Display System Mains Data Uo (Mains Info); Display Battery Temperature Levels Uo (Templevel Info) - Eltek Smartpack User Manual

Example: Flatpack2 DC power system with malfunctioning rectifier;
3 power shelves with 10 rectifiers (rectifier ID #04 malfunctions)
Rectifier ID 01 Rectifier ID 02
Serial No. 01 Serial No. 02
Rectifier ID 05 Rectifier ID 06
Serial No. 05 Serial No. 06
Rectifier ID 09 Rectifier ID 10
Serial No. 09 Serial No. 10
After rectifier reset:
3 power shelves with 9 rectifiers
(rectifier ID #10 reassigned to #04)
Rectifier ID 01 Rectifier ID 02
Serial No. 01 Serial No. 02
Rectifier ID 05 Rectifier ID 06
Serial No. 05 Serial No. 06
Rectifier ID 09
Serial No. 09
Display System Mains Data
You can display information about the power system's AC feed by selecting
"UserOption>Mains Info", via the Smartpack controller's front keys.
Following data may be displayed selecting the Mains Info sub options (level 3):
Option
NoOfPhases nn
Mains Status
Mains Voltage
Display Battery Temperature Levels
You can display how many hours the system's battery bank has been within a certain
temperature range (level) by selecting "UserOption>TempLevel Info", via the
Smartpack controller's front keys.
The information is displayed in the format [nn: <ddC
• nn: The number of the temperature range or level (01 through 10)
• <ddC The range's upper temperature value, in degrees Celsius
• hhhhhH The number of hours the battery bank has been within the
Using the PowerSuite program, you configure the Battery Lifetime Temperature monitor
to automatically activate an alarm when the system's battery bank has been within a
temperature range (or level) longer that a certain period of time. For each of the 10
temperature ranges, you can configure the upper and lower temperature values, and the
time limit.
User's Guide Smartpack Monitoring & Ctrl Unit,
Rectifier ID 03 Rectifier ID 04
Serial No. 03
Rectifier ID 07 Rectifier ID 08
Serial No. 07
Rectifier ID 03 Rectifier ID 04
Serial No. 03
Rectifier ID 07 Rectifier ID 08
Serial No. 07
Description
Number of Mains phases in the system's AC feed
The status of each of the phases
The AC voltage of each of the phases
temperature range
Serial No. 04
Serial No. 08
Serial No. 10
Serial No. 08
hhhhhH], which means:
