NEC MD205MG - MultiSync - 20.1" LCD Monitor Specifications

NEC MultiSync
High-bright LCD displays ideal for color and grayscale medical imaging applications
Designed exclusively for the demanding needs of radiology, medical imaging,
PACS and mammography, the NEC MultiSync MD Series embodies the
precision, high performance and intelligence you'd expect from a world
leader in display technology. The series includes 2-, 3- and 4-Megapixel (MP)
color displays, and 3- and 5-MP grayscale displays.
Benefits you'll realize from these medically certified displays include:
• Outstanding image quality for both color and grayscale images due to
NEC's UA-SFT and SA-SFT liquid crystal technologies, which offers high
brightness without compromising contrast or viewing
• Color displays that feature brightness and contrast performance rivaling
grayscale displays
• Grayscale displays feature long life, high resolution and high brightness
• Fewer screen uniformity errors and automatic compensation for differences
in color/grayscale and luminance across the entire screen because of digital
uniformity correction on select models
• The MD212MC and MD213MC feature an integrated, tri-stimulus (three-color)
sensor that receives more light information than standard (brightness only)
sensors and, therefore, is extremely accurate and stable
• Each MD Series monitor comes calibrated out of the box to the DICOM
grayscale display function for luminance and every model features an
integrated front sensor or a backlight sensor
• More finely detailed, high-definition rendering of color images and crisper
display of even the most delicate shadings and color differences due to RGB
lookup tables (LUTs) as large as 12-bit
• Every display includes GammaComp™ MD software to ensure consistent image
quality by simple local or network interface for conformance to the DICOM
standard, while providing an easy-to-use QA environment for medical imaging
Without ColorComp With ColorComp
www.necdisplay.com
MD Series
®
Achieve complete color and brightness uniformity.
By nature, LCD panels contain uniformity errors,
which are visible as slightly brighter or darker
areas on the screen. To combat this inherent
trait, each MD Series display is individually
characterized during production and digital
uniformity correction is applied. This technology,
called ColorComp, reduces the non-uniformity
to virtually unnoticeable levels and applies a
digital correction to each pixel on the screen
to compensate for differences in color and
luminance.
Medical Desktop
Model Size Type
MD212MC 21.3" 2MP Color
MD213MC 21.3" 3MP Color
MD213MG 21.3" 3MP Grayscale
MD304MC 30" 4MP Color
MD205MG 20.1" 5MP Grayscale
For consistent image
quality the built in
front sensor constantly
monitors and maintains
brightness for
optimal DICOM GSDF
calibration and for non-
assisted conformance,
calibration and reporting
functions,the sensor is
capable of measuring
monitor brightness,
white-point and contrast
response.
