3 Installation of Smartpack Controller

3. Installation of Smartpack Controller

Safety precautions

Get acquantied with the satety precautions on page 2, before installing or handling
the equipment.

Mounting and Removing the Controller

The Smartpack controller incorporates handles that serve both to lock the module
into position and to pull it out of its housing.
CAUTION: Do not hand-carry the controller by its handles. Cables are
plugged to the controller's rear panel. Open the handles before inserting the
Device
controller into the power shelf.
hazard
Hole to release the
handle's spring
Smartpack
mechanism
controller
Handle in locked position
Handle in
unlocked position
Figure 18 Smartpack controller's locking mechanism
Release the panel's upper left and right corners by inserting a small screwdriver
into the panel's upper left gap, and carefully press down and out to release the
locking tabs. Repeat on the upper right gap. Refer to the Flatpack2 system's quick
start guide for more information.
16
Mounting the Smartpack controller
1. Open the handles by
2. Insert the module fully into the power shelf, after
3. Lock the handles by
Removing the Smartpack controller
1. Open the handles by
2. Remove the module by

Removing Blind Panels

User's Guide Smartpack Monitoring & Ctrl Unit,
Mount blind panels in unused module locations.
inserting a screwdriver into the holes to release the
spring mechanism
plugging the cables to the rear panel
pushing the handles up into their housings (locked
position), so that the module is securely locked
inserting a screwdriver into the holes to release the
spring mechanism
using both handles to pull the module loose gently;
support from underneath; unplug the cables connected
to the rear panel
Electric
shock
350003.013, v5-2006-11
