Changing the Parameters that are Logged

The meter's factory configuration logs a comprehensive set of energy, power and
harmonics parameters. You cannot change which parameters are logged by
configuring a setup register. If you are comfortable editing module links, you can
change the logged parameters by linking the output registers you want logged to
the inputs of an Data Recorder module.
N
OTE
Adding or deleting a log's parameters is an advanced procedure, as it requires changes to the links
between modules; use Designer (refer to the Designer section of the online
Setup.

Changing Waveform Recording

The Waveform Recorder modules do not require changes to their default settings.
If you want to change the format of the recorded waveforms, refer to the
Waveform Recorder module description in the ION Reference.

Default Logging Capacity

The default settings allow for a maximum time logging capacity of about 35 days
for the ION 8000 series meters. The following table summarizes the default
recording depths and recording intervals of the various Data recorders and
Waveform recorders in the meter.
ION 8300
Default Depth
Revenue Log 3360
Loss Log N/A
EgyDmd Log N/A
TOU Logs N/A
Hist Logs N/A
Harm Logs N/A
Transient Log N/A
Sag/Swell Log 100
N/A

Changing the Log Depths

Change the value in the Data Recorder's Depth setup register to increase the
number of records stored in the recorder. The RecordMode setup register controls
how the Data Recorder will overwrite old records; refer to the Data Recorder
module description in the online ION Reference before changing this setup register.
ION 8400 ION 8500
Default Depth Default Depth
3360 3360
3360 3360
1350 3360
50 50
N/A 3360
N/A 840
N/A 100
100 100
N/A 10
ION 8000 Series User Guide
ION Enterprise Help) or ION
Interval
900 seconds
900 seconds
900 seconds
Triggered on demand
900 seconds
3600
Triggered on demand
Triggered on demand
Daily, weekly, 10 min...
Chapter 12 - Logging
