1
OSD COLOR*
BOOT LOGO* 1
SIGNAL
INFORMATION*
FACTORY PRESET*
Tag8 DATE & TIME*
Tag9 SCHEDULE* 1
TagA ROTATION
DDC/CI
BLANK SIGNAL SKIP Skip no signal inputs when you change input signal with INPUT button.
INPUT SETTING*
(Analog input only)
*1 This item does not reset by FACTORY PRESET (Tag7).
"Tag window frame color", "Item select color" & "Adjust Window frame color" can be
changed.
The NEC logo is briefl y displayed after the monitor is powered on. This feature can be
turned on or off in the OSD.
Note: If the "EXIT" button is kept pressed while NEC logo is displayed, the BOOT LOGO
menu will appear. It is possible to change the BOOT LOGO setting.
Signal information can be displayed in the corner of the screen.
1
Signal information is either "ON/OFF".
1 Selecting FACTORY PRESET allows you to reset all OSD control settings back to the
factory settings. Highlighting the control to be reset and pressing the RESET button can
reset individual settings.
1 Sets the date, time, and daylight saving region. Date & time must be set in order for the
"SCHEDULE" function to operate.
Programs the GAMMA MEASURE working schedule.
Up to three different schedules can be programmed.
You can select the time and date for GAMMA MEASURE.
QC SCHEDULE:
Use the "Left" or "Right" buttons to select "GAMMA MEASURE only" or "GAMMA
MEASURE and then GAMMA ADJUST".
Use the down button and "SELECT" to edit schedule.
Use the "Left" or "Right" buttons to move the cursor horizontally.
Use the "Down" or "Up" buttons to up/down schedule number, date and time.
A square mark next to the number of the schedule indicates that the selected schedule
is in effect.
: enable : disable
INTERVAL:
Set the frequency with wich the schedule will be executed (days, weeks, months and
weeks per month).
When you set "0", the schedule works once.
NOTE: When a schedule overlaps, the schedule from the later would be canceled.
QC RESULT:
Show the past 14 results. The lower the number, it will be the new results.
Use the down button and "SELECT" to show schedule result.
Use the "Down" or "Up" buttons to show other schedule result.
OSD:
LANDSCAPE: Display the OSD with landscape mode.
PORTRAIT: Display the OSD with portrait mode.
PICTURE:
OFF: The window image is not rotated.
ON: The window image always rotated.
This function allows the DDC/CI function enable or DISABLE.
1
Video Band Width: Reduce the visual "noise" level of the input signal. The higher the
number, the greater the effect of reducing the noise. Press "LEFT" or "RIGHT" to select.
Clamp position: Operating your monitor at a non-standard timing may cause images to
appear darker than normal or have color distortion. Use of the Clamp position control will
adjust images to their normal state.
English-23
