breakdown, grounding provides a path of least resistance for electric current to reduce the risk of electric shock. This tool is equipped with an electric cord having an equipment-grounding conductor and a grounding plug.

  • Page 10: Electrical Connection

    ELECTRICAL CONNECTION The network voltage must conform to the voltage indicated on the tool name plate. Under no circumstances should the tool be used when the power supply cable is damaged. A damaged cable must be replaced immediately by an authorized Customer Service Center. Do not try to repair the damaged cable yourself.

  • Page 11: Diamond Blades

    DIAMOND BLADES Allowed Types Of Blades This machine may use diamond blades only. NOTE: Abrasive wheels may not be used on this machine. • Only use either segmented or continuous rim diamond blades. • If the diamond blades are segmented, the maximum allowable peripheral gap between segments is 10mm and must be with a negative rake angle.

  • Page 12: Sharpening A Glazed Blade

    (the diamonds not exposed) and the blade becomes dull (diamond segments polish smooth). This is called glazing and luckily the blade can be de-glazed (sharpened). If the blade seems to refuse to cut anymore, you know that it is glazed. ”Sharpening a Glazed Blade”...

  • Page 13: Adjusting The Blade Guard

    Inspect the blade before use. It must not be cracked, warped or damaged in any way that would cause a hazard in operation. Loose diamond segments can be ejected at high speed, causing possible injury. Always check that the diamond segments are not under cut. If the diamond segments are thinner or nearly thinner than the blade core, the kerf will be too tight fitting and could easily lead to kickback.

  • Page 14: Guide Roller Assembly

    WARNING: Always use the PRCD (GFCI) when operating with water WARNING: Never allow water to enter the motor. It could lead to an electric shock. WARNING: Check all connections of the water feed system to ensure Water Feed Valve there are no leaks. Inspect hoses and other critical parts which could deteriorate.

  • Page 15: Operation

    Overheat Thermal Protection If the temperature of the motor gets too high, the thermal protection will shut the motor down. The switch must be first shut off and then restarted. When this happens, do not immediately start cutting after restarting the motor.
  • Page 16 the blade being pinched. Thus, make the bottom horizontal cut first, then the sides and finally make the top horizontal cut last. • Make note of the weight of the workpiece and the direction which it will fall when it is cut through. • Whenever there is a situation where severing the workpiece will cause a hazardous situation, leave a tab of material intact and finish off the operation with a chisel or the like. Cutting Technique •...

  • Page 17: Maintenance And Cleaning

    MAINTENANCE AND CLEANING This machine operates in a very harsh environment. The slurry created by wet cutting and the dust created by dry cutting gets sucked into the motor’s cooling slots and enters the motor. The slurry of brick and concrete contains salts and other corrosive substances which will severely shorten the life of the motor or cause electrical shorts if allowed to accumulate.
  • Page 18 WIRING...

  • Page 19: Exploded View

    EXPLODED VIEW...
  • Page 20 C14 PARTS LIST FEB-2015 ITEM PART NO. DESCRIPTION 6078401 CORD W-PLUG 14A x 3C x 3M - SJTW 6078402 INLINE PRCD 110V CORD ARMOR 6078403 6078404 CORD CLIP 6078405 SCREW M4 x 14 6078406 SWITCH LOCK-OFF 6078407 SWITCH BUTTON 6078408...
  • Page 21 C14 PARTS LIST FEB-2015 ITEM PART NO. DESCRIPTION 6078442 BEVEL GEAR M2.35 x 37T 6078443 SPACER Ø16 x Ø22 x 9.7 6078444 SPINDLE PARALLEL KEY 5 x 5 x 10 6078445 6078446 INTERNAL SNAP RING R-62 6078447 BEARING 6206-ZZ TPI...
  • Page 22 C14 PARTS LIST FEB-2015 ITEM PART NO. DESCRIPTION 6078483 HOSE JOINER 6078484 BEADED CABLE TIE KTV-150BK 6078485 LED LIGHT 6078486 SPLASH GUARD 6078487 WIRE HOSE CLAMP 6078488 CLIP-FEMALE...

  • Page 23: Eq U I Pm En T A N D Pa R T S

    (1) year from the date of shipment to Customer. The responsibility of Diamond Products under this Warranty is limited to replacement or repair of defective parts at Diamond Products’ Elyria, Ohio...
