Adjust the incline of the treadmill as desired.
3
To change the incline of the
treadmill, press the top or bot-
tom of the incline control until
the desired incline level is
reached.
Follow your progress with the four displays.
4
Speed display—This
display shows the speed
of the walking belt.
Time display—This
display shows the
elapsed time.
Distance display—
This display shows the
distance that you have
walked or run.
Cals/Fat Cals/Pulse
Arrow
display—This display
shows the approximate
numbers of calories and
fat calories you have
burned. (See Fat
Burning on page 17.)
Every few seconds, the
display will change
from one number to the
other. Arrows in the
display will indicate
which number is cur-
rently shown. Note:
When the chest pulse sensor is worn, this display
will also show your heart rate.
To reset the displays at any time, press the
On/Reset button.
When you are finished exercising, stop the
5
walking belt and remove the key.
Step onto the foot rails, stop the walking belt, and
remove the key from the console. The displays will
turn off a few minutes after the key is removed.
Note: To conserve the batteries, the displays
will automatically turn off any time that the
walking belt is stopped and the On/Reset but-
ton is not pressed for a few minutes.
HOW TO SELECT KILOMETRES AND MILES
The console can display distance and speed in either
kilometres or miles. To change the unit of measure-
ment, first UNPLUG THE POWER CORD. Next, re-
move the screws attaching the console to the console
base. Lift the console a few inches, being careful not to
pull on the wires, and turn the console over. Locate the
small switch on the back of the console. Move the
switch up or down to select kilometres or miles.
Reattach the console to the console base. Next, re-
move one of the batteries from the console for
about five seconds and then reinsert it. This will
reset the console.
Console
Screws
Switch
Screws
12

OPERATION AND ADJUSTMENT

THE PERFORMANT LUBE TM WALKING BELT
Your treadmill features a walking belt coated with PERFORMANT LUBE
TANT: Never apply silicone spray or other substances to the walking belt or the walking platform. Such
substances will deteriorate the walking belt and cause excessive wear.
HOW TO PLUG IN THE POWER CORD
This product must be earthed. If it should malfunction or break
down, earthing provides a path of least resistance for electric
current to reduce the risk of electric shock. This product is equipped
with a cord having an equipment-earthing conductor and an earth-
ing plug.
Two power cords are included. Select the one that will fit your
outlet. Refer to drawing 1. Plug the indicated end of the power
cord into the socket on the treadmill. Next, lift the tab on the
ferrite box and clamp the ferrite box around the power cord.
The ferrite box should not be allowed to slide along the power
cord. Fasten the included plastic tie just behind the ferrite box
and cut off the excess plastic tie. Refer to drawing 2. Plug the
power cord into an appropriate outlet that is properly installed
and earthed in accordance with all local codes and ordinances.
Important: The treadmill is not compatible with GFCI-equipped
outlets.
If the power cord is damaged, it must be replaced with a manufac-
turer-recommended power cord.
DANGER:
Improper connection of the
equipment-earthing conductor can result in an in-
creased risk of electric shock. Check with a qualified
electrician or serviceman if you are in doubt as to
whether the product is properly earthed. Do not mod-
ify the plug provided with the product—if it will not fit
the outlet, have a proper outlet installed by a qualified
electrician.
TM , a high-performance lubricant. IMPOR-
1
Socket on treadmill
Ferrite Box
Plastic
Tab
2
Outlet
9
Tie
