HOW TO PUT ON THE CHEST PULSE SENSOR
The chest pulse sensor consists of two components:
the chest strap and the sensor unit (see the drawing
below). Insert the tab on one end of the chest strap into
one end of the sensor unit, as shown in the inset draw-
ing. Press the end of the sensor unit under the buckle
on the chest strap. The tab should be flush with the
front of the sensor unit.
Chest Strap
Tabs
Tab
Sensor
Buckle
Sensor Unit
Unit
Next, wrap the
chest pulse sen-
sor around your
chest and attach
the other end of
the chest strap to
the sensor unit.
Adjust the length
of the chest strap,
if necessary. The
chest pulse sen-
sor should be under your clothes, tight against your
skin, and as high under the pectoral muscles or
breasts as is comfortable. Make sure that the logo on
the sensor unit is facing forward and is right-side-up.
Pull the sensor unit away from your body a few inches
and locate the two electrode areas on the inner side
(the electrode areas are covered by shallow ridges).
Using saline solution such as saliva or contact lens so-
lution, wet both electrode areas. Return the sensor unit
to a position against your chest.
CHEST PULSE SENSOR CARE AND MAINTENANCE
• Thoroughly dry the chest pulse sensor after each
use. The chest pulse sensor is activated when the
electrode areas are wetted and the heart rate
monitor is put on; the chest pulse sensor shuts off
when it is removed and the electrode areas are
dried. If the chest pulse sensor is not dried after
each use, it may remain activated longer than nec-
essary, draining the battery prematurely.
• Store the chest pulse sensor in a warm, dry place.
Do not store the chest pulse sensor in a plastic bag
or other container that may trap moisture.
• Do not expose the chest pulse sensor to direct
sunlight for extended periods of time; do not expose
it to temperatures above 50° C (122° F) or below
-10° C (14° F).
• Do not excessively bend or stretch the sensor unit
when using or storing the chest pulse sensor.
• Clean the sensor unit using a damp cloth—never
use alcohol, abrasives, or chemicals. The chest
strap may be hand washed and air dried.
CHEST PULSE SENSOR TROUBLESHOOTING
The instructions on the following pages explain
how the chest pulse sensor is used with the con-
sole. If the chest pulse sensor does not function
properly, try the steps below.
• Make sure that you are wearing the chest pulse sen-
sor as described at the left. Note: If the chest pulse
sensor does not function when positioned as de-
scribed, move it slightly lower or higher.
• Use saline solution such as saliva or contact lens
solution to wet the two electrode areas on the
sensor unit. If heart rate readings do not appear until
you begin perspiring, re-wet the electrode areas.
• As you walk or run on the treadmill, position your-
self near the centre of the walking belt. For the
console to display heart rate readings, the user
must be within arm's length of the console.
• The chest pulse sensor is designed to work with
people who have normal heart rhythms. Heart rate
reading problems may be caused by medical
conditions such as premature ventricular contrac-
tions (pvcs), tachycardia bursts, and arrhythmia.
• The operation of the chest pulse sensor can be
affected by magnetic interference caused by high
power lines or other sources. If it is suspected that
this is a problem, try relocating the treadmill.
• The CR2032 battery may need to be replaced (see
page 16).
10
If there is a thin sheet of
clear plastic on the console,
remove it.
CAUTION:
Before operating the
console, read the following precautions.
• Do not stand on the walking belt when turn-
ing on the power.
• Always wear the clip (see the drawing
above) whilst using the treadmill. When the
key is removed, the walking belt will stop.
• Adjust the speed in small increments.
• To reduce the possibility of electric shock,
keep the console dry. Avoid spilling liquids
on it and use only a sealable water bottle.
STEP-BY-STEP CONSOLE OPERATION
Make sure that the power
cord is properly plugged
Clip
in (see page 9). Next,
step onto the foot rails of
the treadmill. Find the
clip attached to the key,
and slide the clip onto
the waistband of your clothes. Test the clip by care-
fully taking a few steps backward until the key is
pulled from the console. If the key is not pulled
from the console, adjust the position of the clip as
needed.
Note: The console can display distance and speed in
either kilometres or miles. (See HOW TO SELECT
KILOMETRES AND MILES on page 12.)
On/Reset
Button
Insert the key fully into the console.
1
Inserting the key will
not turn on the dis-
plays. The displays
Key
will turn on when the
On/Reset button is
pressed or when the
walking belt is started.
Note: If you just in-
stalled batteries, the displays will already be on.
Reset the speed control and start the walking
2
belt.
Slide the speed control
down to the Reset position.
Note: Each time the walk-
ing belt is stopped, the
speed control must be
moved to the Reset posi-
tion before the walking
belt can be restarted.
After you have moved the speed control to the
Reset position, slowly slide the speed control up-
ward until the walking belt begins to move at slow
speed. Carefully step onto the walking belt and
begin exercising. Change the speed of the walking
belt as desired by sliding the speed control.
To stop the walking belt, step onto the foot rails
and slide the speed control to the Reset position.
During the first few minutes that you use the tread-
mill, inspect the alignment of the walking belt, and
align it if necessary (see page 16).
