Factory Information

Factory Information
Page 40
The Factory module displays firmware version, serial number and other device
information in read-only setup registers (read-only registers can be viewed but not
changed).

Factory Module Settings

The device information provided is as follows:
Setup Register Description
Device Type A device type identifier (e.g. "8500" for the ION 8500)
Compliance A statement of whether the device is ION compliant or not
Options Shows model number of meter
Revision The meter's firmware version
Serial Num The meter's serial number
ION Version The ION version supported by the device
Template The name of the template (framework) installed on the device at the factory
Nom Freq The expected frequency of the power system being monitored
The Factory module also contains numerous read-only setup registers that hold
the calibration constants used at the factory.

How to TAG Your Meter

Three configurable setup registers are provided for you to enter your company
name and other text information you want stored in the meter:
Owner - This is a text register for storing user information (e.g. company name); it
can be up to 255 characters in length.
Tag 1 - This is a text register for storing user information (e.g. device location); it
can be up to 15 characters in length.
Tag 2 - This is a text register for storing user information (e.g. device number or
identifier); it can be up to 15 characters in length
