Chapter 12 - Logging

Changing the Frequency of Logging

The five Periodic Timer modules that control the frequency of different data
recording are as follows:
"Revenue Log Trg" controls the frequency of the logging of revenue values
"Loss Log Trg" controls the frequency of Loss Compensation Data logging
"EgyDmd Log Trg" controls the frequency of logging for the Energy and
Demand Log (this log is used for generating reports using Reporter)
"Hist Log Trg" controls the frequency of Historic Data logging
"Harm Log Trg" controls the frequency of Harmonics logging
N
OTE
The life of the flash memory is estimated at 40 to 50 years of read/writes under normal conditions. A
meter programmed to write data recorders in short intervals significantly reduces flash memory life.
Change the value in the Period setup register to change the frequency of data
logging (Period values are specified in seconds). Do not change the Sync Mode
setup register.
EN50160 Data Recorders
For more information about the EN50160 data recorders, refer to the technical note
Power Quality: ION Meters and EN50160.

Default Logging Configuration

The following sections describe each Data Recorder and the parameters they log.
Revenue Log
The Revenue Log (Data Recorder #1) is configured for use with UTS MV90 billing
software. The Revenue log is located through the following folder path on the
meter's program: Advanced Configuration > Revenue Framework > Energy. The
default values logged by the Revenue Log are as follows:
Parameter Description
kWh del int Interval kWh delivered
kWh rec int Interval kWh received
kVARh rec int Interval kVARh delivered
kVARh rec int Interval kVARh received
kVAh rec int Interval kVAh delivered
kVAh rec int Interval kVAh received
kWh del kWh delivered
kWh rec kWh received
Configuring Data Logging
Parameter Description
kVARh del kVARh delivered
kVARh rec kVARh received
kVAh del kVAh delivered
kVAh rec kVAh received
Interval kWh total losses
kWh loss int
(Tran + Line)
kVARh loss int Interval kWh total losses
Period Length Logging Period in seconds
Period Status Logging Period verification
