Setting Up the PC
Before the modem is programmed and installed for the first time, it must have the latest
firmware on it. This can be found by logging into the modem per the instructions below.
On the "Device Info" page find "Software Version", this should be 2.02e.RC3-dss3. If it is
not, the firmware will need to be update before proceeding.
See
Page 14
of this document for instructions on flashing new firmware to the modem.
Setting Up the PC
Before you can get into your new BEC 7800TN Wireless modem, you will need to have the computer's Ethernet interface
to be set up for DHCP, or you will have to set up a static IP address.
Use the following address information if setting up a static IP in the computer's Ethernet interface:
IP ADDRESS: 192.168.10.100
SUBNET MASK: 255.255.255.0
GATEWAY: 192.168.10.1
PRIMARY DNS: 216.129.224.1
SECONDARY DNS: 216.220.0.1
Back to Top
Configuring a BEC 7800TN
Wireless ADSL Modem
|
Logging into BEC
Setup
Setup – Main Port
ATTENTION!
|
Configuring Wireless
|
Setup – Static IP
|
Finished
|
Firmware Update
1
Advertisement
Related Manuals for BEC 7800TN
Summary of Contents for BEC 7800TN
- Page 1 Setting Up the PC Before you can get into your new BEC 7800TN Wireless modem, you will need to have the computer's Ethernet interface to be set up for DHCP, or you will have to set up a static IP address.
- Page 2 Logging Into the BEC 7800N In order to log in, open a web browser (Internet Explorer works best for this), and in the address bar type in the following IP address. 192.168.10.1 After you input the IP address, press the "GO" button or press "ENTER" on your keyboard to access the page. If everything goes as anticipated, you will see a login screen prompting for username and password (Above).
- Page 3 Configuring Wireless After logging into the modem's home page, click "Wireless" on the left side of the page. Enter the "SSID" the customer would like to use. This is usually the customer’s last name. Once entered, click the "Apply" button to save changes. Back to Top...
- Page 4 To setup the wireless security click on the "Security" link on the left side of the page under "Wireless". The "Select SSID" should show the SSID you entered on previous page. “WPA/WAPI passphrase” by default is the MAC address (uppercase letters) which is listed on the underside of the modem on the MAC address label.
- Page 5 Setup If customer is ADSL/DHCP (Not FTTP), you are done configuring the BEC 7800TN modem! The modem is now ready for DHCP authentication. If customer is FTTP/DHCP then skip to “Setup – Main Port” on page 12 Proceed to the next page if the customer is NOT ADSL/DHCP or FTTP/DHCP.
- Page 6 After logging into the modem's home page, click the "Advanced Setup" link at the left of the page to begin configuring your modem. Back to Top...
- Page 7 Next you need to click on the "WAN" link at the left of the page. Back to Top...
- Page 8 Setup – Static IP This section is only for customers with a static IP. If customer is DCHP then proceed to “Setup – Main Port” on page 12 To configure the modem with the customers static IP click on the "WAN Service" link to the left. Here you’ll see two different interfaces.
- Page 9 First uncheck the “Enable” checkbox next to “Obtain an IP address automatically”. Now enter the customers static IP address in the “WAN IP Address” box. The subnet mask will go in the “WAN Subnet Mask” box and their gateway IP will go in the “WAN gateway IP Address Box”. Next the DNS information will need to be put in.
- Page 10 And now click on the "Next" button again. Back to Top...
- Page 11 And now click on the “Apply” button to save the changes. If the customer is FTTP then proceed to the next page “Setup – Main Port” If the customer is ADSL then the modem configuration is done. If the customer is DHCP, the modem is now ready for DHCP authentication.
- Page 12 Setup – Main Port On this page one can change the “Main Port” from “DSL” to “Ethernet” for use with a FTTP connection. The modem will use the “EWAN” port for its WAN connection instead of the “DSL” port. To set modem up for use on a FTTP choose “Ethernet” from this dropdown box. Once you have picked what port type to use click the “Change”...
- Page 13 Finished Now you are done configuring your BEC 7800TN modem! If the customer is DHCP, the modem is now ready for DHCP authentication. If customer has static IP the modem setup should be complete. Congratulations! You are now done configuring your BEC 7800TN Wireless ADSL modem.
- Page 14 Firmware Update Start the firmware update process by clicking on “Management” on the left side of the page. Back to Top...
- Page 15 Next click on “Update Software” listed under “Management” on the left hand side of the page. If this is the first time this modem is used it doesn’t matter which “Restart device with” option is chosen. If this modem is currently installed and you want all your current settings to be saved during the update choose “Current Setting”.
