Figure : Warranty stickers of the enclosure
Important note: Do not handle black stickers seals of the enclosure (Warranty stickers). Their integrity is the proof that Waspmote
Plug & Sense! has not been opened. If they have been handled, damaged or broken, the warranty is automatically void.

4.2. Parts included

Next picture shows Waspmote Plug & Sense! and all of its elements. Some of them are optional accessories that may not be
included.
8
7
Figure : Waspmote Plug & Sense! accessories: 1 enclosure, 2 sensor probes, 3 external solar panel, 4 USB cable, 5 antenna, 6 cable ties, 7 mounting feet
(screwed to the enclosure), 8 extension cord, 9 solar panel cable, 10 wall plugs & screws
5
10
4
1
2
-12-
General view
9
6
3
