- Page 1 CONCRETE SAW PARTS LIST OPERATOR’S MANUAL MODEL C14 PRO JULY-2019...
-
Page 2: Concrete Saw
CONCRETE SAW ORIGINAL INSTRUCTIONS For your personal safety, READ and UNDERSTAND before using. SAVE THESE INSTRUCTIONS FOR FUTURE REFERENCE. 115V Model Warning: On tools equipped with over load protection, when motor has been cut off due to over load, always switch on machine with no load for at least 3 minutes to reduce temperature before returning to operation to avoid burn out of the motor. - Page 3 SPECIFICATIONS Model C14 PRO Power Input North America: 25 A, Other Regions: 110-120V:1700W, 220-240V: 2800W Voltage North America: 115V~60Hz, Other Regions: See Machine Nameplate Rated speed/ min n=4500 min Blade Diameter 355mm (14") Arbor 25.4 (1 in.) Max. Cutting Depth 125mm (5")
-
Page 4: General Power Tool Safety Warnings
GENERAL POWER TOOL SAFETY WARNINGS WARNING! Read all safety warnings and all instructions. Failure to follow the warnings and instructions may result in electric shock, fire and/or serious injury. Save all warnings and instructions for future reference. The term “power tool” in the warnings refers to your mains operated (corded) power tool or battery-operated (cordless) power tool. - Page 5 Remove any adjusting key or wrench before turning the power tool on. A wrench or a key left attached to a rotating part of the power tool may result in personal injury. Do not overreach. Keep proper footing and balance at all times. This enables better control of the power tool in unexpected situations.
-
Page 6: Cut-Off Machine Safety Warnings
………..Rated speed …..revolutions or reciprocation per minute ..Protective earth ..Warning of general danger ..read these instructions ..Always wear eye protection ..Always wear a dust mask..Always wear hearing protection ..Wear safety-approved hard hat ..DANGER! Keep hands away from cutting area and the blade. do not dispose of electric tools, accessories and packaging together with household waste material SAFETY INSTRUCTIONS FOR CUTTING-OFF OPERATIONS Cut-off machine safety warnings... - Page 7 power tool or wheel is dropped, inspect for damage or install an undamaged wheel. After inspecting and installing the wheel, position yourself and bystanders away from the plane of the rotating wheel and run the power tool at maximum no load speed for one minute. Damaged wheels will normally break apart during this test time.
- Page 8 Never place your hand near the rotating accessory. Accessory may kickback over your hand. Do not position your body in line with the rotating wheel. Kickback will propel the tool in direction opposite to the wheel’s movement at the point of snagging. Use special care when working corners, sharp edges etc.
-
Page 9: Grounding Instructions
GROUNDING INSTRUCTIONS All grounded, cord-connected tools: In the event of a malfunction or breakdown, grounding provides a path of least resistance for electric current to reduce the risk of electric shock. This tool is equipped with an electric cord having an equipment-grounding conductor and a grounding plug. -
Page 10: Electrical Connection
ELECTRICAL CONNECTION The network voltage must conform to the voltage indicated on the tool name plate. Under no circumstances should the tool be used when the power supply cable is damaged. A damaged cable must be replaced immediately by an authorized Customer Service Center. Do not try to repair the damaged cable yourself. -
Page 11: Diamond Blades
DIAMOND BLADES Allowed Types Of Blades This machine may use diamond blades or abrasive wheels. • Only use either segmented or continuous rim diamond blades. • If the diamond blades are segmented, the maximum allowable peripheral gap between segments is 10mm and must be with a negative rake angle. -
Page 12: Sharpening A Glazed Blade
glazing and luckily the blade can be de-glazed (sharpened). If the blade seems to refuse to cut anymore, you know that it is glazed. ”Sharpening a Glazed Blade” See below: Never use a sharp motion or the blade will be damaged. Conversely, don’t feed too gently or the diamond segments will become glazed. -
Page 13: Adjusting The Blade Guard
Inspect the blade before use. It must not be cracked, warped or damaged in any way that would cause a hazard in operation. Loose diamond segments can be ejected at high speed, causing possible injury. Always check that the diamond segments are not under cut. If the diamond segments are thinner or nearly thinner than the blade core, the kerf will be too tight fitting and could easily lead to kickback. - Page 14 WARNING: Always use a PRCD (GFCI) protected supply when operating with water WARNING: Never allow water to enter the motor. It could lead to an electric shock. WARNING: Check all connections of the water feed system to ensure there are no leaks. Inspect hoses and other critical parts which could deteriorate.
-
Page 15: Operation
must be first shut off and then restarted. When this happens, do not immediately start cutting after restarting the motor. Always run the machine at no load for a few minutes to return to a normal operating temperature before continuing. CAUTION: The motor will be damaged if it is repeatedly overloaded or overheated. -
Page 16: Cutting Technique
Cutting Technique • Holding the machine with both hands to resist the start up torque, press the release button and then squeeze the trigger switch. • Allow the machine to reach full speed before contacting the workpiece. • Adjust the water flow as needed by turning the water feed valve. •... -
Page 17: Maintenance And Cleaning
pin can insert fully, then turn 90 degrees to lock in place. Ensure that it pivots freely. finally, attach the vacuum hose. Removal is the opposite of mounting. Note: Always ensure the vacuum cleaner's dust bag is not too full. An overfilled dust bag will have reduced dust collection efficiency which could result in poor dust control. - Page 18 WIRING...
-
Page 19: Exploded View
EXPLODED VIEW... - Page 20 C14 PRO PARTS LIST JULY-2019 ITEM PART NO. DESCRIPTION 6078401 POWER SUPPLY CABLE UL-14A x 3C x 3M-SJTW 6078403 CORD ARMOR 6078404 CABLE CLIP 6078405 SCREW M4 x 14 6078406 TRIGGER SWITCH LOCK-OFF 6078408 SCREW M4 x 16 6078501 ELECTRONICS UNIT 110V...
- Page 21 C14 PRO PARTS LIST JULY-2019 ITEM PART NO. DESCRIPTION 6078445 PARALLEL KEY 5 x 5 x 10 6078446 INTERNAL CIRCLIP R-62 6078447 BALL BEARING 6206 6078448 GEAR PLATE 6078449 L-CLEVIS PIN 6078450 E-CLIP E-5 6078451 SCREW M5 x 25 6078452 OIL SEAL Ø25 x Ø35 x 5...
- Page 22 C14 PRO PARTS LIST JULY-2019 ITEM PART NO. DESCRIPTION 6078488 CLIP-FEMALE 6078489 PLASTIC RING Ø74 x Ø91.5 x 0.25 6078490 SCREW M4 x 20 6078491 SPRING 6078492 SCREW M4 x 6 6078497 O-RING Ø35 x 1.5 6078498 BOLT M10 6078496...
- Page 23 NOTES ____________________________________________________ ____________________________________________________ ____________________________________________________ ____________________________________________________ ____________________________________________________ ____________________________________________________ ____________________________________________________ ____________________________________________________ ____________________________________________________ ____________________________________________________ ____________________________________________________ ____________________________________________________ ____________________________________________________ ____________________________________________________ ____________________________________________________ ____________________________________________________ ____________________________________________________ ____________________________________________________ ____________________________________________________ ____________________________________________________ ____________________________________________________ ____________________________________________________ ____________________________________________________ ____________________________________________________ ____________________________________________________ ____________________________________________________ ____________________________________________________ ____________________________________________________ ____________________________________________________...
- Page 24 (1) year from the date of shipment to Customer. The responsibility of Diamond Products under this Warranty is limited to replacement or repair of defective parts at Diamond Products’ Elyria, Ohio...
