4 Front Panel Operation
Service Options
When you enter Menu Mode, you access the User Options. You may then scroll down to
the password protected Service Options.
The Service Option's password is factory-programmed to <0003>. We strongly
recommend that this password is changed as soon as the system is installed
How to browse the display menus
Entering Menu Mode
o
Press on the
Status Mode to Menu Mode
Browsing "down" to a menu option
o
Press the key, to scroll down within
the same menu level, and find menu
options (functions or parameters)
Selecting a menu option
o
Press on the
displayed menu option or parameter
Browsing "up" to a menu option
o
or level
Press the key to scroll up to the
previous menu option, and out to the
previous menu level.
For description of the Service menu options, refer to the PowerSuite online Help system.
20
key to change from
key to select the
User's Guide Smartpack Monitoring & Ctrl Unit,
Level 2
Service menu <ServiceOption>
NomVolt
BoostVolt
LoBattMaj
VoltAdjustment
LoBattMin
HiBattMaj
HiBattMin
LVBD
LVLD 1.1
VoltCalibration
ChangePassword
Password
SetManBoostTime
Start/StopBoost
Auto Boost Conf.
Nxt Test DateTime Date ↓↑ Time
End Volt
MaxTestDur ↓↑
Batt Test Setup
Test Int
Guard Time
Start/Stop Test
NoOfRects. ; nn Reset
Charge Curr Lim.
Battery Setup
NumOfString
CellCap Ah nn
Output Control
Change Date/Time
Alarm Output 1
RelayTest
Alarm Output 2
Batt Contactor
Load Contactor
Alarm Output nn
BattLifeTime Rst
SO
Level 3
↓↑
↓↑
↓↑
↓↑
↓↑
↓↑
↓↑
↓↑
↓↑
VoltCal
↓↑
↓↑
Enable/Disable ↓↑ & Threshold
↓↑
↓↑
↓↑
Enable/Disable ↓↑ & Max
↓↑
↓↑
VoltageCtrl / TempComp ↓
Date ↓↑ Time ↓↑
↑
↑
↑
↑
↑
350003.013, v5-2006-11
