- Page 1 Adam Equipment MDW-160M MECHANICAL HEALTH AND FITNESS SCALE (P.N. 4283, Revision B4, May 2014) © Adam Equipment Company 2014...
- Page 2 © Adam Equipment Company 2014...
-
Page 3: Table Of Contents
CONTENTS INTRODUCTION ......................5 SPECIFICATIONS ......................5 INSTALLATION ......................6 GENERAL INSTALLATION ................... 6 HEIGHT ROD INSTALLATION ................7 MEASURING HEIGHT ....................8 WEIGHING OPERATION ................... 10 WARRANTY INFORMATION ................... 14 © Adam Equipment Company 2014... - Page 4 © Adam Equipment Company 2014...
-
Page 5: Introduction
INTRODUCTION • The MDW-160M Health and Fitness Scale can weigh a person as well as measure the height. • It is simple to use and can be moved around with the help of the wheel attachment at the bottom of the scale. -
Page 6: Installation
− 6 no. M6 x 12 screws − 6 no. M6 Lock washers − 2 no. Hex Head screws − Tool (Spanner/Wrench) 1. Column with head 2. Height measuring rod 3. Platform base 4. Wheel attachment © Adam Equipment Company 2014... -
Page 7: Height Rod Installation
4. Hook at the end of the Draft rod 5. Lever with pivot 6. M6 screws Push the lever. When the lever is in position, hook the draft rod around the pivot. ← An assembled view HEIGHT ROD INSTALLATION © Adam Equipment Company 2014... -
Page 8: Measuring Height
• Carefully lower the measuring arm, while keeping it horizontal, until it rests gently upon the top of the person’s head. If the person is shorter than 101.5 cm, push the latch to the right, while © Adam Equipment Company 2014... - Page 9 • Fold the measuring arm back to the vertical position and adjust the height rod back to the rest position (i.e. the measuring arm should be locked in place within the inner height rod and the inner rod should be at its lowest position). © Adam Equipment Company 2014...
-
Page 10: Weighing Operation
This will be indicated by the arrow indicator being in line with the horizontal mark on the right side of the column head. • It may be necessary to turn the zero-setting screw to the right or left until the scale balances. © Adam Equipment Company 2014... - Page 11 • The total reading of the two balancing masses will give the final weight of the person on the platform. For example, Lower mass 60 kg + Upper mass 2.5 kg = Total weight of the person is 62.5 kg. © Adam Equipment Company 2014...
- Page 12 © Adam Equipment Company 2014...
- Page 13 © Adam Equipment Company 2014...
-
Page 14: Warranty Information
WARRANTY INFORMATION Adam Equipment offers Limited Warranty (Parts and Labour) for the components failed due to defects in materials or workmanship. Warranty starts from the date of delivery. During the warranty period, should any repairs be necessary, the purchaser must inform its supplier or Adam Equipment Company. - Page 15 2011/65/EC, RoHS, on the Restriction of the Restricted substances referred to in Article 4(1) and use of certain hazardous substances in maximum concentration values tolerated by weight in electrical and electronic equipment (recast) homogeneous materials do not exceed prescribed limits. © Adam Equipment Company 2014...
- Page 16 © Copyright by Adam Equipment Co. Ltd. All rights reserved. No part of this publication may be reprinted or translated in any form or by any means without the prior permission of Adam Equipment. Adam Equipment reserves the right to make changes to the technology, features, specifications and design of the equipment without notice.
