ProForm 7.25Q User Manual page 7

HOW TO LOWER THE TREADMILL FOR USE
1. Hold the upper end of the treadmill with your right hand
as shown. Using your left thumb, press the storage latch
and hold it. Pivot the treadmill until the frame and foot rail
are past the storage latch.
2. Hold the treadmill firmly with both hands, and lower the
treadmill to the floor. Do not drop the treadmill frame to
the floor. CAUTION: To decrease the possibility of in-
jury, bend your legs and keep your back straight.
Unlatched
Storage
Latch
14
3. Align the hole in the Handrail (1) with the indicated hole
in the right Upright (11). Thread a Handrail Screw (53)
two turns into the Upright and the Handrail at the angle
shown in drawing 3b. It may be helpful to lift up and push
down on the Handrail as you thread the Handrail Screw.
4. Refer to drawing 4a. Slide a Handrail Endcap (41) onto
the end of the Handrail (1). The Handrail Endcap should
fit on the Handrail as shown, with the narrow part of the
Handrail Endcap on top. Pivot the lower end of the
Handrail to the side as shown. Refer to drawing 4b. Fold
the flap on the Handrail Endcap to one side or the other
as you position the Handrail Endcap on the Upright (11)
as shown in drawing 4c.
5. Refer to step 3. Tighten the Handrail Screw (53).
Attach the other Handrail (1) to the left Upright (11) as
described in steps 2 to 4.
Attach the Storage Latch (14) to the left Upright (11) with
two Latch Screws (3). Be careful not to overtighten the
Latch Screws.
6. Refer to drawing 6a. Insert two of the included plastic ties
(A) through the indicated holes in the right Handrail (1).
Refer to drawing 6b. Look into the right Handrail (1) and
make sure the Wires (21) have been secured to the side
shown. Tighten the plastic ties (A).
3a 3b
1
53
11
Bottom View
4a 4b 4c
11
11
Narrow Part
Flap
1
41
5
1
11
3
14
6a 6b
1
A
1
7
53
A
21
