1
TagB
QA TEST*
GRAYSCALE MODE
STAND ALONE
CALIBRATION*
SELF TEST MODE*
TEMPERATURE*
BACKLIGHT
1
LIFETIME*
HOURS RUNNING*
ILLUMINANCE*
TagC
INFORMATION*
*1 This item does not reset by FACTORY PRESET (Tag7).
Provides a quick daily visual image quality check of this diagnostic monitor by just using
a button on the monitor. See page 16.
This function changes the display image to monochrome.
OFF: The Display Image is COLOR.
MODE1: The signal Input is 8 bit monochrome. The display shows a grayscale image.
This mode uses only the Green channel of an R/G/B input signal.
MODE2: Input is R/G/B Color, but the monitor changes the color space to YUV. The
displayed image will become monochrome. Only Y data passes the R/G/B LUT.
Selects the Calibration mode (page 32).
1
1
Displays an all white screen.
1
Current internal temperature is shown in degrees (C).
The estimated remaining lifetime of the display backlight is indicated here. Backlight
lifetime depends mainly on the desired calibrated settings. The lower the calibrated
setting, the longer the backlight's estimated lifetime.
1
Shows total running time.
1
Shows the lux value calculated by the ambient light sensor. The ILLUMINANCE value is
dependent on the type and position of light source. It may differ from the value measured
by the illuminance meter.
1
Provides information about the current display resolution. Technical data, including the preset
timing currently being used and the horizontal and vertical frequencies is also displayed.
English-24
