8. FUNCTIONS AND OPERATION

OPERATION: The CO alarm is operational once the activation switch is slid to ON
position. The green LED will flash once every 30 seconds. The model CA6050 LCD
will also continuously display
LOW BATTERY CONDITION:
level, the alarm will chirp once per minute and the green LED will blink 5 seconds every
minute. The model CA6050 LCD will also display
information regarding service.
SERVICE CONDITION:
function and other critical components. If an internal failure of any of these components
should occur, the alarm will chirp twice (
LED will blink for 5 seconds every minute. The model CA6050 LCD will also
continuously display
See Section 14 for information regarding service.
END-OF-LIFE CONDITION: The electrochemical sensor has a minimum five year life
expectancy. Once the battery is activated, a microcontroller monitors the total time that
the alarm is under power. After five years of service, the "End-of-Life" signal will be
activated; the alarm will chirp once per minute and the
seconds at the same time. The model CA6050 LCD will also continuously display
to indicate that the sensor life has expired and the alarm should be replaced. See
Section 14 for handling an End-of-Life alarm.
ALARM CONDITION: When the batteries are active, and CO gas is detected at a level
and duration specified in Section 3
red LED will light. The alarm signal will sound 4 short beeps every 6 seconds.
ALARM
The red LED will flash in sync with the beeping sound. The model CA6050 LCD
ALARM
will also display the current CO Level detected. After having alarmed for more than 5
minutes, the alarm signal will change to 4 short beeps every 60 seconds. The alarm
signal is either manually or automatically reset. See Section 10
THE ALARM SOUNDS
TEST/RESET/MUTE BUTTON:
alarm for proper operation, and to temporarily mute horn for 5 minutes when alarm is
activated, for 24 hrs. during the first week of a "Low Battery Voltage" signal (
activation, or for 60 hrs. during the first month of an "End-of-Life" signal (
activation. The model CA6050 LCD will display the current CO level detected when
alarm is being tested, or
procedure.
LCD DISPLAY FUNCTION (FOR MODEL CA6050):
normally, the LCD will continuously display
(48° C), the LCD will display
more is detected, or alarm is activated, the LCD will automatically display the current
CO level detected. The LCD will display the
to indicate that the CO alarm's power is active.
When the battery voltage drops below an acceptable
An internal microcontroller continuously monitors the sensor
BEEP - BEEP
. This malfunction condition indicates a problem with the unit.
CO RESPONSE TIMES
.
The
TEST/RESET/MUTE
when an alarm signal is muted. See Section 9 for Testing
for 5 seconds every minute. If a CO level of 30 ppm or
symbol. See Section 14 for
) per minute and the
SERVICE
, the horn will sound and the
button is used to check the
When alarm is operating
. If room temperature exceeds 120° F
symbol if the battery has low voltage.
- 10 -
SERVICE
red LED will glow for 3
WHAT TO DO WHEN
red
)
)
