INSET LIVE FUEL EFFECT GAS FIRE
INSTALLATION and SERVICING GUIDE
THESE APPLIANCES ARE FOR USE IN THE UNITED KINGDOM (GB)
We trust that these instructions give sufficient details to enable this appliance to be installed and maintained satisfactorily. However, if
further information is required, our Valor advice line will be pleased to help.
Ring 0345 626 341 (Local call rates apply).
ULTIMATE
MODEL 417
THE NATURAL GAS MODEL IS FOR G20
AT A SUPPLY PRESSURE OF 20mbar
THE PROPANE GAS MODEL IS FOR G31
AT A SUPPLY PRESSURE OF 37mbar
AND THE REPUBLIC OF IRELAND (IE) ONLY
Please leave these instructions with the user
600A 935/04
