Installation
26.2. Street Light installation
The node can be fixed to a street light using the PVC coated stainless steel cable ties provided by Libelium. Always be sure that
the enclosure is firmly tied and environmental elements (like wind) do not modify its position. Next pictures show examples of
typical installation processes using external or internal solar panel in combination with the provided accessories.
26.2.1. External solar panel
Step 1: Secure the mounting feet to Waspmote Plug & Sense!
Use provided screws to secure firmly the mounting feet to the node.
Figure : Securing the mounting feet to Waspmote Plug & Sense!
Step 2: Prepare the cable ties
Introduce cable ties through external holes of the mounting feet.
Figure : Preparing metal cable ties
-143-
v5.8
