19.10. Radiation Control

The main application for this Waspmote Plug & Sense! configuration is to measure radiation levels using a Geiger sensor. For
this model, the Geiger tube is already included inside Waspmote, so the user does not have to connect any sensor probe to the
enclosure. The rest of the other sensor sockets are not used.
Figure : Radiation Control Waspmote Plug & Sense! model
Sensor sockets are not used for this model.
Note: For more technical information about each sensor probe go to the
Development section in Libelium website.
-90- v5.8
