NEC MultiSync MDC212C2 Installation & Maintenance Manual page 22

RED
GREEN
BLUE
UNIFORMITY
Tag2 SHARPNESS
RESPONSE
IMPROVE
COLOR
STABILIZATION
AMBIENT LIGHT
COMP.
(6 - AXIS ADJUST)
SHORTCUT
CUSTOM
Tag3 DIGITAL LONG
CABLE
(DVI input only)
Tag4 AUTO ADJUST*
(Analog input only)
AUTO CONTRAST*
(Analog input only)
*1 This item does not reset by FACTORY PRESET (Tag7).
Adjusts color gamut. When the selected settings are outside of the LCD gamut, the
indicator on the OSD will turn magenta.
This function electronically compensates for the slight variations in the white uniformity
level as well as for deviations in color that may occur throughout the display area of
the screen. These variations are characteristic of LCD panel technology. This function
improves the color and evens out the luminance uniformity of the display.
NOTE: Using the UNIFORMITY feature does reduce the overall peak luminance of the
display. If greater luminance is desired over the uniform performance of the display, then
UNIFORMITY should be turned off. A higher number produces a better effect, but may
also reduce CONTRAST RATIO.
This is a digital capability for keeping a crisp image at all signal timings. It continuously
adjusts to maintain as distinct or as soft image as you prefer, and is set independently
according to different timings. Press "LEFT" or "RIGHT" to adjust.
Turns the Response Improve function on or off. Response Improve may reduce blurring
that occurs in some moving images.
Stabilizes the color of the image. Compensates for a yellow color shift that occurs with
long-term LCD usage.
OFF: No function.
ON: Stabilizes Color.
NOTE: When the function is ON, the lifetime of the LUMINANCE setting level will be
reduced.
Adjusts the luminance and gamma value to be in user setting value including outside
luminance level.
OFF: No ambient light compensation.
1: Compensation based on the infl uence of external light measured during the
calibration.
2: Compensation based on the infl uence of surrounding light with constant
measurement of external light.
HUE: Adjusts the hue of each color*
menu color bars will show the amount of adjustment.
SATURATION: Adjusts the color depth of each color*
color vividness increases.
OFFSET: Adjusts the color brightness of each color*
color Brightness increases.
*2: RED, YELLOW, GREEN, CYAN, BLUE and MAGENTA.
You can select the PICTURE MODE which are displayed in PICTURE MODE shortcut
menu.
Compensates for image degradation caused by using a long cable.
A lower number produces less compensation.
1
Automatically adjusts the Image Position and H.SIZE settings and FINE settings.
Press "SELECT" to activate Auto Adjustment.
1
Adjusts the image displayed for non-standard video inputs. Press "SELECT" to adjust.
Any adjustment requires the image to have white portions.
2 . The change in color will appear on screen and the
English-20
2
. Press the "RIGHT" button and the
2 . Press "RIGHT" button and the
